- Page 1 AI ToF People Counting Sensor Featuring LoRaWAN ® VS133 User Guide...
- Page 2 Safety Precautions Milesight will not shoulder responsibility for any loss or damage resulting from not following the instructions of this operating guide. Though the device is compliant with Class 1 (IEC/EN 60825-1:2014), please DO NOT look at the ToF sensor too close and directly.
- Page 3 Revision History Date Doc Version Description May 24, 2023 V 1.0 Initial version 1. Add staff lanyard accessory; 2. Add installation height detection feature; Aug. 10, 2023 V 1.1 3. Add DST time feature; 4. Add ToF frequency setting.
-
Page 4: Table Of Contents
Contents 1. Product Introduction ......................... 5 1.1 Overview ...........................5 1.2 Key Features ..........................5 2. Hardware Introduction ........................5 2.1 Packing List ..........................5 2.2 Hardware Overview ......................... 6 2.3 Button and LED Indicators ...................... 6 2.4 Dimensions (mm) ........................7 3. -
Page 5: Product Introduction
1. Product Introduction 1.1 Overview VS133 is a sensor that uses second-generation ToF technology to accurately count people. This technology provides more precise depth maps and longer detection distances while maintaining an excellent privacy protection rate. The advanced ToF technology combined with an AI algorithm enables the sensor to handle complex scenes and distinguish non-human objects with up to 99.8% accuracy. -
Page 6: Hardware Overview
1 × 1 × 1 × Power Adapter Warranty Card Quick Guide 1 × VB01 Multifunctional 8 × Staff Lanyards Bracket Kit (Optional) (Optional) If any of the above items is missing or damaged, please contact your sales representative. -
Page 7: Dimensions (Mm)
2.4 Dimensions (mm) 3. Power Supply VS133 can be powered by power adapter (12VDC, 2A). 4. Access the Sensor VS133 provides user-friendly web GUI for configuration and users can access it via Wi-Fi connection. The recommended browsers are Chrome and Microsoft Edge. The default IP of Wi-Fi is 192.168.1.1, and default SSID is People Counter_XXXXXX (can be found on the label). -
Page 8: Operation Guide
5. Operation Guide 5.1 Dashboard After logging on to the device web GUI successfully, user is allowed to view live video as follows. -
Page 9: Rule
Parameters Description Reset Count Clear accumulated entrance and exit people counting values. Track When enabled, there is tracking line when people pass the detection area. 5.2 Rule Draw Detection Lines Users can draw detection lines to record the people count values which indicate the number of people enter or exit. - Page 10 Note: 1) The arrow direction of the detection line depends on your drawing direction. 2) Ensure that the detected target can pass through the detection line completely. It’s recommended that the detection line is perpendicular to the In/Out direction and on the center of the detection area without other objects around.
- Page 11 Rule Configuration Users can set the rules to ensure accurate counting. Parameters Description Set the device installation height. Click Detect to detect the current installation height automatically. Installation Height Note: Dark floor/carpet (black, grey, etc.) does not support to detect the installation height automatically.
-
Page 12: Communication
Children The device will detect the people shorter than child filter height as children. Distinction The device will detect the people who wear reflective stripes as staff tags on Staff Detection the visible parts (neck, shoulders, etc.) as staffs. -
Page 13: Lora
Wi-Fi SSID The unique name for this device Wi-Fi access point. Protocol 802.11b (2.4 GHz), 802.11g (2.4 GHz), 802.11n (2.4 GHz) are optional. Bandwidth 20 MHz or 40 MHz are optional. Channel Select the wireless channel. Auto, 1,...11 are optional. - Page 14 Parameters Description LoRa Status LoRaWAN network joining status of this device. ® Device EUI Unique ID of the device, which can also be found on the label. App EUI The Default App EUI is 24E124C0002A0001. Application Port The port used for sending and receiving data, default port is 85.
-
Page 15: Report
Number of When rejoin mode is enabled, set the number of detection. Detection Note: the actual sending number is Number of Detection + 1. LoRaWAN ® V1.0.2, V1.0.3 are available. Version Region Frequency plan of this device. RX2 Data Rate RX2 data rate to receive downlinks. -
Page 16: System
Parameters Description Time Unit Select the unit to generate the graph or export the data. Time Range Select the time range to generate the graph. Select the line to display the graph. Search Click to generate the graph according to the time range and line option. -
Page 17: User
5.5.2 User Parameters Description Click the admin on the user list, then you can click Modify to change the login password of this device. Modify Click to type administrator password, then set three security questions for your Security device. In case that you forget the password, you can click Forget Password... -
Page 18: Time Configuration
5.5.3 Time Configuration... -
Page 19: System Maintenance
Parameters Description Time Zone Choose the time zone for your location. Enable or disable Daylight Saving Time (DST). Daylight Saving Start Time: the start time of DST time range. Time End Time: the end time of DST time range. -
Page 20: Installation Instruction
Description Parameters Adjust the ToF frequency modulation mode to avoid the interference of surrounding IR devices. Please avoid using the same mode if there are multiple Frequency VS133 devices around. Adjustment Note: if there is only one option, please contact Milesight IoT support: iot.support@milesight.com... -
Page 21: Covered Detection Area
1.8 m, then the minimum installation height is 1.8+0.5+0.035=2.335 m. 6.2 Covered Detection Area The detection area covered by the device is related to the field of view angle of the device, the installation height and the target height. -
Page 22: Installation
Avoid 940nm light which may result in incorrect counting. Outdoor sunlight shining on the over channel will not have any effect, but the mirrored reflections that allow sunlight to shine on the ToF Sensor should be avoided. - Page 23 Step 4: Determine the mounting location and drill 3 holes, fix the wall plugs into the mounting holes, then fix the bracket base to the wall plugs via mounting screws. (Note: If the wire needs to be extended to the interior of the ceiling or wall, a wire hole with a suitable size is also required to be drilled.)
-
Page 24: Factors Affecting Accuracy
Avoid installing the device against the wall and ensure that the device keeps away from the wall at least 30 cm on the short side and 50 cm on the long side. Ensure that there are no other objects blocking the ToF light within a 30 cm radius of the ... - Page 25 09 (Hardware Version) 01 04 => V1.4 16 (Device SN) 16 digits 1f 07 00 4b => V31.7.0.75 1f (Software Version) d2 (Accumulated counter) Line 1 accumulated in counter, 4 bytes d2 (Accumulated counter) Line 1 accumulated out counter, 4 bytes...
-
Page 26: Downlink Command
