More Reasons To
Bring Home Plasma WEGA™
Flat Panel Television.
Selectable Widescreen Modes.
Wide Viewing Angle.
Remote Commander
®
Control.
Favorite Channel Setting.
Closed Caption.
Specifications
KZ-42TS1
KZ-32TS1
VIDEO
Panel type:
AC-type Plasma Display Panel with anti-reflection screen
Screen size: (viewable diag.): 42 inches (16:9)
32 inches (16:9)
Resolution:
1024 x 1024 pixels
1024 X 852 pixels
Viewing angle:
160°
160°
TV signals:
NTSC
NTSC
DTV/HDTV signals:
480i, 480p, 1080i, 720p
Computer signals:
Up to XGA signals (with optional cable)
Picture system:
Digital Picture Generator™ System, Pixel-by-Pixel I/P
Conversion, CineMotion™ reverse 3-2 pull-down
Sampling rate:
13.5 kHz to 140 MHz
AUDIO
Processing:
TruSurround
®
Sound
Output:
9W x 2 channels
7W x 2 channels
GENERAL
Power requirements:
120 V AC, 60Hz
120 V AC, 60Hz
Power consumption:
360W (standby, 2W)
270W (standby, 1.5W)
Dimensions (WHD):
41-5/8" x 30-1/8" x 5"
33-3/4" x 24-3/4" x 5-1/4"
(1056 x 764 x 124mm)
(856 x 626 x 132mm)
Weight:
81 lbs. 9 oz. (37kg)
56 lbs. 3 oz. (25.5kg)
INPUTS/OUTPUTS
INPUT:
S-Video:
(2)
Composite:
(2)
RF:
(1)
Component: (Y,Pb,Pr)
(1)
Component w/RGB/HV:
(1)
OUTPUT:
Audio
(1)
Sub-woofer:
(1)
Headphones
(1)
CONTROL S:
Input/Output (1)
Supplied Accessories:
• Remote Commander
®
Control Unit-RM 923Y
• AA Batteries (2)
• 75-ohm Coaxial Cable (1)
• AC Power Cord
• Operation Manual
Optional Accessories:
• WB-PW2 - Wall-Mounting Kit
Design and specifications are subject to change without notice.
