- Page 1 December 2022 167-001090EN-A xMB-9640 MODULE BALANCER Users Guide...
- Page 2 This page intentionally left blank.
-
Page 3: Table Of Contents
Contents General Safety Guidelines 1.Maintenance 2.Personal Precautions 3.Grounding & Power Cord Connections 4.xMB-9640 Location Locking Power Cord 5Wireless Safety Product Specifications 1 – Introduction & Overview Safety Precautions Connecting To AC Power Manual Conventions Front View Rear View Connections... - Page 4 Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527...
-
Page 5: General Safety Guidelines
IMPORTANT: There are no user-serviceable parts inside the xMB-9640. At no time should personnel remove any cover. • Ensure that the AC power line ground is connected properly to the xMB-9640 input connector or chassis. Similarly, other power ground lines including those to application and maintenance equipment must be grounded properly for both personnel and equipment safety. -
Page 6: Personal Precautions
1.8 Do not overcharge the battery (See Section 3). 1.9 Charge the battery in a dry, well-ventilated area. 1.10 Never place articles on or around the xMB-9640, or locate the xMB-9640 in a way that will re- strict the flow of cooling air through the cabinet. -
Page 7: Grounding & Power Cord Connections
2.8 NEVER charge a frozen battery; thaw it out first. Grounding & Power Cord Connections 3.1 The xMB-9640 must be grounded to reduce risk of electric shock. The xMB-9640 is equipped with an electric cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 8: Xmb-9640 Location
The xMB-9640 depends upon the surrounding air for cooling. The free flow of air is important as is the air temperature. The xMB-9640 must be mounted so that air can freely circulate all around it. -
Page 9: Locking Power Cord
General Safety Guidelines xMB-9640 Locking Power Cord Always pull back on the red tab on the side of the power cord connector to release/remove it from the charger’s power socket. Pull Back To Release Storage Always store the charger in safe, dry location and maintain it in perfect condition. -
Page 10: Product Specifications
• 5” Touch Screen Operating Parameters • Input Voltage: 100 – 240 , 50/60 Hz; 12A max. • Output: 48 V , 40A 96 V , 20A Humidity • 15% to 85% R.H., non-condensing Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527... -
Page 11: Introduction & Overview
• Always wear Personal Protection Equipment (PPE) when working with or around batteries. • Keep hair, hands, and clothing as well as the xMB-9640 cords and cables away from moving engine parts. • Remove any jewelry or watches before you start servicing the battery. -
Page 12: Front View
Touch Screen Display USB Port Power Button Rear View High Voltage Cable Connection Cell Measurement Cable Connection Fuse Door Power Cord Socket Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527... -
Page 13: Connections
1 – Introduction & Overview xMB-9640 Connections Locking Power Cord Pull back on the red tab on the side of the connector to release/remove the power cord from the Balancer power socket. Pull Back To Release Charging Cables Connect the low voltage cable. -
Page 14: Main Menu
The measurement of module Setup/adjust: default language, voltage, average cell voltage, display/sound settings, tool and sensor temperature. software version information. Settings Module Also displays voltage and Diagnostics temperature delta. Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527... -
Page 15: Initial Setup
1 – Introduction & Overview xMB-9640 Initial Setup Upon initial power-up, the Language Settings screen is displayed. Tap Next to continue. System Select the Controller default language displayed on the Language screen. Test Result Select the Controller default language for all displayed tests Language and test results. -
Page 16: Module Balance
IMPORTANT: Make sure to properly prepare the battery pack by following all required guidelines Refer to your documentation for complete information. Before balancing a battery module, make sure all of the external components connected to the xMB-9640 are in good working order. Parameters... - Page 17 2 – Module Balance xMB-9640 Once the module is detected and verified, press Next to start the balance procedure. Press Stop to exit. The results are displayed on the xMB screen. www.midtronics.com...
-
Page 18: Transportation Discharge
IMPORTANT: Make sure to properly prepare the battery pack by following all required guidelines Refer to your documentation for complete information. Before balancing a battery module, make sure all of the external components connected to the xMB-9640 are in good working order. Parameters Discharge –... - Page 19 3 – Transportation Discharge xMB-9640 Press Next to start the Transportation Discharge procedure. Press Stop to exit. The results are displayed on the xMB screen. www.midtronics.com...
-
Page 20: Module Diagnostic
The xMB displays Cell Voltage, Temperature, Cell Delta and Module Voltage. The second screen displays the voltages per found cell. Press Done to return to the Main Menu. Hazardous voltage. An improper connection can result in electric shock Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527... -
Page 21: History
5 – History xMB-9640 5 – History Use History to access the tool usage history. It displays complete and incomplete Balance or Discharge sessions. History At the Main Menu, tap History to display the Tool History screen. Complete Balance or... -
Page 22: Settings
Use this function to return the tool to the original as built configuration including all history and test settings. IMPORTANT: All previous modifications to the original settings will be overwritten. Legal Information Displays software attribution information Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527... - Page 23 5 – History xMB-9640 www.midtronics.com...
- Page 24 Midtronics products are warranted to be free of defects in materials and workmanship for a period of two (2) years from date of purchase. Midtronics will, at our option, repair or replace the unit with a re-manufactured unit. This limited warranty applies only to Midtronics products, and does not cover any other equipment, static damage, water damage, overvoltage damage, dropping the unit, or damage resulting from extraneous causes including owner misuse.
