MIC360 ® WITH
XD MICROPHONE
QUICK START GUIDE
Remote Volume Control
OWN,
Source Indicator
Up/Down—Remote
OTHER,
LINE.
Indicates
volume controls
which source will be
controlled by the Up/Down
remote volume controls
Battery and power
Charging status indicator
status indicator
REC—starts/stops
recordings (additional
SELECT—Change the
hardware required: camera)
source (OWN, OTHER
or LINE) to be controlled
by the Up/Down remote
PWR—Power ON/Off and
volume controls
mute control
Foam Cap
XD Microphone
Insert Clip
Foam Ball
Advertisement
Related Manuals for Audio enhancement MIC360
Summary of Contents for Audio enhancement MIC360
- Page 1 MIC360 ® WITH XD MICROPHONE QUICK START GUIDE Remote Volume Control OWN, Source Indicator Up/Down—Remote OTHER, LINE. Indicates volume controls which source will be controlled by the Up/Down remote volume controls Battery and power Charging status indicator status indicator REC—starts/stops recordings (additional SELECT—Change the...
- Page 2 XD MICROPHONE LINKING With the microphone off, press the Link button on the front of the amplifier, side of the BEAM, or rear of the XD Solo (Look for the blinking Yellow LED). On XD Teacher Microphone Successful microphone linking will press and hold REC button.
- Page 3 INSTALLING THE XD MICROPHONE INTO THE MIC360 ® Insert your fingers between the black foam cap and the blue ball, and rotate the black cap counter-clockwise. (Figure 1) Lift the black foam cap to reveal the internal microphone holder. Temporarily set the cap aside.
- Page 4 Charge the microphone at the end of each day by removing the foam cap (see Figure 1 on Page 3), and connecting a micro-USB cable to the plug on the inside of the Mic360. After connecting the microphone to the charger, the charge indicator (green) indicates the charging status.
