Sealey TP6801.V2 Instructions

thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instructions protection
1. Safety
warNiNg! ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this
‰
equipment.
Familiarise yourself with product application and limitations, as well as the specific potential hazards peculiar to this product.
9
maintain the pump in good condition (use an authorised service agent).
9
replace or repair damaged parts. use genuine parts only. non authorised parts will invalidate the warranty.
9
Use only to pump NON-Corrosive fluids such as oil, anti-freeze, degreasants, solvents, agricultural and industrial chemicals.
9
ensure safety eye protection and protective clothing are worn when using this product.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non slip shoes.
9
Keep children and unauthorised persons away from the working area.
9
dispose of waste liquids in accordance with local authority regulations.
9
do Not use to extract corrosive fluids.
8
do Not dismantle, tamper with or adapt the pump for any purpose other than for which it is designed.
8
do Not use the unit if it has been dropped or mishandled, check the unit to ensure there is no damage.
8
do Not use the pump as a handle to move the fluid drum.
8
Keep the pump clean and store in a safe dry, childproof location.
9
warNiNg! do Not allow uncontrolled discharge of fluids thus polluting the environment.
8
2. iNtroductioN
Steel barrelled, self priming, lever pump. Supplied with 2"BSP adaptor and dip-tube suitable for 50 to 205ltr drums. Suitable for oils, antifreeze,
degreasants and other non-corrosive fluids. High flow unit delivers approximately 500ml per stroke. Supplied with two delivery nozzles, one
standard swan neck and one acute angle with filter for removing impurities from fluids.
3. operatioN
3.1. Attach the the required discharge spout (fig.1, fig.2) to the pump ensuring that seal beteen spout and pump body is correctly fitted.
3.2. screw the suction tube into the underside of the pump, attach extention tube with seals as required.
3.3. insert the pump into the 2" BsP drum opening and hand tighten.
3.4. Pump handle up and down to dispence liquid.
fig.1
© Jack sealey limited
instructions for
Heavy-duty lever pump HigH flow
model no:
Wear protective Wear safety
gloves footwear
Original Language Version
tp6801.v2
Wear protective
clothing
fig.2
tP6801.V2 | issue 1 22/09/16
