LIVE SOUND & INSTALLATION
TNA-2051& TNA-1200S-G2
USER MANUAL
DESIGNED AND ENGINEERED IN THE UK
WWW.HHELECTRONICS.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the TESSEN TNA-1200S-G2 and is the answer not in the manual?

Questions and answers

Related Manuals for HH Electronics TESSEN TNA-1200S-G2

Summary of Contents for HH Electronics TESSEN TNA-1200S-G2

  • Page 1 LIVE SOUND & INSTALLATION TNA-2051& TNA-1200S-G2 USER MANUAL DESIGNED AND ENGINEERED IN THE UK WWW.HHELECTRONICS.COM...
  • Page 2 TNA-2051 - SPECIFICATIONS / CABINET DIMENSIONS   13-18.____________________ L ANGUE FRANÇAISE   19-24.____________________ DEUTSCHE SPRACHE   25-30.____________________ LENGUA ESPAÑOLA   31-36.____________________ IDIOMA PORTUGUES   中文 37-42.____________________   한국어 43-48.____________________ © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 3 To prevent electrical shock or fire hazard, do not expose this appliance to rain or moisture. Before using this appliance please read the operating instructions. WARNING: © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 4 2 2 2 2 2 2 (INPUT) (LINK) X-OVER + + + DO NOT CONNECT A SECOND AMPLIFIER TO THE LINK OUTPUT OR THE M4 TERMINAL CONNECTORS! © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 5 Depending on the combination of holes used, a horizontal or angled arrangement can be achieved. The fit options are printed on the side bracket. In all instances, the location notch should point towards the front face of the cabinet. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 6 A TNA-2051 requires the use of Side Brackets only. As with the TNA-1200S-G2, spring washers must be used with all screws! SPRING WASHER LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 7 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 8 M8 x 20 hex bolts. PLEASE NOTE: A maximum of four TNA-2051 and two TNA-1200S-G2 should be used on the Dolly Board. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 9 LEVEL LEVEL FREQUENCY FREQUENCY LEVEL LEVEL FREQUENCY FREQUENCY FULL SYSTEM 2x TNA-1200S-G2 Passive Subwoofer 2x TNA-1800S-G2 Passive Subwoofer 8x TNA-2051 Passive Top Line Array Box © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 10 LEVEL FREQUENCY FREQUENCY LEVEL LEVEL FREQUENCY FREQUENCY FULL SYSTEM 2 4x TNA-1200S-G2 Passive Subwoofer 4x TNA-1800S-G2 Passive Subwoofer 16x TNA-2051 Passive Top Line Array Box © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 11 2 Measured in Full space (4π) conditions 3 Calculated maximum SPL based on rated power handling (Dimensions in mm) STACKING REBATES Ø 42 457.3 OVER SOCKETS OVER FEET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 12 1 AES standard Pink Noise 12dB crest factor 2 hours 2 Measured in Full space (4π) conditions 3 Calculated maximum SPL based on rated power handling 4 System Max SPL based on 4x TNA-2051 © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 13 En raison de la facilité avec laquelle l'amplificateur peut être basculé entre les positions droite et inclinée, utilisez uniquement l'amplificateur sur une surface plane et stable. NE PAS faire fonctionner l'amplificateur sur un bureau, une table, une étagère ou autre plate-forme inappropriée. 13  © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 14 2 2 2 2 2 2 (INPUT) (LINK) X-OVER + + + NE PAS CONNECTER UN DEUXIÈME AMPLIFICATEUR À LA SORTIE LINK OU AUX BORNIERS ! © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 15 TNA-2051. Selon la combinaison de trous utilisée, une disposition verticale ou angulaire peut être obtenue. Les options d'ajustement sont imprimées sur le support latéral. Dans tous les cas, l'encoche d'emplacement doit pointer vers la face avant de l'enceinte. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 16 Un TNA-2051 nécessite l'utilisation de supports latéraux uniquement. Comme pour le TNA-1200S-G2, les rondelles doivent être utilisées avec toutes les vis! SPRING WASHER LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 17 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 18 Array a été correctement positionné. six boulons hexagonaux M8 x 20. VEUILLEZ NOTER: Un maximum de quatre TNA-2051 et deux TNA-1200-G2 doivent être utilisés sur le chariot. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 19 Leichtigkeit, mit der der Verstärker zwischen geraden und schrägen Rücken Positionen bewegt werden kann, verwenden Sie nur den Verstärker auf einer ebenen, stabilen Oberfläche. NICHT den Verstärker auf einem Schreibtisch, Tisch, Regal oder sonst eine ungeeignete nicht stabile Plattform stellen. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 20 2 2 2 2 2 2 2 2 2 (INPUT) (LINK) X-OVER + + + SCHLIESSEN SIE KEINEN ZWEITEN VERSTÄRKER AN DEN LINK-AUSGANG ODER DIE M4-ANSCHLÜSSE AN! © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 21 TNA-2051-Satelliten. Je nach Kombination der verwendeten Bohrungen kann eine vertikale oder abgewinkelte Anordnung erreicht werden. Die Passungsoptionen werden auf der Seitenhalterung gedruckt. In allen Fällen sollte die Positionskerbe auf die Vorderseite der Box zeigen. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 22 Ein TNA-2051 erfordert nur die Verwendung von Side Brackets. Wie beim TNA-1200S-G2 müssen Federscheiben mit allen Schrauben verwendet werden! SPRING WASHER LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 23 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 24 TNA-DF1 (mit zwei Seiten- und Array entsprechend positioniert wurde. einer hinteren Halterung) befestigt. BITTE BEACHTEN SIE: Auf dem Dolly Board sollten maximal vier TNA-2051 und zwei TNA-1200-G2 verwendet werden. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 25 Debido a la facilidad con que puede ser que el amplificador se mueva entre las posiciones recta e inclinada, utilice sólo el amplificador sobre una superficie nivelada y estable. NO haga funcionar el amplificador en un escritorio, mesa, estantería o plataforma no estable o no apta. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 26 2 2 2 (INPUT) (LINK) X-OVER + + + NO CONECTE UN SEGUNDO AMPLIFICADOR A LA SALIDA DE LINK NI A LOS CONECTORES DEL TERMINAL M4! © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 27 Las opciones de fijación se encuentran imprimidas en los adaptadores laterales. En todas las instancias, la grabación de posición en el adaptador debe ser apuntada en sentido frontal con relación a la caja. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 28 La caja satélite TNA-2051 requiere el uso de adaptadores laterales apenas. ¡Igual al sub TNA-1200S-G2, arandelas de muelle deben ser usadas en todos los tornillos! SPRING WASHER LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 29 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 30 20 tornillos Hexagonales. POR FAVOR NOTE: El máximo de cuatro satélites TNA-2051 y dos subwoofers TNA-1200-G2 deben ser usados en el carrito. No ponga nada más. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 31 Devido à facilidade com que o amplificador pode ser movida entre as posições de costas rectas e inclinada, usar apenas o amplificador numa superfície plana e estável. NÃO operar o amplificador em uma escrivaninha, mesa, prateleira ou de alguma forma inadequada plataforma nonstable. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 32 2 2 2 (INPUT) (LINK) X-OVER + + + ¡NO CONECTE UN SEGUNDO AMPLIFICADOR A LA SALIDA DE LINK NI A LOS CONECTORES DEL TERMINAL M4! © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 33 As opções de fixação se encontram gravadas nosadaptadores laterais. Em todas as instâncias, a gravação de posicionamento no adaptador deve ser considerada com estas apontadas para a frente da caixa. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 34 A caixa satélite TNA-2051 requer o uso de adaptadores laterais apenas. Igual ao exemplo do sub TNA-1200S-G2, arruelas SPRING WASHER devem ser usadas em todos os parafusos! LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 35 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 36 20 parafusos Hexagonais. POR FAVOR NOTE: O máximo de quatro satélites TNA-2051 e dois subwoofers TNA-1200-G2 devem ser usados no carrinho. Não coloque nada mais. 36  © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 37 为了降低触电风险，请不要打开盖子。里面不含任何用户可用的配件。请将维修交于被许可的人员。 WARNING: 为避免触电或火灾，请不要将本产品置于雨中或潮湿环境中。在使用本产品前，请仔细阅读操作说明。 该产品仅 用于 2000m 地 全使用 该产品仅适用于非热带气候条件下安全使用 2000m 如果你的产品是倾斜的结构或是后倾款式的箱体，请小心使用该设计 征。由于功 可 在 和后倾 式 间转 换，请在平坦、 固的 面使用该产品。请不要在桌子、架子或其 不 合、不 固的平 上使用该功 。 © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 38 1 1 1 1 1 1 + + + 2 2 2 2 2 2 2 2 2 (INPUT) (LINK) X-OVER + + + 请勿将第二个放大器连接到链路输出或 M4 端子连接器！ © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 39 LIVE SOUND & INSTALLATION LINE ARRAY   TNA侧边支架用于在TNA-1200S-G2和TNA-2051箱体之间进行机械固定/支撑。 根据所用 安装的方式进行组合，可以实现垂直或成角度的布置。 正确的安装方式印在侧面支架上。 在所有情况下，定位 槽口都应指向箱体的 正面。 © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 40 SPRING WASHER REAR BRACKET SPRING WASHER LOCKNUT SPRING WASHER LOCKNUT 每个螺钉必须使用弹簧垫圈！ SPRING WASHER SIDE BRACKET 安装支架时，请格外小心，不要交叉使用侧面螺钉！ TNA-2051的吊挂支架 与TNA-1200S-G2一样， 每个螺钉必须使用弹簧垫圈！ SPRING WASHER LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 41 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 42 LIVE SOUND & INSTALLATION LINE ARRAY   TNA-DF1 - DOLLY BOARD TNA-DF1轻巧坚固的设计使扬声器可以轻松地放置和配置，以适应需求。 TNA-1200S-G2用六个M8 x 一旦正确放置设备后，确 20六角螺栓固定在TNA- 保将折片固定在后轮上。 DF1上（使用两侧和一个后 支架）。 请注意：一块小板车上最多可使用四个TNA-2051和两个TNA-1200S-G2. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 43 LIVE SOUND & INSTALLATION LINE ARRAY   CAUTION: WARNING: © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 44 2 2 2 2 2 2 2 2 2 (INPUT) (LINK) X-OVER + + + 두 번째 앰프를 링크 출력이나 M4 단자 커넥터에 연결하지 마십시오 © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 45 TNA 사이드 브라켓은 TNA-1200S-G2 와 TNA-2051체결시 고정될 수 있도록 사용됩니다. 구멍의 조합에 따라 수직이나 각을 주는 배열이 가능합니다. 장착 옵션은 브라켓 상에 표기되어 있습니다. 모든 경우에 있어서 화살 표의 부분이 스피커 전면 부로 향하도록 위치해야 합니다. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 46 FLYING BRACKET TO TNA-2051 TNA-2051는 사이드 브라켓만 필요로 합니다.. TNA-1200S-G2 와 마찬가지로, 스프 링 와셔는 반드시 각각의 나사와 사용 SPRING WASHER 되어야 합니다! LOCKNUT SPRING WASHER SIDE BRACKET © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 47 Carton dimensions (HWD) 6.7Kg, 14.8 lbs Packed weight In the interest of continued development, HH reserves the right to amend product specification without prior notification. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 48 TNA-1200S-G2 는 M8x20 육각 후 바퀴 브레이크가 걸려있 볼트 6개로 TNA-DF1(측면 2개, 는지 확인합니다. 후면 브라켓 1개)에 고정됩니다. 주의사항: Dolly Board에는 최대 4개의 TNA-2051과 2개의 TNA-1200S-G2 이 허용됩니다. © 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 49 hhelectronics hhelectronics Model number: hhelectronics Serial number: Place of purchase: Date of purchase: www.hhelectronics.com REVISION 1.00...
