- Page 1 U190P Floor Sweeper Instruction Manual...
- Page 2 We explore safer, higher-end and more user-friendly cleaning equipment through technical advantage and idea innovation.
- Page 3 If this manual is lost, please contact us immediately and we will be glad to provide you with a new one. All technical details included in this manual are property of Anhui Chancee Technology Co., Ltd and are protected by law. In this manual we use illustrations to show the components and functions of the machine.
-
Page 4: Table Of Contents
Contents Components and technical parameters Chapter 1 General description 1.1 Contents and purposes 1.2 General instructions 1.3 Safety requirements for the batteries 1.4 General safety requirements Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.2 Operation process of the machine 2.3 Cautions during the operation Chapter 3 Regular inspection and replacement of damaged parts 6/10... - Page 5 Components ① Steering wheel ⑥ Alerting light ⑪ Inspection port ② Baffle lifting pedal ⑦ Water tank ⑫ Ceiling ③ Headlight ⑧ Anti-slippery tire ⑬ Supporting rod ④ Side groom ⑨ Groom cover ⑭ Taillight ○ ⑤ Leather Seat ⑩ Controlling panel 15 Debris hopper Technical parameters Category...
-
Page 6: Chapter 1 General Description
Chapter 1 General description 1.1 Contents and purposes Potential risks concerning the use of the machine are listed in the following sections. Since most accidents take place when safety rules are ignored, it is necessary that you read them carefully and take precautions before getting started. -
Page 7: Safety Requirements For The Batteries
If some spare parts need to be replaced, you can purchase them from the original manufacturer or an authorized distributor. To make sure that the machine is in the proper operating and safety condition, the user or service center must abide by what is stated in Chapter III and Chapter V. Attention must be paid even when the machine is about to be dismantled and ... -
Page 8: Chapter 2 Operating The Machine
Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.1.1 Key controlling buttons of the machine ① Loudspeaker button ② Sprinkler button ③ Headlight button ④ Main light button ⑤ Forward/backward button ⑥ Sweeping button ⑦ Power display ⑧... - Page 9 2.1.3 Adding water to the water tank Before using the machine, add clean water to the clean water tank. Pay attention to the water quality so that the waterway will not be blocked. 2.2 Operating the machine 2.2.1 Before the operation Before getting started, make sure that no doors or covers are open and the ...
- Page 10 2.3 Cautions 2.3.1 General instructions When the brushes are rolling, do leave the machine in the same place for a long time, because this would leave unnecessary marks on the ground. If you need to remove large light garbage, you can lift the front baffle so that ...
-
Page 11: Chapter 3 Regular Inspection And Replacement Of Damaged Parts
Chapter 3 Regular inspection and replacement of damaged parts 3.1 Regular inspection Time interval (h) Regular inspection items Battery power Carbon brushes of the motors Is the main groom entangled? Are there particles and/or crystals in the water tank? Buttons on the control panel and electronic components Are the brushes worn? Is the filter blocked? -
Page 12: Replacement Of The Main Groom
3.3 Replacement of the main groom Before replacing the main brush, place the machine on the flat ground and make sure that it is powered-off. Open the right board of the machine, use an open-end wrench to remove the ... -
Page 13: Replacement Of The Filter Element
3.4.2 Replacement of the side brushes Step 1: loosen the Allen screws of the side brushes; Step 2: remove the screws shown in the picture and take out the old brush(es); Install the new brush(es) in the reverse direction. Note: use gloves to protect your hands from being hurt. -
Page 14: Replacement Of The Fuses
3.7 Replacement of the fuses When an electrical unit is overloaded or the current is too large, the corresponding fuse is blown automatically to protect the unit and the machine. 3.8 Removal and installation of the garbage can Make sure that the machine is powered-off. ... -
Page 15: Cleaning Of The Filter Screen
3.10 Cleaning of the filter screen Remove the filter cover, take out the filter screen and wash it with clean water. 3.11 Cleaning of the filter element of the vibrator Open the board of the machine and remove the fixing nuts of the baffle, and ... -
Page 16: Chapter 4 Common Problems And Solutions
Chapter 4 Common problems and solutions Problems Causes Solutions The main fuse is blown Replace the main fuse Charge the batteries (Charge the The machine is out of batteries once a month if the machine power The batteries have no power output is not going to be used for a long time) Replace the broken batteries The chains have fallen... -
Page 17: Chapter 5 Maintenance
Chapter 5 Maintenance Regular maintenance is necessary in order for the machine to be in its best condition, as well as to extend its service life and ensure the operator’s safety. The time interval of maintenance can be changed under certain circumstances, but this must be determined by a professional technician. -
Page 18: Chapter 6 After-Sale Services
Chapter 6 After-sale services 6.1 General description Seven-day guaranteed return, fifteen-day guaranteed replacement, one-year warranty for the whole machine, 6-month warranty for damaged parts, and no warranty for consumables (calculated from the next day after receiving the machine). The delivery receipt and purchase invoice are certificates for warranty and ... -
Page 19: Warranty Card
Warranty Card 用户名 联系电话 User’s name 通讯地址 票据号 Address Bill No. 购买时间 机身编号 Date of purchase Serial number 产品型号 日期 Type of product Date 更换配件： Accessories to be replaced: 故障描述： Fault description:... - Page 20 Anhui Chancee Technology Co., Ltd. Direction: 11 Qiaowan Road, Heifei, Anhui, China Website: www.chanceeglobal.com...
