Summary of Contents for CHANCEE U125
- Page 1 U125 Floor Sweeper Instruction Manual...
- Page 2 We explore safer, higher-end and more user-friendly cleaning equipment through technical advantage and idea innovation.
- Page 3 If this manual is lost, please contact us immediately and we will be glad to provide you with a new one. All technical details included in this manual are property of Anhui Chancee Technology Co., Ltd and are protected by law. In this manual we use illustrations to show the components and functions of the machine.
-
Page 4: Table Of Contents
Contents Components and technical parameters Chapter 1 General description 1.1 Contents and purposes 1.2 General instructions 1.3 Safety requirements for the batteries 1.4 General safety requirements Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.2 Operation process of the machine 2.3 Cautions during the operation Chapter 3 Regular inspection and replacement of damaged parts 8/10... -
Page 5: Components And Technical Parameters
Components ① Steering wheel ⑥ Leather seat ⑪ Garbage can ② Brake bracket ⑦ Alarming light ⑫ Controlling panel ③ Front baffle lifting pedal ⑧ Anti-slippery tire ⑬ Inspection hole ④ Front light ⑨ Water tank ⑤ Hard-hair side brush ⑩... -
Page 6: Chapter 1 General Description
Chapter 1 General description 1.1 Contents and purposes Potential risks concerning the use of the machine are listed in the following sections. Since most accidents take place when safety rules are ignored, it is necessary that you read them carefully and take precautions before getting started. -
Page 7: Safety Requirements For The Batteries
When a failure is produced, make sure that it is due to the lack of regular maintenance. If some spare parts need to be replaced, you can purchase them from the original manufacturer or an authorized distributor. To make sure that the machine is in the proper operating and safety condition, ... - Page 8 save much time as well as take precautions to protect the machine and yourself. It is vital that you become familiar with all the accessories and components before turning on the machine. Read our instructions carefully so that you will not be confused when you get started. - 4 -...
-
Page 9: Chapter 2 Operating The Machine
Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.1.1 Key controlling buttons of the machine ① Loudspeaker button ② Sprinkler button ③ Voltmeter (the current voltage of the batteries is shown; charge the batteries immediately when the voltage is lower than 42V) ④... - Page 10 2.1.2 Charging the batteries A socket with a minimum diameter of 6 mm is required. If you need to stop charging the batteries, disconnect directly. 2.1.3 Adding water to the water tank Before using the machine, add clean water to the clean water tank. Pay ...
- Page 11 brush and side brushes are raised. Turn the start switch to the "OFF" position. 2.3 Cautions 2.3.1 General instructions When the brushes are rolling, do leave the machine in the same place for a long time, because this would leave unnecessary marks on the ground. If you need to remove large light garbage, you can lift the front baffle so that ...
-
Page 12: Chapter 3 Regular Inspection And Replacement Of Damaged Parts
Chapter 3 Regular inspection and replacement of damaged parts 3.1 Regular inspection Time interval (h) Regular inspection items Battery power Carbon brushes of the motors Is the main brush entangled? Are there particles and/or crystals in the water tank? Buttons on the control panel and electronic components Are the brushes worn? Is the filter blocked? -
Page 13: Replacement Of The Side Brushes
3.3 Replacement of the side brushes Before replacing the side brushes, place the machine on the flat ground and make sure that it is powered-off. Use an Allen wrench to loosen the bolts of the side brushes, and press the side ... - Page 14 In order for the batteries to have a long service life, charge them immediately after using the machine; deep discharge is strictly prohibited, as it would reduce the capacity of the batteries and shorten their service life. When charging the batteries, first insert the them into the ...
-
Page 15: Chapter 4 Common Problems And Solutions
Chapter 4 Common problems and solutions Problems Causes Solutions The main fuse is blown Replace the main fuse Charge the batteries (Charge the The machine is out of batteries once a month if the machine power The batteries have no power output is not going to be used for a long time) Replace the broken batteries The chains have fallen... -
Page 16: Chapter 5 Maintenance
Chapter 5 Maintenance Regular maintenance is necessary in order for the machine to be in its best condition, as well as to extend its service life and ensure the operator’s safety. The time interval of maintenance can be changed under certain circumstances, but this must be determined by a professional technician. -
Page 17: Chapter 6 After-Sale Services
Chapter 6 After-sale services 6.1 General description Seven-day guaranteed return, fifteen-day guaranteed replacement, one-year warranty for the whole machine, 6-month warranty for damaged parts, and no warranty for consumables (calculated from the next day after receiving the machine). The delivery receipt and purchase invoice are certificates for warranty and ... -
Page 18: Warranty Card
Warranty Card 用户名 联系电话 User’s name 通讯地址 票据号 Address Bill No. 购买时间 机身编号 Date of purchase Serial number 产品型号 日期 Type of product Date 更换配件： Accessories to be replaced: 故障描述： Fault description: - 14 -... - Page 19 Anhui Chancee Technology Co., Ltd. Direction: 11 Qiaowan Road, Heifei, Anhui, China Website: www.chanceeglobal.com - 15 -...
