Summary of Contents for CHANCEE U190CAR
- Page 1 U190CAR Floor Sweeper Instruction Manual...
- Page 2 We explore safer, higher-end and more user-friendly cleaning equipment through technical advantage and idea innovation.
- Page 3 If this manual is lost, please contact us immediately and we will be glad to provide you with a new one. All technical details included in this manual are property of Anhui Chancee Technology Co., Ltd and are protected by law. In this manual we use illustrations to show the components and functions of the machine.
-
Page 4: Table Of Contents
Contents Technical parameters Chapter 1 General description 1.1 Contents and purposes 1.2 General instructions 1.3 Safety requirements for the batteries 1.4 General safety requirements Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.2 Operation process of the machine 2.3 Cautions during the operation Chapter 3 Regular inspection and replacement of damaged parts 8/10... -
Page 5: Technical Parameters
Technical parameters Category Unit Parameter Cleaning width 1,900 Main brush width Side brush width 500 * 4 Cleaning efficiency 16,800 Battery capacity V/Ah 48/100 Water tank capacity Garbage can capacity Main brush motor power Side brush motor power 80 * 4 Driving motor power 1,200 Suction motor power... -
Page 6: Chapter 1 General Description
Chapter 1 General description 1.1 Contents and purposes Potential risks concerning the use of the machine are listed in the following sections. Since most accidents take place when safety rules are ignored, it is necessary that you read them carefully and take precautions before getting started. -
Page 7: Safety Requirements For The Batteries
When a failure is produced, make sure that it is due to the lack of regular maintenance. If some spare parts need to be replaced, you can purchase them from the original manufacturer or an authorized distributor. To make sure that the machine is in the proper operating and safety condition, ... -
Page 8: Chapter 2 Operating The Machine
Chapter 2 Operating the machine 2.1 Buttons and pedals of the machine 2.1.1 Key controlling buttons of the machine Note: when the general switch is turned on, the current voltage of the machine will be displayed; if the voltage is lower than 42V, charge the batteries immediately. - Page 9 Note: The sweeping button has three gears: the front gear, the middle gear and the reset gear. The dust-vibrator button can only be used when the sweeping button is turned off. Before turning on the sprinkler button, make sure that the sprinkler valve ...
- Page 10 garbage can is correctly closed. If the machine does not work after transportation, check every part first. 2.2.2 Power display Insert the start key in the steering wheel console and turn the start switch clockwise to the "ON" position. The current voltage of the battery will be displayed in three seconds.
- Page 11 should be vibrated regularly: stop the machine, press the dust-vibrator button to start the dust-vibrator motor and keep it operating for one minute. During the work, the filter screen should be vibrated every 30 minute on average (depending on the working area) The machine cannot collect garbage when the filter screen is blocked or the ...
-
Page 12: Chapter 3 Regular Inspection And Replacement Of Damaged Parts
Chapter 3 Regular inspection and replacement of damaged parts 3.1 Adjustment and replacement of the main brush Note: The main brush is capable of sending garbage to the garbage can through its own rotation. 3.1.1 Adjusting the position of the main brush Note: Any adjustment must be realized on the flat ... -
Page 13: Adjustment And Replacement Of The Side Brushes
Step 5: adjust the position of the main brush according to 3.1.1. Step 1 Step 2 Step 3 Step 4 3.2 Adjustment and replacement of the side brushes Note: The side brushes can sweep out garbage in dead corners so that the cleaning efficiency of the machine can be boosted. -
Page 14: Replacement Of The Filter Element
3.3 Replacement of the filter element Note: The filter is used to remove dust and small particles. When dust and high-density garbage such as leaves cannot be cleaned, the filter element needs to be replaced. Step 1 Step 2 Step 3 Remove the nuts on the panel of the dust-vibrator motor and pull out the ... -
Page 15: Chapter 4 Common Problems And Solutions
Chapter 4 Common problems and solutions Problems Causes Solutions The main fuse is blown Replace the main fuse Charge the batteries (Charge the The machine is out of batteries once a month if the machine power The batteries have no power output is not going to be used for a long time) Replace the broken batteries The chains have fallen... -
Page 16: Chapter 5 Maintenance
Chapter 5 Maintenance Regular maintenance is necessary in order for the machine to be in its best condition, as well as to extend its service life and ensure the operator’s safety. The time interval of maintenance can be changed under certain circumstances, but this must be determined by a professional technician. -
Page 17: Chapter 6 After-Sale Services
Chapter 6 After-sale services 6.1 General description Seven-day guaranteed return, fifteen-day guaranteed replacement, one-year warranty for the whole machine, 6-month warranty for damaged parts, and no warranty for consumables (calculated from the next day after receiving the machine). The delivery receipt and purchase invoice are certificates for warranty and ... -
Page 18: Warranty Card
Warranty Card 用户名 联系电话 User’s name 通讯地址 票据号 Address Bill No. 购买时间 机身编号 Date of purchase Serial number 产品型号 日期 Type of product Date 更换配件： Accessories to be replaced: 故障描述： Fault description: - 14 -... - Page 19 Anhui Chancee Technology Co., Ltd. Direction: 11 Qiaowan Road, Heifei, Anhui, China Website: www.chanceeglobal.com - 15 -...
