Biostar H110M-BTC User Manual
Hide thumbs Also See for H110M-BTC:

Advertisement

Quick Links

BIOS User Guide
H110M-BTC
BIOS Update ������������������������������������������������������������������������������������� 2
UEFI BIOS Setup �������������������������������������������������������������������������������� 6
1� Main Menu ����������������������������������������������������������������������������������� 7
2� Advanced Menu ���������������������������������������������������������������������������� 8
3� Chipset Menu �������������������������������������������������������������������������������18
4� Boot Menu �����������������������������������������������������������������������������������22
5� Security Menu ������������������������������������������������������������������������������25
6� O�N�E Menu����������������������������������������������������������������������������������28
7� Exit Menu�������������������������������������������������������������������������������������35

Advertisement

Table of Contents
loading

Summary of Contents for Biostar H110M-BTC

  • Page 1: Table Of Contents

    BIOS User Guide H110M-BTC BIOS Update ������������������������������������������������������������������������������������� 2 UEFI BIOS Setup �������������������������������������������������������������������������������� 6 1� Main Menu ����������������������������������������������������������������������������������� 7 2� Advanced Menu ���������������������������������������������������������������������������� 8 3� Chipset Menu �������������������������������������������������������������������������������18 4� Boot Menu �����������������������������������������������������������������������������������22 5� Security Menu ������������������������������������������������������������������������������25 6� O�N�E Menu����������������������������������������������������������������������������������28 7� Exit Menu�������������������������������������������������������������������������������������35...
  • Page 2: Bios Update

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIOS Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 3 H110M-BTC 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system. 8. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 4 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 5 H110M-BTC 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup. After entering the BIOS setup, please go to the <Save & Exit>, using the <Restore Defaults>...
  • Page 6: Uefi Bios Setup

    UEFI BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. UEFI BIOS determines what a computer can do without accessing programs from a disk.
  • Page 7: 1� Main Menu

    H110M-BTC 1� Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information It shows system information including UEFI BIOS version, Project Code, Model Name, Build Date and etc.
  • Page 8: 2� Advanced Menu

    2� Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note   » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. ACPI Settings Enable ACPI Auto Configuration This item enables or disables BIOS ACPI auto configuration function.
  • Page 9 H110M-BTC Enable Hibernation This item enables or disables system ability to hibernate (0S/S4 sleep state). This option may not be effective with some OSs. Options: Enabled (Default) / Disabled Lock Legacy Resources The item enables or disables Lock of Legacy Resources.
  • Page 10 CPU Fan1 Calibrate Press [ENTER] to calibrate CPU Fan speed. Control Mode This item provides several operation modes of the fan. Options: Manual (Default) / Quiet / Aggressive Fan Ctrl OFF(°C) When CPU temperature is lower than this value, the CPU fan will keep lowest RPM. Options: 10 (°C) (Default) Fan Ctrl ON(°C) When CPU temperature is higher than this value, the CPU fan controller will turn on.
  • Page 11 H110M-BTC Serial Port 1 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=3F8h; IRQ=4 / IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=2F8h;...
  • Page 12 Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. Options: Disabled (Default) / 70°C/158°F / 75°C/167°F / 80°C/176°F / 85°C/185°F / 90°C/194°F AMI Graphic Output Protocol Policy Output Select This item sets Output Interface. Options: HDMI (Default) Network Stack Configuration 12 | 2.
  • Page 13 H110M-BTC Network Stack This item enables or disables UEFI network stack. Options: Disabled (Default) / Enabled Note   » The following items appear only when you set the Network Stack function to [Enabled] IPv4 PXE Support This item enables or disables IPv4 PXE Boot Support. If disabled IPv4 PEX boot option will not be created.
  • Page 14 Offboard PCIe SATA Controller USB Configuration Legacy USB Support The item allows you to enable Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Options: Enabled (Default) / Disabled / Auto XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
  • Page 15 H110M-BTC USB Mass Storage Driver Support The item allows you to enable or disable USB Mass Storage Driver Support. Options: Enabled (Default) / Disabled Port 60/64 Emulation The item allows you to enable or disable I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes.
  • Page 16 C6DRAM This item enables or disables moving of DRAM contents to PRM memory when CPU is in C6 state. Options: Disabled (Default) / Enabled SW Guard Extensions (SGX) This item enables or disables Software Guard Extensions (SGX). Options: Software Controlled (Default) / Enabled / Disabled Note  ...
  • Page 17 H110M-BTC SATA and RST Configuration The BIOS will automatically detect the presence of SATA devices. There is a sub-menu for each SATA device. Select a device and press <Enter> to enter the sub-menu for detailed options. SATA Controller(s) This item enables/disables Serial ATA Device.
  • Page 18: 3� Chipset Menu

    3� Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. Note  ...
  • Page 19 H110M-BTC Onboard LAN1 This item enables/disables Onbaord LAN1. Options: Enabled (Default) / Disabled Onboard LAN1 Option ROM This item enables/disables Onboard LAN1 Option ROM. Options: Disabled (Default) / Enabled PCH-IO Configuration PCI Express Configuration PEX1_4/ PEX1_2/ PEX1_3/ PEX1_1/ PEX1_5 Options: Auto(Default) / Gen1 / Gen2 / Gen3...
  • Page 20 HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be unconditionally enabled. Auto = HDA will be enabled if present, disabled otherwise. Options: Auto (Default) / Disabled / Enabled ErP Control When ErP is enabled, the system will meet ErP requirement.
  • Page 21 H110M-BTC DVMT Pre-Allocated This item selects DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. Options: 32M (Default) / 0M / 64M / 4M / 8M / 12M / 16M / 20M / 24M / 28M / 32M/F7 / 36M...
  • Page 22: 4� Boot Menu

    4� Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 1 (Default) Bootup NumLock State This item selects the keyboard NumLock state. Options: On (Default) / Off Full Screen Logo Display This item allows you to enable/disable Full Screen Logo Show function.
  • Page 23 H110M-BTC SATA Support Options: All Sata Devices (Default) / Last Boot HDD Only VGA Support If Auto, only install Legacy OpRom with Legacy OS and logo would NOT be shown during post. EFI driver will still be installed with EFI OS.
  • Page 24 Storage This option controls the execution of UEFI and Legacy Storage OpROM. Options: Legacy (Default) / UEFI / Do not launch Video This option controls the execution of UEFI and Legacy Video OpROM. Options: Legacy (Default) / UEFI / Do not launch Other PCI device Determines OpROM execution policy for devices other than Network, Storage, or Video.
  • Page 25: 5� Security Menu

    H110M-BTC 5� Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Menu 5. Security Menu | 25...
  • Page 26 Attempt Secure Boot Secure Boot can be enabled if 1. System running in user mode with enrolled Platform Key(PK) 2.CSM function is disabled. Options: Disabled (Default) / Enabled Secure Boot Mode Secure Boot mode selector. ‘Custom’ mode enables users to change Image Execution policy and manage Secure Boot Keys.
  • Page 27 H110M-BTC Authorized Signatures Save Key to File – Allows you save key to DB file. Set new Key – Allows you set new DB file. Append Key – Allows you append Var to DB. Erase Key – Allows you erase DB file.
  • Page 28: 6� O�N�E Menu

    6� O�N�E Menu This submenu allows you to change voltage and clock of various devices. Note   » We suggest you use the default setting. Changing the voltage and clock improperly may damage the device.   » The options and default settings might be different by RAM or CPU models.  ...
  • Page 29 H110M-BTC Memory Profile Select DIMM timing profile. The blow values start with the current running values and don’t auto populate. Options: Default profile (Default) / Custom profile Note   » The following items appear only when you set the Memory Profile function to [Custom profile] Memory Ratio Automatic or the frequency will equal ratio times reference clock.
  • Page 30 tFAW This item allows you to select Four Active Window Delay, 0: AUTO, max: 63 Options: Auto (Default) tREFI This item allows you to select Maximum tREFI time,, 0: AUTO, max: 65535 Options: Auto (Default) tRFC This item allows you to select Minimum Refresh Recovery Time, 0: AUTO, max: 1023 Options: Auto (Default) tRTP This item allows you to select Read to Precharge Delay, 0: AUTO, max: 15.
  • Page 31 H110M-BTC Advance Memory Timing Dimm ODT Training* Dimm On-Die Termination Training Options: Disabled (Default) / Enabled Read ODT Training* Read On-Die Termination Training Options: Disabled (Default) / Enabled Turn Around Timing Training Turn Around Timing Training Options: Disabled (Default) / Enabled Voltage Configuration 6.
  • Page 32 DRAM Voltage This item sets DRAM Over Voltage. Options: Auto (Default) / 1.20V / 1.35V CPU Power Management Intel(R) SpeedStep(tm) This item allows more than two frequency ranges to be supported. Options: Enabled (Default) / Disabled Power Limit 1 Override This item enables or disables Power Limit 1 override.
  • Page 33 H110M-BTC Enhanced C-states This item enables or disables C1E. When enabled, CPU will switch to minimum speed when all cores enter C-State. Options: Enabled (Default) / Disabled C-states Auto Demotion This item sets C-State Auto Demotion. Options: C1 and C3 (Default) / C1 / C3/ Disabled C-states Un-demotion This item sets C-State Un-demotion.
  • Page 34 Memory Insight DIMM Profile These items display memory information. 34 | 6. O.N.E Menu...
  • Page 35: 7� Exit Menu

    H110M-BTC 7� Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup. Save Changes and Reset Reset the system after saving the changes.
