BIOS User Guide
H110MHV3 / H110MGV3 / H110MLV3
BIOS Update ������������������������������������������������������������������������������������� 2
UEFI BIOS Setup �������������������������������������������������������������������������������� 6
1� Main Menu ����������������������������������������������������������������������������������� 7
2� Advanced Menu ���������������������������������������������������������������������������� 8
3� Chipset Menu �������������������������������������������������������������������������������17
4� Boot Menu �����������������������������������������������������������������������������������21
5� Security Menu ������������������������������������������������������������������������������24
6� O�N�E Menu����������������������������������������������������������������������������������27
7� Exit Menu�������������������������������������������������������������������������������������34

Advertisement

Table of Contents
loading

Summary of Contents for Biostar H110MGV3

  • Page 1: Table Of Contents

    BIOS User Guide H110MHV3 / H110MGV3 / H110MLV3 BIOS Update ������������������������������������������������������������������������������������� 2 UEFI BIOS Setup �������������������������������������������������������������������������������� 6 1� Main Menu ����������������������������������������������������������������������������������� 7 2� Advanced Menu ���������������������������������������������������������������������������� 8 3� Chipset Menu �������������������������������������������������������������������������������17 4� Boot Menu �����������������������������������������������������������������������������������21 5� Security Menu ������������������������������������������������������������������������������24 6� O�N�E Menu����������������������������������������������������������������������������������27...
  • Page 2: Bios Update

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIOS Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 3 H110MHV3 / H110MGV3 / H110MLV3 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system. 8. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 4 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 5 H110MHV3 / H110MGV3 / H110MLV3 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 6: Uefi Bios Setup

    UEFI BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. UEFI BIOS determines what a computer can do without accessing programs from a disk.
  • Page 7: 1� Main Menu

    H110MHV3 / H110MGV3 / H110MLV3 1� Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information It shows system information including UEFI BIOS version, Project Code, Model Name, Build Date and etc.
  • Page 8: 2� Advanced Menu

    2� Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note   » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. Trusted Computing TPM Device Selection This item selects TPM device: PTT or TPM.
  • Page 9 H110MHV3 / H110MGV3 / H110MLV3 Security Devices Support This item enables or disables BIOS ACPI auto configuration function. Options: Enabled (Default) / Disabled ACPI Settings Enable ACPI Auto Configuration This item enables or disables BIOS ACPI auto configuration function. Options: Disabled (Default) / Enabled Enable Hibernation This item enables or disables system ability to hibernate (0S/S4 sleep state).
  • Page 10 Wake up hour / Wake up minute / Wake up second You can choose the system boot up time, input hour, minute and second to specify. SMART FAN Control CPU Smart Fan1 This item allows you to control the CPU Smart Fan function. Options: Disabled (Default) / Auto Note  ...
  • Page 11 H110MHV3 / H110MGV3 / H110MLV3 H/W Monitor Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. Options: Disabled (Default) / 70°C/158°F / 75°C/167°F / 80°C/176°F / 85°C/185°F / 90°C/194°F CPU Configuration This item shows CPU Information...
  • Page 12 Active Processor Cores This item sets number of cores to enable in each processor package. Options: All (Default) / 1 / 2 / 3 Overclocking lock This item sets Overclocking lock. Options: Disabled (Default) / Enabled Intel Virtualization Technology Virtualization Technology can virtually separate your system resource into several parts, thus enhance the performance when running virtual machines or multi interface systems.
  • Page 13 H110MHV3 / H110MGV3 / H110MLV3 SATA Controller(s) This item enables/disables Serial ATA Device. Options: Enabled (Default) / Disabled SMART Self Test This item runs SMART Self Test on all HDDs during POST. Options: Disabled (Default) / Enabled Network Stack Network Stack...
  • Page 14 NVMe Configuration The item shows NVMe controller and driver information. Offboard PCIe SATA Controller 14 | 2. Advanced Menu...
  • Page 15 H110MHV3 / H110MGV3 / H110MLV3 USB Configuration Legacy USB Support The item allows you to enable Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.
  • Page 16 Note   » The following items appear only when you set the Device power-up delay function to [Manual]. Device power-up delay in seconds Delay range is 1 ~ 40 seconds, in one second increments. Options: 5 (Default) 16 | 2. Advanced Menu...
  • Page 17: 3� Chipset Menu

    H110MHV3 / H110MGV3 / H110MLV3 3� Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 18 PCI Express Configuration PEX1_1 Options: Auto(Default) / Gen1 / Gen2 / Gen3 HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be enabled. Options: Auto (Default) / Disabled / Enabled EuP Control When EuP is enabled, the system will meet EuP requirement.
  • Page 19 H110MHV3 / H110MGV3 / H110MLV3 VT-d This item enables or disables VT-d capability. Options: Enabled (Default) / Disabled Max TOLUD Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Options: Dynamic (Default) / 1 GB / 1.25 GB / 1.5 GB / 1.75 GB / 2 GB / 2.25 GB / 2.5 GB / 2.75 GB / 3 GB / 3.25 GB / 3.5GB...
  • Page 20 Onboard Device Onboard LAN1 This item enables/disables Onbaord LAN1. Options: Enabled (Default) / Disabled Onboard LAN1 Option ROM This item enables/disables Onboard LAN1 Option ROM. Options: Disabled (Default) / Enabled 20 | 3. Chipset Menu...
  • Page 21: 4� Boot Menu

    H110MHV3 / H110MGV3 / H110MLV3 4� Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 1 (Default) Bootup NumLock State This item selects the keyboard NumLock state.
  • Page 22 SATA Support Options: All Sata Devices (Default) / Last Boot HDD Only VGA Support If Auto, only install Legacy OpRom with Legacy OS and logo would NOT be shown during post. EFI driver will still installed with EFI. Options: EFI Driver (Default) / Auto USB Support If Disabled, all USB devices will NOT be available until after OS boot.
  • Page 23 H110MHV3 / H110MGV3 / H110MLV3 Video This option controls the execution of UEFI and Legacy Video OpROM Options: Legacy (Default) / UEFI / Do not launch Other PCI device For PCI devices other than Network, Mass storage or video defines which OpROM to launch.
  • Page 24: 5� Security Menu

    5� Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Menu 24 | 5. Security Menu...
  • Page 25 H110MHV3 / H110MGV3 / H110MLV3 Secure Boot Secure Boot can be enabled if 1. System running in user mode with enrolled Platform Key(PK) 2.CSM function is disabled. Options: Disabled (Default) / Enabled Secure Boot Mode Secure Boot mode selector. ‘Custom’ mode enables users to change Image Execution policy and manage Secure Boot Keys.
  • Page 26 Forbidden Signature Delete Key – Allows you to delete the DBX file from your system. Set new Key – Allows you set new DBK file. Append Key – Allows you append Var to DBX. Authorized Timestamps Set new Key – Allows you set new DBT file. Append Key –...
  • Page 27: 6� O�N�E Menu

    H110MHV3 / H110MGV3 / H110MLV3 6� O�N�E Menu This submenu allows you to change voltage and clock of various devices. Note   » We suggest you use the default setting. Changing the voltage and clock improperly may damage the device.
  • Page 28 Note   » The following items appear only when you set the Memory Profiles function to [Manual] Memory Reference Clock This sets the memory reference clock in Automatic, 133MHZ or 100MHZ. Options: Auto (Default) / 133 / 100 Memory Ratio Automatic or the frequency will equal ratio times reference clock.
  • Page 29 H110MHV3 / H110MGV3 / H110MLV3 tCWL This item allows you to select Minimum CAS Write Latency Range, 0: AUTO, max: 20 Options: Auto (Default) tFAW This item allows you to select Four Active Window Delay, 0: AUTO, max: 63 Options: Auto (Default)
  • Page 30 Voltage Configuration DRAM Voltage This item sets DRAM Over Voltage. Options: Auto (Default) / 1.35V / 1.42V CPU Power Management Intel(R) SpeedStep(tm) This item enables/disables Enhanced Intel SpeedStep Technology. Options: Enabled (Default) / Disabled Turbo Mode This item enables/disables CPU Turbo Mode. Options: Enabled (Default) / Disabled 30 | 6.
  • Page 31 H110MHV3 / H110MGV3 / H110MLV3 Package Power Limit MSR Lock This item enables or disables locking of Package Power Limit settings. When enabled, PACKAGE_ POWER_LIMIT MSR will be locked and a reset will be required to unlock the register. Options: Disabled (Default) / Enabled Power Limit 1 Override This item enables or disables Power Limit 1 Override.
  • Page 32 This item enables or disables Reliability Stress Restrictor (RSR) feature. Options: Enabled (Default) / Disabled AC Loadline AC Loadline defined in 1/100 m0hms. A value of 100=1.00 m0hm, and 1255 =12.55 m0hm. Range is 0-6249 (0-62.49 m0hms). 0=AUTO/HW default. Options: Auto (Default) DC Loadline DC Loadline defined in 1/100 m0hms.
  • Page 33 H110MHV3 / H110MGV3 / H110MLV3 DIMM Profile These items display memory information. 6. O.N.E Menu | 33...
  • Page 34: 7� Exit Menu

    7� Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup. Save Changes and Reset Reset the system after saving the changes.
