Summary of Contents for V-ZUG VacuDrawer V6000
- Page 1 Operating instructions VacuDrawer V6000 Vacuum drawers...
- Page 2 Validity These operating instructions apply to: Model designation Type Size system VacuDrawer V6000 14 DV6T-36004 60-144 VacuDrawer V6000 14 DV6T-36005 60-144 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2021...
-
Page 3: Table Of Contents
Contents 2 Trouble-shooting 21 What to do if … ............ 21 Safety precautions 4 Accessories and spare parts 24 Symbols used............ 4 General safety precautions........ 4 Technical data 25 Appliance-specific safety precautions .... 5 Tips and tricks 25 Before using for the first time...... 5 Disposal 26 General appliance description... -
Page 4: Safety Precautions
Safety precautions Symbols used provided they are supervised or have been instructed on Unauthorized repairs could result in unforeseen dangers for the user, for the safe use of the appliance which the manufacturer cannot ac- and have understood the haz- cept liability. -
Page 5: Appliance-Specific Safety Precautions
1 Safety precautions Appliance-specific safety Before using for the first precautions time ▪ The appliance must be installed and The sealing bar gets hot during use. connected to the electricity supply in Care should be taken. Avoid touch- accordance with the separate installa- ing the sealing bar. - Page 6 1 Safety precautions ▪ The appliance corresponds to recog- Caution: Burns hazard nized technology standards and the rel- ▪ The sealing bar on the appliance gets evant safety regulations. Proper use of very hot. The sealing seam of the va- the appliance is essential to avoid dam- cuum bag also heats up strongly during age and accidents.
-
Page 7: General Appliance Description
General appliance description Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▪ Remove packaging and transport materials from out of the vacuum tank. ▪ Remove the operating instructions, bags and any unneeded accessories. Construction 13 12 Drawer front (push-and-pull... -
Page 8: Operating And Display Elements
2 General appliance description Operating and display elements Display Buttons A Vacuuming level On/Off B Sealing time Vacuuming level C Vacuuming level – external vacuuming Sealing time External vacuuming Start Stop Dehumidifying Maintenance Explanation of the displays Inactive (no displays, dark) Preselection (number of selected levels, illuminated) Process running... -
Page 9: Opening And Closing The Drawer
3 Opening and closing the drawer Opening and closing the drawer Opening Closing ▸ Push in the middle of the drawer front. ▸ Close in the middle of the drawer front. – The drawer opens. – The drawer engages and closes. Never force the drawer open as this could damage the closing mechanism (push/pull system). -
Page 10: Operating The Appliance
4 Operating the appliance Operating the appliance Switching on ▸ Touch the button. – The appliance is ready for opera- tion. ▸ Open the appliance lid. Inserting bag ▸ Put the food into the vacuum bag. ▸ Push the opening of the bag under the bag clip 1. -
Page 11: Food Handling
5 Food handling Switching the appliance off ▸ Touch the button. – The appliance switches off. Sealing sooner The vacuuming process can be interrupted and the bag sealed sooner. ▸ Touch the sealing time button. Liquids already start to boil at low temperatures when under a vacuum. This pro- duces steam, which can cause the appliance to malfunction. -
Page 12: Storage
Vacuum sealing food is not the same as preserving it! Vacuisine © Vacuum-sealed food can be prepared using the sous-vide method of cooking. At V-ZUG, we call this method Vacuisine ©. Only use original V-ZUG vacuum bags for the Vacuisine method. -
Page 13: Vacuum Sealing Food
Overpressure can otherwise develop and cause the va- cuum bag to burst. If bags other than V-ZUG vacuum bags are used for sous-vide cooking, these could be- come soft, the sealing seam may not hold or may melt. Only use other bags for vacuum sealing and adjust the sealing time to the material of the bag. -
Page 14: Recommended Vacuuming Levels
6 Vacuum sealing food Recommended vacuuming levels Selecting the vacuuming level The following vacuuming levels are available for selection (after portioning) for pack- aging, marinating, sous-vide cooking (Vacuisine ©), freezing or storing: Vacuuming level Food category with examples Tips and uses with display ▪... -
Page 15: Selecting The Level For Sealing Time
Selecting the level for sealing time If using original V-ZUG vacuum bags, set the sealing time to level 2. If using non-original bags, the sealing time must be adjusted to the material of the bag. Using non-original bags may damage the sealing bar. The use of such bags is at the owner's own risk. -
Page 16: Vacuuming Only
7 Overview of applications Vacuuming only Jars with screw-top lids, containing e.g. nuts or kernels, can be vacuumed and sealed airtight at the same time using this application. Only use jars with intact screw-top lids. Check that the jars are not too tall before closing the appliance lid. -
Page 17: Care And Maintenance
8 Care and maintenance Place the bottle for external evacuating on a flat and stable surface near the va- cuum drawer. ▸ Touch the button once or more to select a suitable vacuuming level. See «Recom- mended vacuuming levels (see page 14)». Vacuum seal large quantities of liquid in solid containers with an appropriate volume. -
Page 18: Cleaning
8 Care and maintenance Cleaning Outside ▸ Remove any soiling or excess cleaning agent immediately. ▸ Clean the surfaces with a soft cloth dampened with water and a little washing-up liquid – for metallic surfaces rub in the direction of the original polish lines. ▸... -
Page 19: Replacing The Sealing Bar
8 Care and maintenance Replacing the sealing bar ▸ Remove the damaged sealing bar 1 together with the sealing bar cover 2 from the appliance. ▸ Put the sealing bar cover 2 back in place in the appliance. ▸ Position the new sealing bar 1 on the two locating pins in the appliance. -
Page 20: System Check
8 Care and maintenance System check If the maintenance button illuminates, the vacuum pump cannot achieve the re- quired underpressure in the allotted time. The appliance lid may not be closed properly or the appliance lid gasket may be dirty or damaged. ▸... -
Page 21: Trouble-Shooting
9 Trouble-shooting Trouble-shooting What to do if … This section lists faults that can be solved simply by following the instructions given. If another fault is displayed or the fault cannot be remedied, please call Customer Ser- vices. … the appliance is not working Possible cause Solution ▪... - Page 22 9 Trouble-shooting … the vacuum bag is incorrectly sealed Possible cause Solution ▪ The sealing time set was in- ▸ Select the next highest sealing time level. sufficient for the vacuuming level selected. ▪ The vacuum bag is not posi- ▸...
- Page 23 9 Trouble-shooting … the liquid in the vacuum bag is boiling vigorously while being vacuumed Possible cause Solution ▪ Liquids already start to boil ▸ Sealing sooner. at low temperatures when ▸ Select vacuuming level 1 for vacuum sealing liquid under vacuum.
- Page 24 10 Accessories and spare parts Accessories and spare parts Please give model number of the appliance and exact designation of the accessory or spare part when ordering parts. ▪ Bag tray: For vacuum sealing flat foodstuffs ▪ Appliance lid gasket ▪...
- Page 25 11 Technical data Technical data Type DV6T-36004/36005 Appliance measurements External dimensions (height × width × depth) 142 × 596 × 547 mm Capacity of vacuum tank (height × width × depth) 95 × 350 × 285 mm Volume of vacuum tank 7.83 dm³...
- Page 26 13 Disposal Disposal 13.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 13.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
- Page 27 Index Accessories ............24 Preparations Appliance disposal .......... 26 Special types of food ........ 11 Applications ............15 Quality and hygiene......... 11 Before using for the first time ......5 Recommended vacuuming levels ....14 Cleaning............. 18 Replacing appliance lid gasket..... 19 Accessories ..........
- Page 28 Notes...
- Page 31 V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.
- Page 32 Quick instructions Open appliance Switch appliance on Operate vacuuming level Operate level for sealing time Vacuuming Switch appliance off and close 1081233-01 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
