Summary of Contents for Knightsbridge OLG1P
- Page 1 INSTALLATION & MAINTENANCE MANUAL OLG1P...
- Page 2 These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: OLG1P SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: OLG1P SAFETY INSTALLATION This product must be installed in accordance with the latest edition of the IEE Wiring Regulations •...
- Page 4 • Remove the baseplate from the luminaire by loosening the screws on the sides Remove the baseplate from the luminaire by loosening the screws on the sides • • When the concrete is set, fix the baseplate to the threaded rods using the spring washers •...
- Page 5 If fixing onto solid surface: using the baseplate as a template, mark the location for, and drill the • fixing holes ensuring not to infringe with any gas/water pipes or electrical cables. Fix the baseplate using suitable fixings (not provided) •...
- Page 6 WARNING This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed. GENERAL Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not use aggressive cleaning products or solvents which may damage the product.
- Page 7 AVMAY21_V1...
