Assembly

Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specified sequence. The
final positions of the components are shown in the illustration below.
1 Drum module
2 Hi-hat pad with pedal (13 inch)
3 Crash pad (15 inch, dual zone, with choke function)
4 Tom pad (10 inch, dual zone, mesh head)
5 Tom pad (12 inch, dual zone, mesh head)
6 Ride pad (18 inch, triple zone, with choke function)
7 Snare pad (13 inch, dual zone, mesh head)
8 Bass drum pad (18 inch) with bass drum pedal
9 Ground tom pad (14 inch, dual zone, mesh head)
