- Page 1 GT06 High Precision Vehicle GPS Tracker Based on 4G/GSM communication technology & GPS high-precision satellite positioning technology Manual Rev.: 1.0 Revision Date: Mar.18, 2023...
- Page 2 Updated Version Instruction Edition Revision Date Version Described V1.0 2023/03/18 Document built...
-
Page 3: Table Of Contents
Table Of Contents 1.Introduction ..............4 2.SMS Command Description ......... 10 3.Platform & APP ..............14 4.Installation ..............15 5.Trouble shooting ............17 6.Appendix（Test Report） ..........17... -
Page 4: Introduction
1.Introduction 1.1 Product Introduction Product: GT06 4G/GSM high precision vehicle GPS tracker This product is based on 2G/4G network and GPS satellite, it realizes positioning and monitoring of any remote target through SMS, application and Internet. Adopt the most advanced GPS and AGPS dual positioning technology. - Page 5 GPS continuous positioning, GPRS regular ◆ reporting (1 report in 10 seconds by default); Support SMS and platform to query ◆ location information; Built-in vibration sensor to realize ◆ vehicle intelligent anti-theft; ACC ignition signal detection and ◆ vehicle status display; Remote control vehicle by Relay;...
- Page 6 Ultra-wide voltage input range: DC ◆ 10V～40V; GPS continuous positioning, GPRS regular ◆ reporting (1 report in 10 seconds by default); Support SMS and platform to query ◆ location information; Built-in vibration sensor to realize ◆ vehicle intelligent anti-theft; ACC ignition signal detection and ◆...
- Page 7 Characteristics Work 10~40V Voltage ● Range Work 12V/30mA ● Current 80mA Sleep 12V/5mA ● Current 15mA 3.7V/180mAH Battery ● lithium Battery Capacity Work Temperatu ● -30℃~+80℃ re Range Storage Temperatu ● -40℃~+85℃ Environmental re Range Characteristics Operating Humidity ● 5%-95% Range Communica Simcom/A7670S...
- Page 8 SIM CARD ● BIG SIM CARD Communica tion ● Built-in design Antenna Positioning ● GPS/AGPS/LBS Type Cold Start Cold Start: <30S ● Time: (Open Sky) Warm Start Warm Start: ● Time: <10S (Open Sky) Start Hot Start: <2S ● Time: (Open Sky) Position...
- Page 9 1.4 Indicator Definition GPS LED Indicator (Blue LED) Flashing Searching GPS signal Continuously bright GPS fixed Continuously dark No GPS fix or initializing Continuously bright Come in sleeping to dark Communication LED Indicator (Green LED) Searching communication Flashing signal Continuously bright Communication signal ok No communication signal or Continuously dark...
-
Page 10: Sms Command Description
wire connection method: Figure 3 wiring diagram 2.SMS Command Description All the commands are SMS command; no case-sensitive; space between parameters. 1)APN Setting Parameter Sample Command APN123456 1: apn123456 internet APN123456 2: apn123456 Setting APN APNNAME java.claro.com.br APNPASSWORD claro claro 1)Please get APN from the sim card Command mobile operator in the tracker;... - Page 11 2)Server Setting Parameter Sample Command adminip123456 adminip123456 45.112.205.99 Server ip port 7018 Setting adminip123456 domain port adminip123456 www.19gps.net 7018 Server setting is done in factory, Command normally after APN setting, the Description tracker will be online. Command Successful Setting: set ip port ok! Feedback 3)Heartbeat Packet Upload Time Setting Parameter...
- Page 12 Command 1)Default 10 Seconds; Description 2)30 mean 30seconds. Command Successful Setting: fix 30S ok! Feedback 5)Static Upload Time Setting Parameter Sample Command Static sup123456 5 sup123456 5 Upload Time Setting 1)The default: GPS closed, only upload heartbeat packet to save power; 2)If needed to send this command to Command upload GPS data in static;...
- Page 13 SMS Command Parameter Sample Inflection angle123456 angle123456 20 Points Supplementary 1)Default: 22degrees; 2) Scope:18~28 degrees; 3)20 mean: when >20 degrees, the Command tracker auto add points GPS data Description to upload; 4)SMS command: noangle123456 to cancel inflection points supplementary upload. Command Successful Setting: 1)angle ok! Feedback...
- Page 14 Tracking tracker123456 tracker123456 1)Monitor mode: tracker auto answer Command calling; Description 2)Tracker mode: tracker return Google link message after calling. Command Successful Setting: 1)monitor ok! Feedback 2)tracker ok! 10)SMS Position query Parameter Sample Command smslink123456 Smslink123456 Position query 1)Tracker mode: tracker return Google link message after calling;...
- Page 15 the password will be back to 123456. Command Successful Setting: password ok! Feedback 12)Admin Numbers Setting Parameter Sample Command Admin Admin123456 Admin123456 Numbers 00861380013800 00861380013800 Setting 1)Country code needed; Command 2)Maximum:5 numbers; Descriptio 3)Other numbers set or deleted by the first number.
- Page 16 14)Wire-Cut Alarm Parameter Sample Command Enable extpower123456 extpower123456 Wire-Cut Alarm Disable extpower123456 extpower123456 Wire-Cut Alarm 1)Default: the alarm disabled; 2)Alarm enabled: the tracker will send Command alarm message to admin numbers and Description alarm data to platform when external power cut. Command Successful Setting:1) extpower on ok! Feedback...
- Page 17 Enable shock123456 shock123456 Shock Alarm Disable noshock123456 noshock123456 Shock Alarm 1)Default: the alarm disabled; 2)Alarm effective time: 5 minutes; Command 3)When Alarm triggered, the tracker Description will send alarm message to admin numbers and alarm data to platform. Command Successful Setting:1) shock ok! Feedback 2) noshock ok! 17)Time Zone...
- Page 18 state, all alarms enabled, when door opened, the tracker will send Door alarm to admin number and platform. Command Successful Setting:1) arm ok! Feedback 2) disarm ok! 19)Status Check Parameter Sample Command Status check123456 check123456 Check The tracker will return communication signal strength, GPRS Command status, GPS status, external power...
- Page 19 Command The tracker will return IMEI numbers, Description sim card ICCID. Command IMEI numbers and sim card ICCID. Feedback 22)Mileage Check Parameter Sample Command Mileage mileage123456 mileage123456 Check Command The tracker will return total mileage Description and current mileage information. Command Total mileage and current mileage Feedback...
-
Page 20: Platform & App
Parameter Sample Command Factory superformat12345 superformat12345 Reset Command Descriptio All setting return to factory status. Command Successful Setting: superformat ok! Feedback 3.Platform & APP 3.1 Platform: Website: http://www.19gps.net Login as IMEI IMEI is in the label on the tracker, it is 15bits numbers. Enter IMEI Password:123456 3.2 APP:... -
Page 21: Installation
4.1.2 This product is a high-tech electronic device, installation should be undertaken by a professional. 4.1.3 Please follow the following procedures to install your tracker, during installation, there should be no power to the device. 4.1.4 Installing sim card: The device is need to insert a sim card which support 4G or GSM 2G network. - Page 22 There are two kinds of installation: covert and non covert. 4.3.1 If you need the covert installation, please refer installation to an auto electrical contractor. Note: To prevent theft of the tracker, please install it as covertly as possible. Avoid placing the tracker close to higher power electrical devices, such as reversing radar, anti-theft device or other vehicle communication equipment.
-
Page 23: Trouble Shooting
consulting the professional. 4.3.2Non Covert Installation The first please fix the device on the dash board below windshield. - In the parcel shelf in the rear; - In the front bumper (non-material face), please ensure the device cannot get wet; - Under the wiper version (non-metal), please ensure the device cannot get wet. -
Page 24: Appendix（Test Report
position. GPS signal only can be received out of the room and face to sky. 5.1.2 Please check the offline area in order to judge if the network problem of operators. 5.2 When GPS unfixed, please drive in the open sky and ensure there is no metal thins on the device. - Page 25 Figure 8 trajectory of viaduct road 6.4 Urban Canyon Road Test Tall buildings stand on both sides of the road, which can verify the impact of urban canyon on equipment accuracy. Figure 9 trajectory of urban canyon road...
