3.3 Electrical connection
Install the hob with a socket supply line. If
there is no socket supply line, the fixed home
electrical system must include an isolating
device with at least a 3 mm-contact
separation to enable a simultaneous and all-
pole cut off from the mains (according to NIN
SEV 1000).
3.4 Attaching the seal
On-top installation
1. Clean the worktop around the cut out
area.
2. Attach the supplied 2x6 mm seal stripe to
the lower edge of the hob, along the outer
edge of the glass ceramic. Do not stretch
it. Make sure that the ends of the seal
stripe are located in the middle of one
side of the hob.
3. Add some millimetres to the length when
you cut the seal stripe.
4. Join the two ends of the seal stripe
together.
Integrated installation
1. Clean the rabbets in the worktop.
2. Cut the supplied 3x10 mm seal stripe into
four stripes. The stripes must have the
same length as the rabbets.
3. Cut the ends of the stripes at an angle of
45°. They should fit in the corners of the
rabbets accurately.
4. Attach the stripes to the rabbets. Do not
stretch the stripes. Do not bond the ends
of the stripes one over the other.
After you assemble the hob, seal the
remaining gap between the glass ceramic
and the worktop with silicone. Make sure the
silicone does not get under the glass ceramic.
3.5 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
min.
500mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
ON-TOP INSTALLATION
290
min. 50
min.
50mm
510
60 30
51
490
270
min. 1500
min. min.
12 28
