安科瑞电气股份有限公司
322
ATE 系列无线测温传感器
ATE series Wireless Temperature Sensor
安装说明 V2.2
Installation Instruction V2.2
安科瑞电气股份有限公司
Acrel Co., Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Acrel ATE Series

  • Page 1 安科瑞电气股份有限公司 ATE 系列无线测温传感器 ATE series Wireless Temperature Sensor 安装说明 V2.2 Installation Instruction V2.2 安科瑞电气股份有限公司 Acrel Co., Ltd.
  • Page 2 安科瑞电气股份有限公司 申 明 DECLARATION 版权所有,未经本公司之书面许可,此手册中任何段落,章节内容均不得被摘抄、拷贝或以任何形式复 制、传播,否则一切后果由违者自负。 本公司保留一切法律权利。 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form by any means, electronic, mechanical photocopying, recording, or otherwise without prior permission of our company.
  • Page 3 安科瑞电气股份有限公司 目 录 Contents ATE 系列无线测温传感器 ..........................1 ATE series Wireless Temperature Sensor ......................1 安科瑞电气股份有限公司 ..........................1 1 安装指南 ..............................1 1 Installation Guide ............................1 1.1 产品概述 ............................1 1.1 Product Introduction ...........................1 1.2 型号说明 ............................1 1.2 Type Introduction ..........................1 1.3 技术指标...
  • Page 4 3~35kV 户内开关柜,包括中置柜、手车柜、固定柜、环网柜等多种开关柜;也可用于 0.4kV 低压 柜,包括固定柜,抽屉柜等。无线测温传感器可安装于柜内任何发热点上,利用无线数据传输技术 实时发送监测数据,再通过接收装置将温度数据传输到显示装置或者远程监控系统。 ATE series wireless temperature measuring sensor has been developed in compliance with Specification for Wireless Temperature Measuring equipment, NB/T 42086-2016. It is suitable for 3-35kV indoor switchgears, including built-in switchgears, handcart switchgears, fixed switchgears and loop-net switchgears.
  • Page 5 安科瑞电气股份有限公司 1.3 技术指标 1.3 Technical Features 项目 指标 Items Features 工作温度 -40℃~85℃ Temperature 环境要求 相对湿度 ≤95% Environment Humidity 大气压力 86kPa~106kPa atmospheric pressure 无线频率 470MHz、433Mhz Wireless frequency 空旷 150m(470Mhz)、空旷 50m(433Mhz) 通讯距离 Communication distance 150m(470Mhz) 、50m(433Mhz)in open area 采样频率 Sampling frequency 发射频率 25s-5min ATE100M/100/200 Transmitting frequency...
  • Page 6 安科瑞电气股份有限公司 安装方式 合金片固定 Installation alloy chip fixing 传感器探头 合金底座 Sensor probe alloy bottom 测温范围 -50℃~125℃ Range of temperature 精度 ±1℃ Precision 应用范围 高低压柜内电气接头 Application Joints in high or low voltage switchgears 无线频率 470MHz、433Mhz Wireless frequency 空旷 150m(470Mhz)、空旷 50m(433Mhz) 通讯距离 Communication distance 150m(470Mhz) 、50m(433Mhz)in open area 采样频率...
  • Page 7 安科瑞电气股份有限公司 精度 ±1℃ Precision 应用范围 低压抽屉柜内电气接头 Application Joints in low voltage switchgears 1.4 产品安装 1.4 Product Installation 无线温度传感器共有多种型号,分别对应磁吸固定、螺栓固定、表带固定、合金片固定等安装 方式。 There are several types of wireless temperature sensors and mounting methods correspondingly, i.e. , bolted , belt and alloy chip fixing. Magnetic 1.4.1 外形尺寸...
  • Page 8 安科瑞电气股份有限公司 ATE200/ATE200P ATE400 ATE300M...
  • Page 9 安科瑞电气股份有限公司 1.4.2 标签说明 1.4.2 Label Instructions 1.4.2.1 ATE 传感器搭配 ASD/ARTM-Pn 装置 1.4.2.1 ATE sensor with ASD/ARTM-Pn device ASD/ARTM-Pn ATE400 ATE200 ATE100M ATE100 ATE100P ATE200P 如 果 安 装 ATE100M/ATE100/ATE200/ATE400/ATE100P/ATE200P , 其 组 号 应 与 显 示 装 置 ASD/ARTM-Pn 的标签组号一致,安装位置依照标签文字安装,“编码:1A”为安装第一个 A 相, “编码:1B”为安装第一个...
  • Page 10 安科瑞电气股份有限公司 ATC600-C ATC450-C ATE400 ATE200 ATE100M ATE100 ATE100P ATE200P 如 图 所 示 , 如 果 安 装 ATE100M/ATE100/ATE200/ATE400/ATE100P/ATE200P , 其 组 号 应 与 ATC450-C/ATC600-C 的组号一致,安装位置依照标签文字安装,“编码:001”建议安装在第一个 柜子的第一个测温点,再依次按照测温点顺序安装。 According to the above pictures, If the sensor is ATE100M/100/200/400/100P/200P, the group number of ATE must be same as the group number of ATC450-C/ATC600-C and the installation order is base on the label.
  • Page 11 安科瑞电气股份有限公司 In case of any special situation, please contact the relevant engineers for communication. 1.4.3 安装方法 1.4.3 Installation Method 1.4.3.1 ATE100M 安装方法 1.4.3.1 ATE100M Installation Method ATE100M 磁吸式无线测温传感器适用于铁质的电气节点或设备表面。 The magnetic wireless sensor ATE100M is suitable for iron electrical nodes or equipment surfaces. 磁吸式无线温度传感器...
  • Page 12 安科瑞电气股份有限公司 拆下安装位置搭接处的螺丝,将传感器固定在安装位置,对准合金底板的开孔,然后旋紧螺丝 固定,安装前打开电池开关,电源指示灯闪烁两次。安装实例见下图: Remove the screw from the joints, and fixing the sensor on the position with the hole on the alloy baseplate, then tighten the screw, open the battery switch before installation, the power indicator flashes twice. The installation examples see images below. 1.4.3.3 ATE200 安装方法...
  • Page 13 安科瑞电气股份有限公司 将传感器主体固定在安装位置,将表带绕过安装母排或者触头穿过表带,表带头收紧,最后将 表带尾用锁扣锁紧。表带过长可以剪掉多余部分,表带过短可以联系我司增订。安装前打开电池开 关,电源指示灯闪烁两次。安装实例见下图: 注:ATE200 可安装静触头,铜排,电缆头。 Fixing the body of sensor on the position, then strapping it on the bus bar or breaker contact and frapping it through the hole on the strap, fixing the strap by hasp. Clipping the strap if it is too long when finished, if it is too short, contacting us for strap parts before installation.
  • Page 14 安科瑞电气股份有限公司 取 2 根合金片穿过锁紧件安装孔,将合金片居中对折后锁紧件固定在折弯处;将对折后的 4 层 合金片分别穿过硅胶垫片-传感器主体-硅胶垫片;将整体传感器环绕安装部位一圈后拉紧合金片并 旋紧螺丝;合金片多余部分留取适当长度并折叠压紧。合金片安装示意过程如下: 注:ATE400 可安装静触头,铜排,电缆头; 如需安装动触头,需要考虑梅花头及套筒高度是否 足够。 Firstly, take 2 pieces of alloy chips through the mounting hole of metal hasp, meanwhile fold the alloy chips and fix the metal hasp in the middle of alloy chips. Secondly, take the folded alloy chips through one silicone gasket, the core of ATE400 and another silicone gasket in turn.Thirdly, circle the whole alloy chips around the mounting position and tension the alloy chips, then tighten the screw on the metal hasp.
  • Page 15 安科瑞电气股份有限公司 ATE400 无线温度传感器安装实例如下: The wireless temperature sensor called ATE400 installation examples, see images below. 1.4.3.5 ATE300M 安装方法 1.4.3.5 ATE300M Installation Method ATE300M 多回路式温度传感器适用于低压柜内电气接头等多种场合。 Ate300M multi circuit temperature sensor is applicable to various occasions such as electrical connectors in low-voltage cabinet. 将传感器主体在柜内合适位置通过导轨或者扎带捆绑的方式固定好,拆下安装位置搭接处的螺...
