- Page 1 安科瑞电气股份有限公司 ATE series Wireless Temperature Sensor Installation Instruction V1.7 Acrel Co., Ltd.
-
Page 2: Product Introduction
1 Installation Guide 1.1 Product Introduction ATE series wireless temperature measuring sensor has been developed in compliance with Specification for Wireless Temperature Measuring equipment, NB/T 42086-2016. It is suitable for 3-35kV indoor switchgears, including built-in switchgears, handcart switchgears, fixed switchgears and loop-net switchgears. -
Page 3: Product Installation
安科瑞电气股份有限公司 Power source Battery Magnetic / bolted /Belt Installation Range of temperature -50 ℃ ~+125 ℃ Precision ± 1 ℃ Application Joints in high or low voltage switchgears Battery life ≥ 5 years Wireless frequency 470MHz Communication distance 150m in open area Sampling frequency Transmission frequency 400 Passive... - Page 4 安科瑞电气股份有限公司 ATE100M ATE100/ATE100P ATE200/ATE200P ATE400 1.4.2 Label Instructions 1.4.2.1 ATE sensor with ASD/ARTM-Pn device...
- Page 5 安科瑞电气股份有限公司 ASD320 ARTM-Pn ATE400 ATE200 ATE100M ATE100 ATE100P ATE200P If the sensor is ATE100M/ATE100/ATE200/ATE400/ATE100P/ATE200P, the number behind “ 组号： ” should be same as number underlined in “*51809190240001*”, the sequence of installation is base on the label, “ 编码： 1A” is first one on the phase A, “ 编码： 1B” is first one on the phase B ， and so on. Notice: wireless temperature sensors and display device in the package have been matched before delivery.
- Page 6 安科瑞电气股份有限公司 ATE400 ATE200 ATE100M ATE100 ATE100P ATE200P According to the above pictures, If the sensor is ATE100M/100/200/400/100P/200P, the group number of ATE must be same with the group number of ATC450-C/ATC600 and the installation order is base on the label. The code of each sensor is used to distingguish each sensor from same group. “ code: 001 ”...
- Page 7 安科瑞电气股份有限公司 joints between cable and disconnector. ATE100 structure introduction: 1 —— The core of wireless temperature sensor ATE100 2 —— Thermo-sensitive part 3 —— battery switch Remove the screw from the joints, and fixing the sensor on the position with the hole on the alloy baseplate, then tighten the screw, open the battery switch before installation, the power indicator flashes twice.
- Page 8 安科瑞电气股份有限公司 Fixing the body of sensor on the position, then strapping it on the bus bar or breaker contact and frapping it through the hole on the strap, fixing the strap by hasp. Clipping the strap if it is too long when finished, if it is too short, contacting us for strap parts before installation.
- Page 9 The complete installation process is shown in Figures 1 to 4. The wireless temperature sensor called ATE400 installation examples, see images below. 1.4.4 Wireless Temperature Coordinator The wireless temperature coordinator connected with ATE series wireless temperature sensor ATC450-C which can be mounted on rail (DIN35mm) or bolted directly.
- Page 10 安科瑞电气股份有限公司 The wireless temperature coordinator connected with ATE series wireless temperature sensor ATC600 which can be mounted on rail (DIN35mm).
- Page 11 3 ） Before placing an order for wireless temperature measurement products, you need to have a Acrel Wireless Temperature Measurement detailed configuration plan, and fill in the Confirmation Form...
