We.lock SECBNEBL51 Instructions

SECBNEBL51
Catalogue
Applicable size
.........................................................01
Product components ..................................................03
Accessories list (TOOL BOX)
.....................................04
Install battery
Adjust the length of the cylinder
..................................05
Installation pictures/video
Uresetting diagram
Setting operation ......................................................06
Unlock and lock .......................................................08
Bluetooth activation and login instructions .......................09
Select"Android/iOS"to download
Log in to the app
Bind the device ........................................................10
Specifications ...........................................................11
FAQ
40.60.12.1101
Product Components
Front
handle
Fingerprint
Set key
Wake up
key
Lock cylinder
Open
Please use power bank
to charge the lock via
USB cable,and then
unlock the lock via
welock APP
Another method
of unlocking
Cam Product ID
Please note:
No support for
charging
Front handle
screw
English
Accessories list (TOOL BOX)
If there is alack of accessories, please contact customer service in time.
RFID Card * 3 Lock cylinder
extension * 1
Front handling
screw* 2
Fixing screw for
battery cover* 2
Install battery
Reset
1. Loosen the screws with allen key
3. Open the battery cover
Rear handle
screw
5. Install battery
Applicable size
cross
screwdriver * 1
Phillips
Allen key *1
screwdriver *1
SECBNEBL51
Thimble*1
ID:195106XX
Silicone plug* 2
Manual Product ID
2. Open the metal case
4. 3 * AAA battery
(Please buy it by yourself)
6. Fix the battery cover and tighten
the screws
30- 70mm
Adjusting the length of the lock cylinder
In accordance with the required lock cylinder length, you can adjust the internal and
external length by loosening the screw with an inner hexagon spanner and pulling out
the handle as needed; if necessary, you can increase the lock cylinder length by using
an extended lock cylinder piece and tighten the screw after adjustment. Plugged the
adjusting hole with a silicone plug, which can play a certain waterproof role.
Silicone plug
Spare lock cylinder extension, which can increase the length of the lock cylinder if necessary.
Align and tighten
the holes with a cross screwdriver
Due to the security reason, the front handle cannot be taken off.
Installation pictures
1. Remove the fixing screw and 2. Take out the screws and take
original cylinder out the rear handle
3.The lock cylinder is installed into 4. Installation Fixing screws
the lock hole from the outside
5. Install rear handle 6. Fixed rear handle screw
Uresetting diagram
1. Opening the silicone cover
2. Find the Thimble in the attached accessories
3. Find the hole where the reset button is located
4. Insert the thimble into the hole and press the reset button
Reset
Thimble
