- Page 1 A10 Pro Auto-Empty Robot Vacuum Cleaner User Manual EN English DE Deutsch ES Español FR Français Find more information at Italiano www.zaco.eu...
- Page 2 EN English Dear Customer, thank you for choosing the ZACO A10 Pro robot vacuum cleaner! You are now among the millions of people who clean with robots - the smarter way to get things done. Please take a few minutes to read this manual and familiarize yourself with your robot so you can get the best performance out of it.
-
Page 3: Table Of Contents
Mopping function App download & user instructions Product Operation Operating instructions Intelligent cleaning (default mode) Spot-mode cleaning Room-specific cleaning Cleaning of defined areas Setting up restricted areas (no-go-areas) Scheduled cleaning Do-not-disturb mode (DND) Other app functions Find more information at www.zaco.eu... - Page 4 Clean the suction shaft of the self-emptying charging station Clean the infrared sensor & charging contacts of the self-emptying charging station Product Specification Main device Self-emptying charging station ErP information Common Problems Troubleshooting Frequency Band EU Declaration of Conformity Find more information at www.zaco.eu...
-
Page 5: Safety Instructions
Keep the cleaning tool out of reach of children. • Do not place any objects (including children and pets) on the stationary or moving robot. • Make sure to keep your fingers and hair away from the suction inlet of the robot. Find more information at www.zaco.eu... - Page 6 • Do not use the mopping function on carpets or on top of furniture. • Make sure there is no more residual water in the water tank and remove it before charging the robot. Find more information at www.zaco.eu...
- Page 7 If you do not use the robot for a long time, charge it fully and store the product in a dry and shaded place. It is recommended to charge the robot at least once every three months to avoid battery damage due to overcharging or discharging. Find more information at www.zaco.eu...
-
Page 8: Product Overview
List of accessories Robot Self-emptying station 2 in 1 Dustbin & water tank High-performance filter + Dust bag 2x Side brush sponge filter Mopping plate Mop cloth Cleaning tool User manual Main Brush Rubber brush Find more information at www.zaco.eu... -
Page 9: Main Device
3 seconds to power on/off lndicator status Status Light Cleaning Blue light on Recharging Blue light on Charging Blue light flashing Low power Red light flashing Fully charged Blue light on Alarming Red light flashing Standby Find more information at www.zaco.eu... -
Page 10: Sensors And Structure
EN English Product Overview Sensors and structure Buttons Laser sensor Bumper lnfrared sensors Cliff sensors Charging contacts Nose wheel Side brushes Battery cover Drive wheels Main brush Dustbin Find more information at www.zaco.eu... -
Page 11: Self-Emptying Charging Station
Cover Dust bag Lifted position Indicator light Charging contacts lnfrared sensor Dust extraction shaft Dustbin & water tank High-performance filter cover High-performance filter Sponge filter Primary filter Water tank cap Dustbin release button Suction shaft Find more information at www.zaco.eu... -
Page 12: Installation
Also remove fragile, valuable, and potentially dange- rous objects as well as objects that can easily be tipped over. Please avoid getting the robot tangled, stuck, dragged or knocked over. Failure to do so may result in injury or property damage. Find more information at www.zaco.eu... - Page 13 If the robot is used in a suspended environment, it should be protected by rails or barriers to prevent it from accidentally falling or hitting other objects. Failure to do so may result in personal injury or property damage. Find more information at www.zaco.eu...
- Page 14 Insert the left side brush (L) and the right side brush (R) into the openings provided on the bottom of the robot. The brushes are also marked with L and R. Press the side brushes down firmly until they engage with a "click" sound. Find more information at www.zaco.eu...
- Page 15 EN English Installation Place the self-emptying charging station on a flat surface against the wall. Ensure that the cabling is neat and tidy. Find more information at www.zaco.eu...
- Page 16 Keep a minimum distance of 0.5 m to both the left and right of the charging station and 1.5 m in front of the charging station. Do not move the charging station once it has a set position and avoid direct sunlight on the charging station. Find more information at www.zaco.eu...
- Page 17 When you hear the voice prompt “start charging” the robot is charging successfully. Note If the battery is too low, the robot cannot be turned on. Place the robot vacuum cleaner on the charging station. The device will be switched on automatically. Find more information at www.zaco.eu...
-
Page 18: Mopping Function
EN English Installation Mopping function Open the water tank cap and add the appropriate amount of water. Close the cap. Do not add any cleaning detergent. Put the water tank back into the robot. Find more information at www.zaco.eu... - Page 19 EN English Installation Attach the mop to the mopping plate. Attach the mopping plate to the underside of the robot. Find more information at www.zaco.eu...
-
Page 20: App Download & User Instructions
EN English App download & user instructions Scan the QR code to install the app. Register and log in to the app. Or search "ZACO Smart" in the iOS App Store or the Google Play Store and download the App. Smart Click "Add a device"... - Page 21 3 sec., until you hear the voice prompt “AP mode” and the Wi-Fi indicator light flashes. Select the “SMARTlife-XXXX” WiFi on your Return to the ZACO Smart App. mobile device to connect to the device. Find more information at www.zaco.eu...
-
Page 22: Product Operation
Make sure that there are no cables in the way. The robot can get tangled in loose cables and can also pull a cable out of the socket. Under certain circumstances, this can lead to damage to electrical equipment. Find more information at www.zaco.eu... - Page 23 If the robot vacuum cleaner does not find the charging station, it will automati- cally return to the starting point. Please place the robot on the station manually for charging. 4. Selection of suction power Use the app to select from 3 different modes Energy-saving Standard (default) Powerful Find more information at www.zaco.eu...
-
Page 24: Intelligent Cleaning (Default Mode)
If the robot is unable to determine its exact position, it will cancel the cleaning process it has started and begin a new map. This may result in the robot skipping the automatic return to the charging station. Find more information at www.zaco.eu... -
Page 25: Spot-Mode Cleaning
1.6 m Note Before you can use this function, the robot must first create a map. Only then the map will be displayed in the mobile app and you will be able to select this function. Find more information at www.zaco.eu... -
Page 26: Room-Specific Cleaning
The robot may also clean parts of the room that are not considered in the planning. Make sure that there are generally no obstacles in the area of the planned cleaning and beyond to ensure a safe cleaning process. Find more information at www.zaco.eu... -
Page 27: Cleaning Of Defined Areas
The robot may also clean parts of the room that are not considered in the planning. Make sure that there are generally no obstacles in the area of the planned cleaning and beyond to ensure a safe cleaning process. Find more information at www.zaco.eu... -
Page 28: Setting Up Restricted Areas (No-Go-Areas)
When moving the robot vacuum cleaner or there are obvious changes in your home environment, the map might become ineffective and the restricted area might be lost. Find more information at www.zaco.eu... -
Page 29: Scheduled Cleaning
Real-time map updating • Search robot • Language selection • Map management • Cleaning history • Cleaning mode selection • Maintenance management • Partition area editing • Defining cleaning cycles of selected areas • Area attribute customizing Find more information at www.zaco.eu... -
Page 30: Routine Maintenance
Take out the main brush. Use the brush of the cleaning tool to remove dust from the main brush. Use the small blade on the cleaning tool for tangled up hairs. Note Recommended cleaning frequency: once a week. Find more information at www.zaco.eu... -
Page 31: Side Brushes
Note • lt is recommended to replace the side brush every three months to ensure an effective cleaning process. • Recommended cleaning frequency: once a week. Find more information at www.zaco.eu... -
Page 32: Dustbin And Filter
Press the dustbin release button and draw out the dustbin. Press the button on the dustbin to open the cover and empty it into a trash can. Note Recommended cleaning frequency: after each cleaning cycle. Find more information at www.zaco.eu... -
Page 33: Wash The Dustbin
Do not use a brush to clean the filter. Only use your fingers to avoid any damage. • The filter shall be dried in the air for at least 24 hours. This ensures that it is dried thoroughly. Find more information at www.zaco.eu... -
Page 34: Clean The Infrared Obstacle Avoidance Sensor
EN English Routine maintenance Clean the infrared obstacle Clean the cliff sensors avoidance sensor Clean the charging contacts Note Recommended cleaning frequency: once a month. Find more information at www.zaco.eu... -
Page 35: Clean The Signal Output Range The Self-Emptying Charging Station
The battery capacity should not be less than 50% during the firmware update. It is recommended to place the robot on the charging station during the update. Find more information at www.zaco.eu... -
Page 36: Change The Dust Bag
How to change the dust bag Unplug the power cord and lift the self-emptying charging station cover. Pull up the lifting handle of the dust bag to seal it. Remove the dust bag from the station. Find more information at www.zaco.eu... - Page 37 Ensure that the handle of the new dust bag is lowered (not pulled out) and the dust bag is firmly in place. After closing the cover of the self-emptying charging station, plug in the power cord again. Find more information at www.zaco.eu...
-
Page 38: Clean The Suction Shaft Of The Self-Emptying Charging Station
If the suction shaft is blocked, remove the cover with a screwdriver (as shown in the figure below) and clean the suction shaft. Suction shaft cover Suction shaft Caution Violent disassembly is strictly prohibited. Please reinstall it after cleaning. Find more information at www.zaco.eu... -
Page 39: Clean The Infrared Sensor & Charging Contacts Of The
Clean the infrared sensor & charging contacts of the self-emptying charging station Gently wipe the two areas regularly with a clean, soft, dry cloth. lt is recommended to clean them once a month. lnfrared sensor Charging contacts Find more information at www.zaco.eu... -
Page 40: Product Specification
Capacity of water tank 240 ml Self-emptying charging station Product name Self-emptying charging station Product model A10 Pro Overall dimension 320 x 240 x 165 mm Net weight 2.7 kg Rated Input 220 - 240 V~50 / 60 Hz Rated Output 19 V 1A Rated power 680 W Find more information at www.zaco.eu... -
Page 41: Erp Information
Efficiency at low load (10 %) ≥82.43% No-load power consumption ≤0.923W Percentage of nameplate output current Load condition 1 100%±2% Load condition 2 75%±2% Load condition 3 50%±2% Load condition 4 25%±2% Load condition 5 10%±1% Find more information at www.zaco.eu... -
Page 42: Common Problems
The cleaning performance is impaired. • The dustbin is clogged. Clean the dustbin. • The filter is worn. Clean or replace the filter. • Foreign objects are caught in the main brush. Clean the main brush. Find more information at www.zaco.eu... - Page 43 The lithium battery does not have a hours when the robot is used for the first memory effect. lt can be used instantly three times? after it is fully charged. There is no need to wait. Find more information at www.zaco.eu...
-
Page 44: Troubleshooting
Error 9: Please check whether the side The side brushes are stuck or something brushes are stuck has become tangled in the side brushes. Please check them and remove foreign objects. Find more information at www.zaco.eu... -
Page 45: Frequency Band
802.11g: 14 dB 802.11n: 13 dB EU Declaration of Conformity Robovox Distributions GmbH hereby declares that the ZACO A10 Pro radio complies with Directive 2014/53/EU. The full text of the EU Declaration of Conformity can be found on the Internet address https://conformity.zaco.eu/download/a10pro.pdf...
