Summary of Contents for ASROCK H610M-H2/M.2 D5

  • Page 2 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header Installing the I/O Panel Shield Installing the Motherboard Installing SATA Drives Installing a Graphics Card Connecting Peripheral Devices...

  • Page 4: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 5: Specifications

    • Max. capacity of system memory: 96GB • Supports Intel® Extreme Memory Profile (XMP) 3.0 * Actual support may vary by CPU * Supports DDR5 4800 (1DPC) natively. * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 6 H610M-H2/M.2 D5 • Gigabit LAN 10/100/1000 Mb/s • Realtek 8111H • 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front) • 6 x USB 2.0 (4 Rear, 2 Front) * All USB ports support ESD Protection • 1 x PS/2 Mouse/Keyboard Port Rear Panel • 2 x USB 3.2 Gen1 Type-A Ports...
  • Page 7 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 8: Motherboard Layout

    H610M-H2/M.2 D5 1.3 Motherboard Layout...
  • Page 9 No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) Chassis/Water Pump Fan Connector (CHA_FAN1/WP) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB3_3_4) USB 2.0 Header (USB_5_6) SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_3) (Lower) SPI TPM Header (SPI_TPM_J1) SATA3 Connector (SATA3_1) SATA3 Connector (SATA3_0)

  • Page 10: I/O Panel

    H610M-H2/M.2 D5 1.4 I/O Panel No. Description No. Description USB 2.0 Ports (USB_1_2) USB 2.0 Ports (USB_3_4) LAN RJ-45 Port* USB 3.2 Gen1 Type-A Ports (USB3_1_2) Line In (Light Blue)** PS/2 Mouse/Keyboard Port Front Speaker (Lime)** HDMI Port Microphone (Pink)** HDMI Port * There are two LEDs on each LAN port.

  • Page 11: Block Diagram

    1.5 Block Diagram...

  • Page 12: Chapter 2 Installation

    H610M-H2/M.2 D5 Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 13: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
  • Page 14 H610M-H2/M.2 D5...
  • Page 15 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 16: Installing The Cpu Fan And Heatsink

    H610M-H2/M.2 D5 2.2 Installing the CPU Fan and Heatsink...

  • Page 17: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 18 H610M-H2/M.2 D5...

  • Page 19: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 20: Installing The I/O Panel Shield

    H610M-H2/M.2 D5 2.5 Installing the I/O Panel Shield...

  • Page 21: Installing The Motherboard

    2.6 Installing the Motherboard...

  • Page 22: Installing Sata Drives

    H610M-H2/M.2 D5 2.7 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 23 SATA Power Connector SATA Data Connector...

  • Page 24: Installing A Graphics Card

    H610M-H2/M.2 D5 2.8 Installing a Graphics Card CLICK!
  • Page 25 Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 26: Connecting Peripheral Devices

    H610M-H2/M.2 D5 2.9 Connecting Peripheral Devices...

  • Page 27: Connecting The Power Connectors

    2.10 Connecting the Power Connectors...

  • Page 28: Power On

    H610M-H2/M.2 D5 2.11 Power On...

  • Page 29: Jumpers Setup

    2.12 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) (see p.5, No. 14) CLRMOS1 allows you to clear the data in CMOS.

  • Page 30: Onboard Headers And Connectors

    H610M-H2/M.2 D5 2.13 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.5, No.
  • Page 31 Chassis Intrusion and Speaker Header (7-pin SPK_CI1) (see p.5, No. 13) Please connect the chassis intrusion and the chassis speaker to this header. SPK_CI1 SPEAKER DUMMY DUMMY SIGNAL DUMMY Serial ATA3 Connectors Vertical: (SATA3_0) (see p.5, No. 11) (SATA3_1) (see p.5, No. 10) Right Angle: (SATA3_2) (see p.5, No.
  • Page 32 H610M-H2/M.2 D5 USB 2.0 Header (9-pin USB_5_6) (see p.5, No. 7) There is one header on this motherboard. This USB 2.0 header can support two ports. USB_5_6 DUMMY USB_PWR USB_PWR USB 3.2 Gen1 Header (19-pin USB3_3_4) (see p.5, No. 6) There is one header on this motherboard.
  • Page 33 Front Panel Audio Header (9-pin HD_AUDIO1) (see p.5, No. 15) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 PRESENCE# MIC_RET OUT_RET OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly.
  • Page 34 H610M-H2/M.2 D5 CPU Fan Connector (4-pin CPU_FAN1) (see p.5, No. 2) This motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED...
  • Page 35 ATX 12V Power Connector (8-pin ATX12V1) (see p.5, No. 1) This motherboard provides a 8-pin ATX 12V power connector. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5. *Warning: Please make sure that the power cable connected is for the CPU and not the graphics card.
  • Page 36 H610M-H2/M.2 D5 2.14 M.2 SSD Module Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_1, Key M) supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) modes.
  • Page 37 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module. NUT2 NUT1 For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 38 In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 39 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You...
  • Page 40 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.
  • Page 41 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
