Credenza
Costa Collection | Model 422984
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
Sit and surf.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 547057
05/05/20
Purchased: __________________
Advertisement
Related Manuals for Sauder Costa Credenza 422984
Summary of Contents for Sauder Costa Credenza 422984
- Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-523-3987 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 8:30 a.m.
- Page 2 CENTER BACK (1) W LEFT DOOR (1) RIGHT BOTTOM (1) LEFT REAR LEG (1) RIGHT DOOR (1) BOTTOM (1) LEFT FRONT LEG (2) RIGHT FRONT LEG (2) LEFT CENTER LEG (1) BOTTOM MOLDING (1) LEFT BOTTOM (1) Page 2 422984 www.sauder.com/service...
- Page 3 Part Identification www.sauder.com/service 422984 Page 3...
- Page 4 3S GOLD 5/16" FLAT HEAD SCREW - 4 BLACK 9/16" LARGE HEAD SCREW - 1 BLACK 1/2" FLAT HEAD SCREW - 8 18S BROWN 1" FLAT HEAD SCREW - 4 BLACK 1-1/8" MACHINE SCREW - 2 BLACK 9/16" FLAT HEAD SCREW - 4 Page 4 422984 www.sauder.com/service...
- Page 5 STOP å To begin assembly, push a SAUDER TWIST-LOCK® FASTENER (7F) into the large holes in the ENDS (A and B). Repeat this step for If you purchased the BOTTOMS (F, G, and R) and UPRIGHTS (L and M).
- Page 6 ENDS (A and B), PRINTER SHELF (D), Some assembly and UPRIGHTS (L and M). (and snacks) required. (27 used) Arrow Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 422984 www.sauder.com/service...
- Page 7 Step 3 å Turn twenty-seven CAM SCREWS (8F) into the PRINTER SHELF MOLDING (K) and LEGS (H, O, P, Q, S, and T). (27 used) www.sauder.com/service 422984 Page 7...
- Page 8 NOTE: If the MOLDING comes up off of the SCREWS, remove it and slide it on again. The MOLDINGS should be even on both edges of the ENDS. Shoulder BLACK 9/16" FLAT HEAD SCREW (4 used in this step) Page 8 422984 www.sauder.com/service...
- Page 9 Fill the holes 1/4 to 1/2 full with GLUE. These surfaces should be even. Edge without hole Edge with TWIST-LOCK® FASTENERS S u r f a c H I D D E N i t h These surfaces should be even. Edge without hole www.sauder.com/service 422984 Page 9...
- Page 10 Fill the holes 1/4 to 1/2 full with GLUE. These surfaces should be even. Edge with hole S u r f a c H I D D E N i t h Edge with TWIST-LOCK® FASTENERS These surfaces should be even. Edge with hole Page 10 422984 www.sauder.com/service...
- Page 11 These surfaces should be even. Edge without hole Edge with TWIST-LOCK® FASTENERS S u r f a c H I D D E N i t h o These surfaces should be even. Edge without hole www.sauder.com/service 422984 Page 11...
- Page 12 These surfaces should be even. Edge with hole S u r f a c H I D D E N i t h o Edge with TWIST-LOCK® FASTENERS These surfaces should be even. Edge with hole Page 12 422984 www.sauder.com/service...
- Page 13 UPRIGHTS (L and M). Use four GOLD 5/16" FLAT HEAD SCREWS (3S). å NOTE: The CABINET RAILS are marked "CABINET RIGHT" and "CABINET LEFT" for easy identification. Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end www.sauder.com/service 422984 Page 13...
- Page 14 Step 10 å Slide the BOTTOM MOLDING (I) onto the notched edge of the BOTTOM (G). Now might be a good time to refresh your drink. Notched edge Slide the BOTTOM MOLDING (I) onto the notched edge. Page 14 422984 www.sauder.com/service...
- Page 15 Caution Tighten four TWIST-LOCK® FASTENERS. Do not stand the unit upright without the BACK fastened. The unit may collapse. How to use the SAUDER TWIST-LOCK FASTENER ® 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
- Page 16 (4 used) Meet Part (V). This component has been engineered to be lighter, stronger, faster… well ok. Not technically faster. But definitely makes for a sturdier Credenza that’ s easier to assemble and friendlier to the environment. Page 16 422984 www.sauder.com/service...
- Page 17 BOTTOMS (F and R). BOTTOM MOLDING (E) onto the notched edge. Notched edge These edges should be even. Notched edge These edges should be even. Slide the SHORT BOTTOM MOLDING (E) onto the notched edge. www.sauder.com/service 422984 Page 17...
- Page 18 Step 14 å Fasten the BOTTOMS (F and R) to the UPRIGHTS (L and M). Tighten four TWIST-LOCK® FASTENERS. Page 18 422984 www.sauder.com/service...
- Page 19 Fasten the ENDS (A and B) to the BOTTOMS (F and R) and TOP (V). Tighten eight TWIST-LOCK® FASTENERS. å NOTE: Be sure the WOOD DOWELS in the LEGS insert into the TOP. Wipe away the excess GLUE. 177M Fill the holes 1/4 to 1/2 full with GLUE. www.sauder.com/service 422984 Page 19...
- Page 20 TOP (V). å Fasten the BACKS (U) to your unit using the NAILS (1N). Edge without holes NAIL BLACK 9/16" LARGE HEAD SCREW (1 used for the METAL BRACKET) (36 used in this step) Edge without holes Page 20 422984 www.sauder.com/service...
- Page 21 Remove the Nail Holder from the NAIL and completely tap the NAIL in with your hammer. offset edge 5" nail slot Nail Holder 2" bead bead NAIL (16 used in this step) 5" 2" offset edge www.sauder.com/service 422984 Page 21...
- Page 22 Step 18 å Fasten two HINGES (14H) to each DOOR (W and X). Use eight BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2” FLAT HEAD SCREW (8 used in this step) Page 22 422984 www.sauder.com/service...
- Page 23 Fasten a KNOB SET (167K) to the LEFT DOOR (W). Use a BLACK 1-1/8" MACHINE SCREW (21S). Hinge å Repeat this step for the RIGHT DOOR (X). å See the next step for DOOR adjustments. 167K BLACK 1-1/8" MACHINE SCREW (2 used in this step) www.sauder.com/service 422984 Page 23...
- Page 24 To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 24 422984 www.sauder.com/service...
- Page 25 Fasten the PRINTER SHELF MOLDING (K) to the PRINTER SHELF (D). Tighten three HIDDEN CAMS. å NOTE: Be sure to position the PRINTER SHELF MOLDING exactly as shown. The CAM SCREWS should be closer to this edge. www.sauder.com/service 422984 Page 25...
- Page 26 Push a CORD CLIP (4P) into the hole in the KEYBOARD SHELF (D). å NOTE: The CORD CLIP is used to hold your keyboard cord against the KEYBOARD SHELF. Roller end Roller end BROWN 1" FLAT HEAD SCREW (4 used in this step) Page 26 422984 www.sauder.com/service...
- Page 27 SHELF behind the rollers on the unit. Lift the front of the SHELF up and slide it into the unit. å Insert the GROMMET (10P) and GROMMET CAP (1P) into the large hole in the TOP (V). www.sauder.com/service 422984 Page 27...
- Page 28 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or 25 lbs. (8 used) 25 lbs.
- Page 29 EXTRÉMITÉ DROITE ..........1 GLISSIÈRE DROITE D'ÉLÉMENT .....1 pour future référence. EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE GAUCHE D'ÉLÉMENT ....1 Pour contacter Sauder MOULURE D’EXTRÉMITÉ ........2 COULISSE DROITE DE TIROIR ......1 en ce qui concerne cet élément, faire référence TABLETTE POUR IMPRIMANTE.......1 COULISSE GAUCHE DE TIROIR ......1...
- Page 30 Pour commencer l'assemblage, enfoncer une FIXATION TWIST-LOCK® Insérer ensuite deux CHEVILLES EN BOIS (15F) dans les trous. SAUDER (7F) dans les gros trous des EXTRÉMITÉS (A et B). Répéter Nettoyer l'excès de COLLE. cette étape pour les DESSOUS (F, G et R) et les MONTANTS (L et M).
- Page 31 Fixer le DESSOUS (G) aux MONTANTS (L et M). Serrer quatre ÉTAPE 16 FIXATIONS TWIST-LOCK®. Utilisation de la FIXATION TWIST-LOCK® SAUDER: Attention: Ne pas relever l'élément dans sa position verticale 1. Insérer l'extrémité filetée de la FIXATION dans le trou de la pièce attenante.
- Page 32 ÉTAPE 21 Fixer la MOULURE DE TABLETTE POUR IMPRIMANTE (K) à la TABLETTE POUR IMPRIMANTE (D). Serrer trois EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer de positionner la MOULURE DE TABLETTE POUR IMPRIMANTE comme l'indique le schéma. Page 32 422984 www.sauder.com/service...
- Page 33 MOLDURA DE EXTREMO ........2 CORREDERA DERECHA DE CAJÓN ....1 necesita ponerse en ESTANTE DE LA IMPRESORA ......1 CORREDERA IZQUIERDA DE CAJÓN ..1 contacto con Sauder en MOLDURA DE FONDO CORTA .......2 EXCÉNTRICO ESCONDIDO ......27 cuanto a esta unidad, FONDO DERECHO .............1 BIELA DE EXCÉNTRICO ........27...
- Page 34 Para comenzar el ensamblaje, empuje un SUJETADOR TWIST-LOCK® A continuación, inserte dos PASADORES DE MADERA (15F) dentro SAUDER (7F) dentro de los agujeros grandes de los EXTREMOS (A y B). de los agujeros. Quite el exceso de PEGAMENTO. Repita este paso para los FONDOS (F, G y R) y los PARALES (L y M).
- Page 35 Fije el FONDO (G) a los PARALES (L y M). Apriete cuatro SUJETADORES TWIST-LOCK®. PASO 16 Cómo utilizar el SUJETADOR TWIST-LOCK® SAUDER: 1. Inserte el extremo con cabilla del SUJETADOR en el agujero de la parte adjunta. Precaución: No coloque la unidad en posición vertical hasta que se NOTA: El extremo con cabilla del SUJETADOR debe quedarse fije el DORSO.
- Page 36 Apriete el tornillo de montaje después de hacer los ajustes. PASO 21 Fije la MOLDURA DE ESTANTE DE IMPRESORA (K) al ESTANTE DE LA IMPRESORA (D). Apriete tres EXCÉNTRICOS ESCONDIDOS. NOTA: segúrese de colocar la MOLDURA DE ESTANTE DE LA IMPRESORA exactamente como se muestra. Page 36 422984 www.sauder.com/service...
