Page 2: Table Of Contents
Table of Contents Store Locator ........... 3 Truma Ultra-Rapid Hot Water System ..21 Head Office ..........3 How to light hot water system on gas ..21 Caboolture Showroom ........ 3 How to light hot water system on 240 V .. 21 Rocklea Showroom ........ -
Page 3: Store Locator
Store Locator Head Office 07 5498 3888 sales@austrackcampers.com.au Mon – Fri 9am-5pm Scan for Map Caboolture Showroom 73 Lear Jet Drive Caboolture, QLD 4510 07 5408 7111 caboolture@austrackcampers.com.au Mon – Fri 9am-5pm Sat 9am-3pm Rocklea Showroom 7 Collinsvale Street Rocklea, QLD 4106 07 3112 7868 rocklea@austrackcampers.com.au Mon –... -
Page 4: Re-Sellers And Suppliers
Re-sellers and suppliers Rising Sun Townsville – Re-seller 35 Bowen Road Rosslea, QLD 4812 07 4779 0211 Precision Motors Armidale – Re-seller 101/107 Barney Street Armidale, NSW 02 36772 5866 Redarc www.redarc.com.au Technical support 1300 733 272 Projecta www.projecta.com.au Technical support 1800 422 422 Truma hot water systems https://www.leisure-tec.com.au/services/ Technical support 1300 072 018... -
Page 5: Warranty T&C's
Office by telephone: (07) 5498 3888 or email: service@austrackcampers.com.au. By purchasing an item from Austrack Campers, you agree to all terms and conditions of warranty below. Austrack Campers registered business address is 73 Lear Jet Drive, Caboolture, QLD, 4510. Trailer Limited Warranty... - Page 6 1. WARRANTY DISCLAIMER. THIS LIMITED WARRANTY IS THE SOLE EXPRESS WARRANTY PROVIDED BY AUSTRACK CAMPERS AND THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF, EXCEPT AS MAY BE PROVIDED BY AUSTRALIAN CONSUMER LAW. THIS WARRANTY IS GIVEN ONLY BY AUSTRACK CAMPERS, AND Page | 6...
- Page 7 MAY BE MODIFIED ONLY BY AUSTRACK CAMPERS. THIS LIMITED WARRANTY IS THE FINAL EXPRESSION OF OUR AGREEMENT, AND IS A COMPLETE AND EXCLUSIVE STATEMENT OF THE TERMS OF THAT AGREEMENT. THIS LIMITED WARRANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS UNDER AUSTRALIAN CONSUMER LAW.
- Page 8 5. general consumables (bearings, light bulbs etc). Factory Seconds, Ex-Demonstration and Damages Goods Occasionally, Austrack Campers may offer items for sale deemed to be “factory seconds”, “ex- demonstration”, or “damaged”. Such items are sold on an “as is” basis. No warranties, refunds, credits, exchanges or similar associated apply to “factory seconds”, “ex- demonstration”, or “damaged”...
- Page 9 The original purchaser will make no claims or be eligible for any claims on behalf of the new owner. 8. Warranties do not extend to any products purchased from Austrack Campers that are used in hire schemes or as rentals.
- Page 10 Warranty Terms. 3. The customer bears the responsibility of providing adequate evidence of the failure which amounts to a warranty claim. Austrack Campers may require additional evidence to be produced by the customer in the event...
-
Page 11: General Safety Introduction
This manual is supplied as a reference to required maintenance of your new Austrack Campers Hybrid offroad camper. Failure to use and maintain the product in accordance with what is outlined in this manual may affect your warranty. -
Page 12: Load Distribution
Load Distribution When heading away on your next big adventure it is important to load your caravan correctly to distribute weight evenly and achieve a suitable ball weight load and prevent loading in a manner that can cause a caravan to sway and/or roll excessively left and right. The optimum ball weight on a caravan is between 8% and 12% of the total caravan weight. -
Page 13: Maintenance Schedule
Maintenance Schedule Page | 13... -
Page 14: Specifications
Specifications Fully welded Aluminium frame construction with Royal silver aluminium Structure & Finish composite panel & gloss black aluminium checker plate. Fully Welded aluminium wall frame, aluminium composite panelling, Hot Construction dipped galvanised Chassis & Drawbar. Hot dipped galvanised Inside & Outside 150 x 50 x 4mm. Full RHS box chassis Drawbar &... - Page 15 Multiple Storage Boxes with Drawers & plenty of open space. High Quality Storage pinch-weld automotive seals & adjustable compression locks. Double glazed quality tinted glass door with mosquito & security mesh. Windows Windows include anti-mosquito mesh and shade curtain. Gas strut assisted pop up roof for easy quick set up. Internal zip windows with Internal setup screens in pop top.
-
Page 16: Electrical System
Electrical System Battery Management System The Tanami is equipped with the Redarc Manager30 Battery Management System (BMS). The Manager30 operates like 6 separate products, it charges an auxiliary battery from the vehicle while on the move, it’s a 240 V charger, a MPPT solar regulator, a battery isolator, a load disconnect controller, all with a remote battery monitor. -
Page 17: Inverter
Inverter The Tanami is also equipped with a Redarc 2000 W pure sine wave inverter and automatic change- over relay. This means that no matter where you are, you are able to run your 240 V appliances off the hybrid! If you are free camping, you will need to turn on the inverter, and you are limited to 2000 W appliances. -
Page 18: Extra Solar Input
Extra Solar Input Also included on the Tanami is a solar input on the rear driver’s side of the hybrid. This is for connection to an external solar panel to supplement the 400 W of solar on the roof. This input requires a regulated panel to be connected, use of an un-regulated panel may cause damage to the batteries in the hybrid. -
Page 19: Fuse Box
Fuse box The fuse box is located under the seat inside the Tanami. Each of the fuses are listed on the inside of the fuse box lid and will have a red light next to them if they need replacing. It is highly recommended to keep a mix pack of spare fuses in the hybrid in case of tripping. -
Page 20: Water System
Water System The Tanami is equipped with 2 x 120 L fresh water poly tanks with stainless steel guard and 1 x 80 L grey water poly tank with stainless steel guard. All 3 tanks have taps and bungs on the bottom of the tank for easy draining and rinsing. -
Page 21: Truma Ultra-Rapid Hot Water System
Truma Ultra-Rapid Hot Water System The Tanami has a Truma ultra-rapid gas/electric hot water system installed. This system is designed to run off either the plumbed gas in the hybrid or from 240 V mains power. For detailed instructions, please see the instruction manual supplied in the hybrid. How to light hot water system on gas •... -
Page 22: Braking Systems
Braking Systems Electric Brakes The Tanami comes fitted with electric brakes which require a brake controller installed into the towing vehicle that can be controlled from the driver’s seat. There are many systems available which can either be permanently installed into the tow vehicle or Bluetooth units that are mounted to the trailer and have a remote to control from the driver’s position. -
Page 23: Trailer Breakaway
Trailer Breakaway The Tanami comes fitted with a Breakaway switch. The steel cable attached to the drawbar switch is designed to attach to a solid part of your vehicle. In the event of a trailer disconnection, this will pull out the pin from the switch and activate the trailer brakes. The brakes will stay locked on as long as the pin is removed from the drawbar switch and there is power in the battery system of the hybrid. -
Page 24: Setting Up Campsite
Setting up campsite When setting up your campsite it is important to have the camper set up close to level but keeping a small run off to the rear of the van to ensure water does not pool on the roof. Picking a spot that is relatively level, gets sun during the day and is not under any large tree’s, especially Gum trees, is important. -
Page 25: Gas System
Gas System The Tanami is fitted with plumbed gas, with the gas cylinder holders mounted inside the front toolbox. The gas hoses have the LCC27 connection and requires the matching gas cylinder to be able to use the system. The regulator has a one-way valve on top to allow for easy switching of the gas cylinders. The valve must be pointing in the direction of the gas cylinder being used for the gas to flow through the system. -
Page 26: Outside Shade
Outside Shade Electric awning The Tanami range is fitted with an electric awning as standard. This is controlled by the 3-way awning rocker switch in the control panel. It is important to use the legs to support the awning when opening, closing and when the awning is fully extended. -
Page 27: Toilet
Toilet The Tanami is fitted with the Thetford C402-2 toilet. This has an inbuild 15L flush tank and 19L waste tank for longer trips. A tester set of chemicals is provided in the hybrid, and it is recommended to use only the Thetford chemicals and toilet paper. Filling the flush tank •... -
Page 28: Use Of The Toilet
Use of the toilet • Run water into the bowl by pressing the flush knob briefly or open the valve blade by turning the handle anti-clockwise. Your Thetford toilet is now ready for use. • After use, open the valve blade (if still closed) by turning the handle anti-clockwise. •... -
Page 29: Preparing The Toilet For Storage
Preparing the toilet for storage It is important that you follow the instructions below if you do not expect to use the Thetford toilet for a long period. • Completely empty the water tank through the drain tube, which also serves as a level indicator. -
Page 30: External Kitchen
External Kitchen Your Tanami is equipped with a quality stainless steel kitchen complete with a Dometic 3 burner cook top, sink and drying rack. The kitchen is located at the rear passenger side of the camper and can be accessed by opening the access hatch, once the hatch is open you will see 2 spring &... - Page 31 Now just loosen the nuts to lower the legs to the ground, keep the legs angled at around 45 degrees then tighten the nuts. Once again take hold of the top handle (2) and gently lift the kitchen slide, allowing the legs to move forward, this may take a couple of goes until you get your kitchen nice and level.
-
Page 32: Air Conditioner
Air Conditioner The Tanami range of hybrids comes fitted with the Dometic Harrier Lite air conditioner. This is installed to work off the 240 V system only, meaning that it will not work unless the hybrid is connected to shore power; it will not work off the installed inverter. The air conditioner will work from a generator connected through the 15 A input on the side of the hybrid. -
Page 33: Tv Antenna / Tv / Dvd
TV antenna / TV / DVD The hybrid is fitted with an Omnidirectional TV antenna with booster, a Digital TV, and a FM/CD/DVD/Bluetooth capable stereo. Watching Free-to-Air TV • Make sure “cigi sockets” switch is on • Turn on TV with the remote •... -
Page 34: Condensation / Mould
Condensation / mould Condensation is a normal part of living in Australia, and this is highlighted when camping. The temperature difference inside and outside a hybrid camper can be quite significant, and with the moisture in the Australian air and the smaller living area of a hybrid camper, condensation can build up overnight. -
Page 35: Troubleshooting
Troubleshooting Category Issue Troubleshooting Steps • Electrical - AC AC not turning on Check mains power is connected • Check RCD not tripped on incoming power supply • Check RCD not tripped in hybrid • Replace remote batteries • Contact Dometic service centre for more advice •... - Page 36 Electrical – Any other error Inverter • Water No water to taps Make sure water pump is on • Make sure there is water in the tank selected • Swap water tank used • Let tap run for approx. 20 secs to clear the air from the lines •...
- Page 37 • Hold down the ignition button for 2 secs after the flame starts • Not finding any channels Make sure input is DTV • Make sure “cigi sockets” switch is on • Contact service department for more advice • Fridge Not switching on Make sure “fridge”...
Need help?
Do you have a question about the TANAMI X15L and is the answer not in the manual?
Questions and answers
How do I clean the filter in the air conditioner The filter closest to the shower curtain in the Tanami 15L
