Summary of Contents for Engler Vet II
- Page 1 Rev.C 10 / 09 / 2014 Page 1 of 28...
-
Page 2: Table Of Contents
WATER FILTER CLEANING INSTRUCTIONS.................19 SADDLE VALVE ASSEMBLY ....................20 Options for connecting the saddle valve....................22 WATER TANK INSTRUCTIONS.......................23 WATER TANK CARE & MAINTENANCE..................24 CARE AND MAINTENANCE OF YOUR PORTABLE WATER TANK..........24 OPTIONAL VET II ACCESSORIES....................25 TECHNICAL DATA..........................27 DIMENSIONS............................28 Page 2 of 28... -
Page 3: Read Before You Start
This is normal for all ultrasonic scalers. Never let the scaling tip touch soft tissue or skin, Engler Engineering Corporation is not responsible for any damage caused by improper use of this device and / or its accessories. -
Page 4: Company Profile
A.D.S. 2000, microprocessor controlled anesthesia delivery system / ventilator, Sentinel V.R.M., respiratory monitor. We manufacture all of the inserts and tips used in the Engler products as well as many others on the market today in the 18K and 25K frequency range. -
Page 5: Introduction
As a result, the tip vibrates at this ultrasonic frequency with an amplitude of 0.001 to 0.004 in. (25.4 um to 102 um). In designing our unique Engler tips, water flows internally through the tip as it vibrates. As the bubbles in the lavage are bactericidal, the energy released collapses and destroys the bacterial cell walls. The water flowing internally through the tip, effectively cools the area and assists in removing any debris from the operative site. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Before installing or operating your new VET II, carefully read and follow all of the instructions. IMPORTANT: This device must be connected to a clean, filtered, water supply, capable of delivering 30 to 60 psi (2.0 to 4.2 kg/cm2) of water input pressure. This unit comes with an In-Line water filter (P/N: A52030). - Page 7 Female Quick Disconnect (P/N: 44300) - This is the female mating connector to the male quick disconnect supplied with the VET II . Use this to create a custom water installation utilizing ¼ “ I.D. water tubing. 44300 Female quick disconnect 2.
- Page 8 Connecting water supply, cont. PLEASE NOTE: Minerals and foreign particles in the water may cause a buildup or blockage of hoses and parts. The water filter supplied with this device must be opened and inspected quarterly and we suggest that the filter disc and O-ring be cleaned regularly and changed out at least once a year.
-
Page 9: Ultrasonic Scaler Handpiece
ULTRASONIC SCALER HANDPIECE Note: Water lines were purged prior to shipping. When activating the Vet II for the first time, please follow these instructions. To begin: WITH NO STACK / INSERT IN THE HANDPIECE, rotate the power control knob to the right, the knob will click “on”... - Page 10 Ultrasonic scaling procedures are not intended for soft tissue. CAUTION: Contact with Soft Tissue Will Cause Burns. Engler Engineering Corporation will not be liable for damage or injury due to improper use of this device.
-
Page 11: Scaler Maintenance
SCALER MAINTENANCE FINAL PROCEDURES AT THE END OF EACH DAY: 1. Turn the unit off. 2. Remove the insert, rinse with running water, then sterilize. 3. Disconnect the unit from its water source or turn off the water supply. 4. Clean and disinfect all surfaces. Scaler tip maintenance: Inserts may be sterilized by autoclave or chemiclave, always following the manufacturer’s instructions and recommendations. - Page 12 5. Do not rotate the selector switch on the front of the control box between forward and reverse rapidly. always allow the micromotor to stop between the two selections. 6. As this is a precision instrument, always return it to Engler Engineering Corporation for maintenance and repair.
- Page 13 POLISHER OPERATION 1. Dampen the rubber cup and place a small amount of polishing paste on it. 2. Rotate the POWER control to the minimum setting in the PROPHY RANGE. 3. Depress the footswitch and the rubber cup will begin to rotate. The speed of rotation may be adjusted to your desired level by re-adjusting the POWER control.
-
Page 14: Straight Handpiece Maintenance Cont
2. Never clean the handpiece with boiling water, chemical solutions, ultrasonic cleaner, or with wire brushes. STERILIZATION: 1. Autoclaving is recommended for the Engler straight handpiece. 2. Clean the handpiece as described above. 3. Lubricate the handpiece as described above . -
Page 15: Micromotor Maintenance
MICROMOTOR MAINTENANCE The Micromotor is capable of speeds up to 35,000 RPM for use in cutting, sectioning and drilling. It contains sealed bearings and does not require any lubrication. The Micromotor has cooling vents at the back of the unit, Do not allow water, oil, or any other substance to enter these vents. Do not block the air vents. Failure to keep debris out of the micromotor will shorten the life of the unit and cause permanent damage. -
Page 16: Scaler Troubleshooting
2. Tip clogged. See #6 above. 3. Check and / or replace O-ring and disc in the inline filter. 4. Water restriction in unit: contact Engler's repair department. 5. If using a Portable Water Bottle, check water level then pump to pressurize the bottle. -
Page 17: Polisher Troubleshooting
2. Damaged footswitch: contact Engler Engineering Corporation. MISCELLANEOUS: 1. Micromotor speed not adjustable (runs at one speed): Return the complete VET II with micromotor. 2. If the prophy cup unscrews, (“flies off”) the prophy angle: Micromotor is rotating in the wrong direction, change direction by rotating the selector on the front of the unit to the opposite direction. -
Page 18: Prophy Angle Cleaning And Maintenance Instructions
PROPHY ANGLE CLEANING AND MAINTENANCE INSTRUCTIONS The prophy angle is a precision engineered dental device. all gear and shaft assemblies are made of high grade stainless steel which must be kept free of debris. If cleaned and lubricated correctly will provide long, trouble-free service. The manufacturer recommends replacing prophy angles at least every 3 to 4 months depending on use. -
Page 19: Water Filter Cleaning Instructions
WATER FILTER CLEANING INSTRUCTIONS SHOULD BE PERFORMED AT LEAST QUARTERLY 1. Turn off water supply to unit or disconnect the male from the female water connector 2. Unscrew filter by firmly holding point “A” in your left hand and point “B” in your right hand. (Refer to Figure) Next, unscrew by simultaneously rotating your left hand away from you and rotating your right hand toward you. -
Page 20: Saddle Valve Assembly
SADDLE VALVE ASSEMBLY Installation Instructions Installation instructions on the following two pages. Page 20 of 28... - Page 21 Page 21 of 28...
-
Page 22: Options For Connecting The Saddle Valve
It is very important that you mount the saddle valve after a shut off valve. Engler Engineering Corporation will not be held liable for any damage including, but not limited to leakage caused by improper installation of our products. It is suggested that a professional plumber make any necessary installations or connections. -
Page 23: Water Tank Instructions
WATER TANK INSTRUCTIONS PT-1 Water Tank DIRECTIONS: 1. Release air pressure by PULLING and TURNING pressure relief valve, located on the side of the bottle. 2. Remove pump and cap assembly. 3. Fill tank with distilled water or medicated solution up to the “FILL LINE” mark. Do NOT fill beyond this line. -
Page 24: Water Tank Care & Maintenance
4. Black particles found in water bottle indicates that the pump assembly is deteriorating. Order new pump assembly from Engler Engineering. Pump assembly has been pre-lubricated prior to shipping. -
Page 25: Optional Vet Ii Accessories
2. DO NOT SUBMERGE IN LIQUIDS, INCLUDING ULTRASONIC SOLUTIONS. 3. Do not heat over 275 ºF (135 ºC). 4. Use only Engler Care Free Prophy Rubber Cups. Other brands will not properly seal the angle, causing premature wear and voiding the warranty. - Page 26 Optional Oiling Accessory Spray lubricant with E-type nozzle for all Engler polisher straight handpieces NET WT. 8.8OZ (249.48 GRAMS) If you have any questions or concerns, please contact us. ENGLER ENGINEERING CORP 800-445-8581 To contact us by INTERNET please use: info@englerusa.com...
-
Page 27: Technical Data
TECHNICAL DATA SCALER: Input Voltage: +5/-10% 120 or 240 VAC Input Frequency: 50/60 Hz. Current (Amperes) 1.25A at 110 VAC, or 0.63 at 220 VAC Transducer Style: Magnetostrictive Operating frequency: 24,200-25,300 Hz. Ultrasonic Generator Data: Auto-Tuned Technology. Variable Power Control WATER: Input Pressure: 30 PSI (min.) 60 PSI (max) POLISHER:... -
Page 28: Dimensions
9 3/4 Lbs., 4.4 Kg Net: 11 Lbs., 5.0 Kg Shipping: For warranty information please visit engler411.com Engler Engineering Corp. 1099 East 47 Street Hialeah, FL 33013 If you wish to fax to us, please use 305-685-7671. Page 28 of 28...
