We have 45,000 LP502030-PCM-NTC-LD-A02554 - EEMB - Lithium Battery Rectangular 3.7V 250mAh Rechargeable in
stock now. Starting at $0.034. This EEMB part is fully warrantied and traceable.
Looking for a discount?
Check out our current promotions!
This coversheet was created by Verical, a division of Arrow Electronics, Inc. ("Verical"). The attached document was created by the part supplier,
not Verical, and is provided strictly 'as is.' Verical, its subsidiaries, affiliates, employees, and agents make no representations or warranties
regarding the attached document and disclaim any liability for the consequences of relying on the information therein. All referenced brands,
product names, service names, and trademarks are the property of their respective owners.
00000005981LF-000
STW1147ASE-TR
EOS Power
STANLEY ELECTRIC
Buy Now
Buy Now
Give us a call
1-855-837-4225
International: 1-555-555-5555
1-415-281-3866
1-415-281-3866
Arrow Electronics,
Arrow Electronics, Inc
Verical Division
9201 East Dry Creek Road
P.O. Box 740970
Centennial, CO 80112
Los Angeles, CA 90074-0970

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STW1147ASE-TR and is the answer not in the manual?

Questions and answers

Related Manuals for Stanley Electric STW1147ASE-TR

Summary of Contents for Stanley Electric STW1147ASE-TR

  • Page 1 We have 45,000 LP502030-PCM-NTC-LD-A02554 - EEMB - Lithium Battery Rectangular 3.7V 250mAh Rechargeable in stock now. Starting at $0.034. This EEMB part is fully warrantied and traceable. 00000005981LF-000 STW1147ASE-TR EOS Power STANLEY ELECTRIC Buy Now Buy Now Looking for a discount?

  • Page 2: Recommended Applications

    STW1147ASE-TR Standard Product Reference Sheet Features Outer Dimension 2.4 x 1.85 x 0.6mm ( L x W x H ) Package Diffused pale yellow color lens ・ Thinner package, White color emitting LED Product features ・ Lead–free soldering compatible ・ RoHS compliant Recommended Applications ・...

  • Page 3: Outline Dimensions

    STW1147ASE-TR Outline Dimensions Unit Weight :5.2mg Tolerance : ± 0.1mm SYMBOL PART NAME REMARKS QTY. ① LED Die InGaN Protection ② Diode ③ Lamp Housing Glass fabric ④ Terminal Au Plating ⑤ Encapsulant Silicone Resin Recommended Pad Unit ： mm...

  • Page 4: Specifications

    STW1147ASE-TR Specifications 【 Product Overview 】 Die Material InGaN Emitting Color White Resin Color( Emitting Area) Diffused Pale Yellow 【 Absolute Maximum Ratings 】 (Ta=25℃) ITEM SYMBOL MAXIMUM RATINGS UNIT Power Dissipation Forward Current Repetitive Peak Forward Current "1ms,1/20duty" ΔI Derate Linearly from "60℃"...
  • Page 5 STW1147ASE-TR Specifications 【 Electro and Optical Characteristics 】 (Ta=25℃) ITEM SYMBOL CONDITIONS MIN. TYP. MAX. UNIT Forward Voltage = 20mA Luminous Intensity = 20mA 1,000 2,000 3,300 Note3 Φ Luminous Flux = 20mA = 20mA 0.31 Note4 Chromaticity coordinate = 20mA 0.32...
  • Page 6 STW1147ASE-TR Specifications 【 Sorting chart For Chromaticity coordinates】 Chromaticity coordinates shall be sorted out into the following chart and each rank parts shall be packed separately when shipping. =20mA, Ta=25℃) Left Down Left Up Right Up Right Down Rank 0.280 0.248...

  • Page 7: Technical Data

    STW1147ASE-TR Technical Data Wavelength vs. Relative Intensity Conditions: Ta = 25℃, I =20mA Wavelength: (nm) Spatial Distribution Conditions: Ta = 25℃, I =10mA x Direction y Direction -100 Relative Intensity: (%) Page : 6 2013/2/12...
  • Page 8 STW1147ASE-TR Technical Data Forward Voltage vs. Forward Current Ambient Temperature vs. Forward Voltage Condition : I = 20mA Condition : Ta = 25℃ Ambient Temp. : Ta (℃) Forward Voltage : V Forward Current vs. Relative Intensity Ambient Temperature vs. Relative Intensity...
  • Page 9 STW1147ASE-TR Technical Data Ambient Temperature vs. Power Dissipation Ambient Temperature vs. Maximum Forward Current Ambient Temp. : Ta(℃) Ambient Temp. : Ta(℃) Ambient Temperature vs. Maximum Forward Current Duty Ratio vs. Max. Forward Current Repetition Frequency : f ≧ 50Hz Condition: Ta = 25℃...
  • Page 10 STW1147ASE-TR Technical Data Pulse Width vs. Maximum Tolerable Peak Current Condition : Ta=25℃ ２ 1kHz 100Hz 50Hz 10kHz 10.0 100.0 1,000.0 10,000.0 100,000.0 Pulse Width : tw (μs) 2013/2/12 Page : 9...
  • Page 11 STW/JS □ /JU □ 11 □ 7AS(E)-TR Soldering condition 【Soldering Precaution】 (acc.to EIAJ-4701/300) 1. Heat stress during soldering will influence the reliability of LEDs, however that effect will vary on heating method. Also, if components of varying shape are soldered together, it is recommended to set the soldering pad temperature according to the component most vulnerable to heat (e.g., surface mount LED).
  • Page 12 STW/JS □ /JU □ 11 □ 7AS(E)-TR Soldering condition 4. If soldering manually, Stanley recommends using a soldering iron equipped with temperature control. During the actual soldering process, make sure that the soldering iron never touches the LED itself, and avoid the LED's electrode heating temperature reaching above the heating temperature of the solder pad.

  • Page 13: Handling Precaution

    STW/JS □ /JU □ 11 □ 7AS(E)-TR Handling Precaution 【 For Electric Static Discharge ( ESD) 】 This kind of LED lamp is highly sensitive to surge voltage generated by the On/Off status change and discharges of static electricity through frictions with synthetic materials, which may cause severe damage to the die or undermine its reliability.
  • Page 14 STW/JS □ /JU □ 11 □ 7AS(E)-TR Handling Precaution 【 Other Precautions 】 1. Stanley LED Lamps have semiconductor characteristics and are designed to ensure high reliability. However, the performance may vary depending on usage conditions 2. Absolute Maximum Ratings are set to prevent LED lamps from failing due to excess stress( temperature, current, voltage, etc.).
  • Page 15 STW/JS □ /JU □ 11 □ 7AS(E)-TR Handling Precaution 【 Handling Precautions for Product Mounting 】 ＜ Recommendation ＞ 1. Picking up point with nozzle: Lamp housing of the product ( area) (Shown below) The picking up point should be within lamp housing portion, because the silicone resin used for the lens is soft.

  • Page 16: Packaging Specifications

    STW/JS □ /JU □ 11 □ 7AS(E)-TR Packaging Specifications This product is baked (moisture removal) before packaging, and is shipped in moisture-proof packaging (as shown below) to minimize moisture absorption during transportation and storage. However, with regard to storing the products, Stanley recommends the use of dry-box under the following conditions is recommended. Moisture-proof bag as the packaging is made of anti-static material but packaging box is not.

  • Page 17: Packaging Specification

    STW/JS □ /JU □ 11 □ 7AS(E)-TR Packaging Specification 【Moisture-proof Packaging Specification】 Fastener for re-storage after opening bag ① Customer's opening position Product Label Heat Sealing position (after product being put in) (Desiccant with indicator for moisture level is enclosed.) SYM.
  • Page 18 STW/JS □ /JU □ 11 □ 7AS(E)-TR Packaging Specifications 【 Packing box 】 (RoHS ・ ELV Compliant) Outline dimension Box Type Capacity of the box L × W × H (mm) 280 × 265 × 45 Type A 3 reels 310 ×...
  • Page 19 STW/JS □ /JU □ 11 □ 7AS(E)-TR Packaging Specifications 【 Label Specification】 ( acc.to JIS-X0503(Code-39) Product label A. Parts number B. Bar-code for parts number C. Parts code (In-house identification code for each parts number) D. Packed parts quantity E. Bar-Code for packed parts quantity F.
  • Page 20 STW/JS □ /JU □ 11 □ 7AS(E)-TR Taping and Reel Specifications (acc.to JIS-C0806-03） 【Appearance】 Note "-TR" means cathode side of LEDs should be placed on the sprocket-hole side. Items Specifications Remarks Cover-tape shall be longer The end of cover-tape shall be Cover-tape than 320mm without carrier-tape held with adhesive tape.
  • Page 21 STW/JS □ /JU □ 11 □ 7AS(E)-TR Taping and Reel Specifications (acc.to JIS-C0806-03） 【 Qty. per Reel】 4,000parts/reel Minimum Qty. per reel might be 500 parts when getting less than 4,000 parts. In such case, parts of 500-unit-qty. shall be packed in a reel and the qty. shall be identified on the label. 【...
  • Page 22 STW/JS □ /JU □ 11 □ 7AS(E)-TR Taping and Reel Specifications (acc.to JIS-C0806-03） Unit ：mm 【Taping Dimensions】 ① ② 【Reel Dimensions】 ③ SYM. PART NAME REMARKS ① Carrier-tape with ESD protection ② Cover-tape with ESD protection ③ Carrier-reel with ESD protection Page : 21 Page : 21 2013/2/12...
  • Page 23 STW/JS □ /JU □ 11 □ 7AS(E)-TR Lot Number Notational System ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① - 1digit ： Production Location (Mark identify alphabet) ② - 1digit ： Production Year (Last digit of Production Year 2009 → 9,2010 → 0,2011 → 1, ･･･ ) ③...
  • Page 24 Correspondence to RoHS ・ ELV instruction STW/JS □ /JU □ 11 □ 7AS(E)-TR This product is in compliance with RoHS・ELV. Prohibition substance and it's criteria value of RoHS・ELV are as follows. ・ RoHS instruction …… Refer to following (1) ～ (6). ・...
  • Page 25 STW/JS □ /JU □ 11 □ 7AS(E)-TR Reliability Testing Result 1. Reliability Testing Result Test Item Criteria Test Condition Duration Failure EIAJ ED-4701 Operating Life Ta=25 ℃ Maximum Rated Current 1,000h 0 /20 /100(101) High Temperature EIAJ ED-4701 Ta=85 ℃ Maximum Rated Current ( ※ ) 1,000h 0 /20 /100(101)
  • Page 26 STW/JS □ /JU □ 11 □ 7AS(E)-TR Special Notice to Customers Using the Products and Technical Information Shown in This Data Sheet 1) The technical information shown in the data sheets are limited to the typical characteristics and circuit examples of the referenced products. It does not constitute the warranting of industrial property nor the granting of any license.
