AirBurners S223E Operating Manual

S-series air curtain burner

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Operating Manual

S-Series Air Curtain Burner

Equipped With

Electric Motor and VFD Speed Control

S116E S119E S220E S223E, S327 S330E

Above Ground Self Contained

Refractory Walled Air Curtain Burner

"Better Economically - Better Environmentally"

Factory and Main Office

Visit Our Website at:

Air Burners, Inc.

AirBurners.com

4390 SW Cargo Way

Palm City, FL 34990

Phone: 772-220-7303

888-566-3900

E-mail: support@airburners.com

The words Air Burners and the Air Burners Logo are Registered Trademarks of Air Burners, Inc.

(Vers. 08.30.2022)

Table of Contents

Need help?

Do you have a question about the S223E and is the answer not in the manual?

Questions and answers

Summary of Contents for AirBurners S223E

Page 1 Operating Manual S-Series Air Curtain Burner Equipped With Electric Motor and VFD Speed Control S116E S119E S220E S223E, S327 S330E Above Ground Self Contained Refractory Walled Air Curtain Burner "Better Economically - Better Environmentally" Factory and Main Office Visit Our Website at: Air Burners, Inc.
Page 2 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL CAUTION! All electrical connections and installations must be made by a licensed local electrician according to re- spective codes and regulations by the local compe- tent authorities. The installation must include a properly sized grounding rod to earth connected to the provided grounding lug on the FireBox.
Page 3: Table Of Contents
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL INDEX PRINCIPLE OF AIR CURTAIN BURNING ........Page 1 GENERAL DESCRIPTION OF S-SERIES ........Page 2 SAFETY CONSIDERATIONS ............Page 5 HOW TO SET UP THE MACHINE ........... Page 8 SITE PREPARATION ...............
Page 4 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL S220E Electric Series FireBox S327 (Vers.08.30.2022) Page iii...
Page 5: Principle Of Air Curtain Burning
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL PRINCIPLE OF AIR CURTAIN INCINERATION OPERATION Air curtain incinerators are designed primarily as a pollution control device. Using a Diesel engine or electric motor driven fan, these machines generate a curtain of air with a very particular mass flow and velocity.
Page 6: General Description Of S-Series
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL GENERAL DESCRIPTION S-SERIES The self-contained refractory walled air curtain system is manufactured as an over-the- road transportable combustion system designed to reduce clean wood waste and veg- etative growth to ash in a safe, controlled burning process without excessive particu- late emissions.
Page 7 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL GENERAL DESCRIPTION S-SERIES (E-VERSION) When delivered to a job site, the S-Series machine is ready for use as soon as it is off- loaded and properly connected to an appropriate electrical power source. The entire system is built on a skid type base frame which is designed for easy movement over the ground.
Page 8 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL FireBox in Operation: Particulate Matter (PM) trapped by Air Curtain and re-burned S327 Rear Doors Open IMPORTANT: Notice, how dirt is placed all around the inside bottom to close any openings under the skids that may be caused by uneven terrain.
Page 9: Safety Considerations
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL SAFETY CONSIDERATIONS READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN BURNING OPERATIONS The S-Series machine operator is dealing with fire on a daily basis; it is very important that each and every individual involved with the machine be alert and practice very rig- id safety precautions.
Page 10 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL 4) NEVER use highly combustible materials to light the unit. Highly combustible materials such as gasoline, refined spirits, etc. ignite at an ex- plosive rate which may cause serious injury or death. The safest method to start the fire in the box is to use materials such as paper and kindling wood.
Page 11 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL 7) Personal Safety Operators need to be aware of the following potential hazards: A) Flying hot embers being released from the fire. Operators or anyone within the 100 foot radius of the fire should wear appropriate fire resistant clothing.
Page 12: How To Set Up The Machine
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL HOW TO SET UP THE MACHINE A) POSITIONING THE UNIT The S-Series units are totally self-contained and ready to use upon delivery to the job site. The electrically powered S-Series units are built on a skid base that is designed to facilitate dragging the unit into position near the on-site external electric power connec- tion and grounding rod.
Page 13 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL HOW TO SET UP THE MACHINE C) STARTING/SHUT-DOWN Electric Motor and VFD Starting: Ensure that an appropriate ground wire is properly connected to the grounding lug (See Page 23) and the earth grounding rod.
Page 14: Site Preparation
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL SITE PREPARATION THE GOALS TO GOOD SITE PREPARATION ARE: To place the wood piles for easy access. To sort the waste wood pile. To organize the inflow of new wood waste. When locating the FireBox;...
Page 15 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL SITE PREPARATION Faster operation through staging the wood piles Air Burners FireBoxes were designed primarily as a pollution control device, but oper- ated correctly they will burn clean wood two or three times faster than open burning. To achieve the best throughput the fire must remain at the highest temperature possible.
Page 16 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL SITE PREPARATION The “Two Pile System” For an efficient operation you would have two piles: The first pile or “main debris” pile, is the material being generated from the landfill or transfer station operation and is located away from the ember path, but with good ac- cess to your loading machinery.
Page 17: Loading And Starting A Fire
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL LOADING AND STARTING THE FIREBOX LOADING AN S-SERIES UNIT You can load the FireBox from either side, but we recommend loading from the manifold side because (1) it is safest and (2) it tends to in- crease the life of the manifold, as it is reduces the chance for it to be accidentally damaged.
Page 18 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL LOADING AND STARTING THE FIREBOX Once you have this smaller material loaded and your accelerant added (if used) load some larger, heavier material on top, such as logs or big branches. Load these heavier materials, also from your “good wood”...
Page 19 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL LOADING AND STARTING THE FIREBOX To minimize start-up smoke you can: Use your driest materials. Ensure your materials do not retain dirt or sand. Use diesel fuel to accelerate the light up. COLD START LIGHTING 1.
Page 20 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL LOADING AND STARTING THE FIREBOX HOT START A hot start uses the coals from the previous day’s burning operation. Depending on how much ash is in the unit a hot start can be done once or twice before the unit will need to be emptied.
Page 21: How To Feed A Fire
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL HOW TO FEED A FIRE It will generally take 30 minutes for the fire to build to a point where the temperatures are sufficient for the unit to be operating with minimal smoke. 1.
Page 22: Shutdown
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL SHUTDOWN HOW TO BURN FIRE DOWN FOR SHUT DOWN All loading should stop one or two hours before you intend to put the fire out. As the fire burns down, maintain the air speed until the box begins to smoke. As the smoke increases reduce the air speed in increments to Positions Normal 1 and the Cool Down Position.
Page 23: Ash Removal
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL ASH REMOVAL HOW TO EMPTY THE S-SERIES UNITS We recommend removing the ash every morning before burning operations begin. This will give you maximum capacity in the FireBox and the ash will be easier to han- dle.
Page 24: Troubleshooting
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL TROUBLESHOOTING 1. Fire will not start. Material in FireBox has too much air space. To correct, load heavy material such as stumps to make the lower material pack down. Use torches and light from the bot- tom so the fire burns up.
Page 25: Maintenance And Care Of The Unit
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL MAINTENANCE AND CARE A. Daily Check List: 1. Ensure that the ground wire is properly connected to the FireBox grounding lug and the grounding rod and that the wire gauge meets AWG of local code.
Page 26: Vfd Servicing Specifications & Motor/Vfd Wiring
20V by the VFD. Models S330E and S327E are fitted with a 75 HP (56 kW) and models S223E, S220E, S119E and S116E are fitted with a 30 HP (22.4 kW) premium three-phase motor.
Page 27 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL Default Shut-down of VFD and Motor / VFD Wiring (Continued) The external power lead of proper gauge (AWG) must be connected to the power distribution block in the up- per left corner (see right photo;...
Page 28 7) Allow the material to harden overnight before placing the FireBox back into service. After the compound has hardened operate the FireBox under nor- mal conditions. Contact Air Burners, Inc., should you require assistance with this maintenance tasks. Send Email to support@airburners.com, call 772-220-7303 or 888-566-3900 (Customer Support) Page 24 of 25...
Page 29: Lifting Points
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL LIFTING POINTS There are four designated lifting pad eyes for lifting all FireBox units by crane, two on each side. Only lift by attaching straps or cables to these four pad eyes. Their locations are marked with yellow lifting point labels with up-arrows.
Page 30: Checking Coupling Alignment
Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL APPENDIX A CHECKING COUPLING ALIGNMENT This Technical Memorandum covers FireBox Models equipped with Dodge Raptor Couplings. The S327 and S330 use Size E30 (Air Burners Replacement Part Number 5000-2120) and all other FireBox models use Size E20 (Air Burners Replacement Part Number 5000-5123).
Page 31 Series (E) Refractory Walled Air Curtain Burner (Electric Motor & VFD) OPERATING MANUAL APPENDIX A CHECKING COUPLING ALIGNMENT Step 3 Verify Angular Alignment of Hubs 1. Measure the distance “B” between the hubs with calipers or other appropriate tool at four places on the outer diame- ter of the hub 90°...
