AirBurners BurnBoss T24 Operating Manual

Trailer mounted refractory walled air curtain burner

Hide thumbs Also See for BurnBoss T24:

Operating manual (35 pages)

Operating manual (36 pages)

Operating manual (34 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

Trailer Mounted Refractory Walled Air Curtain Burner

Factory and Main Office

Air Burners, Inc.

4390 SW Cargo Way

Palm City, FL 34990

Phone: 772-220-7303

888-566-3900

E-mail: support@airburners.com

The words Air Burners and the Air Burners Logo are Registered Trademarks of Air Burners, Inc.

Subject to change without notice. Dimensions & metric conversions rounded. The words Air Burners, BurnBoss,

CharBoss, TrackBoss and the Air Burners Logo are Registered Trademarks of Air Burners, Inc.

Operating Manual

BurnBoss

Equipped With Kubota Z482-E4 Diesel Engine

"Better Economically - Better Environmentally"

T24

Visit Our Website at:

Visit Our Website at

AirBurners.com

(Vers. 05.05.2023b)

Table of Contents

Need help?

Do you have a question about the BurnBoss T24 and is the answer not in the manual?

Questions and answers

Summary of Contents for AirBurners BurnBoss T24

Page 1 Phone: 772-220-7303 Phone: 772-220-7303 Phone: 772-220-7303 888-566-3900 888-566-3900 888-566-3900 E-mail: support@airburners.com E-mail: support@airburners.com E-mail: support@airburners.com © 2012-2022 Air Burners, Inc. © 2023 Air Burners, Inc. All Rights Reserved. © 2023 Air Burners, Inc. All Rights Reserved. The words Air Burners and the Air Burners Logo are Registered Trademarks of Air Burners, Inc.
Page 2 PLEASE READ ALL WARNING NOTICES BEFORE OPERATING THE BURNBOSS T24. Caution When towing the street-legal BurnBoss T24 on public roadways observe all rules and regulations of the compe- tent authorities and travel at a safe speed. Ensure that the towing vehicle and its trailer hitch system are of the proper size and type to safely handle the BurnBoss trailer weight (GVWR) of approximately 10,000 lb.
Page 3: Table Of Contents
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL INDEX PRINCIPLE OF AIR CURTAIN INCINERATION ......Page 1 GENERAL DESCRIPTION OF THE BURNBOSS ......Page 2 SAFETY CONSIDERATIONS ............Page 5 HOW TO TRANSPORT THE MACHINE ........... Page 8 HOW TO SET UP THE MACHINE ...........
Page 4 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL “BurnBoss” Trailer Mounted FireBox Page iii (Vers. 05.05.2023)
Page 5: Principle Of Air Curtain Incineration
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL PRINCIPLE OF AIR CURTAIN INCINERATION OPERATION Air curtain burners are designed primarily as a pollution control device. Using a diesel engine driven fan, these machines generate a curtain of air with a very particular mass flow and velocity. This cur- tain of air acts as a trap over the top of an earthen trench or thermal ceramic lined firebox.
Page 6: General Description Of The Burnboss
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL ® GENERAL DESCRIPTION OF BURNBOSS The BurnBoss design is intended to allow for the use of our self-contained refractory walled air cur- tain system design, but mounted on a trailer frame for ease of mobility. The standard S-Series machines are offered in several sizes as indicated below.
Page 7 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL GENERAL DESCRIPTION OF BURNBOSS The BurnBoss is a proven design that adds mobility to the Air Burners S-Series FireBox line of ma- chines. When delivered to a job site, the machine is ready for use as soon as it is off-loaded. The firebox system (burn chamber) is built on a patented trailer frame that allows the firebox to be raised and lowered for easy movement over the ground.
Page 8 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL T24 BurnBoss in Full Operation T24 BurnBoss - Trailer Mounted FireBox Page 4 of 30 (Vers. 05.05..2023)
Page 9: Safety Considerations
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SAFETY CONSIDERATIONS READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN BURNING OPERATIONS The BurnBoss operator is dealing with fire on a daily basis; it is very important that each and every individual involved with the machine be alert and practice very rigid safety precautions.
Page 10 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL 4. NEVER use highly combustible materials to light the wood waste. Highly combustible materials such as gasoline, refined spirits, etc. ignite at an explosive rate which may cause serious injury or death. The safest method to start the fire in the firebox is to use materials such as kindling wood.
Page 11 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL 7. Personal Safety (Personal Protective Equipment – PPE) Operators need to be aware of the following potential hazards: a. Flying hot embers being released from the fire. Operators or anyone within the 100 ft. radius of the fire should wear appropriate fire resistant clothing.
Page 12: How To Transport The Machine
OPERATING MANUAL HOW TO TRANSPORT THE MACHINE A. Towing BurnBoss T24 Towing the T24 BurnBoss is like towing any other “heavy” trailer. It is important that the frame rails are as level as possible when hooked to the truck. The T24 comes equipped with electric brakes, be sure your truck has an appropriate brake controller.
Page 13 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL HOW TO TRANSPORT THE MACHINE B. LOWERING THE FIREBOX FOR USE 1. The firebox must be on level ground. 2. The machine should be disconnected from the tow vehicle. 3.
Page 14 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL C. RAISING THE FIREBOX FOR TRANSPORT 1. Connect machine to tow vehicle. 2. Raise jack stand. 3. Raise the firebox until it stops. 4. Immediately move the machine forward if there are hot ashes in the firebox to prevent tire dam- age by hot embers.
Page 15: How To Set Up The Machine
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL HOW TO SET UP THE MACHINE A. POSITIONING THE UNIT The BurnBoss unit is self-contained and ready to use upon delivery to the job site. 1. The BurnBoss must be setup on level ground. 2.
Page 16 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL B. PRE-OPERATION CHECKS: 1. Air filter for cleanliness (VERY IMPORTANT) 2. Engine oil level and hydraulic oil level 3. Engine coolant level and antifreeze rating 4. Diesel fuel level (Check fuel gauge) 5.
Page 17 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL HOW TO SET UP THE MACHINE C. STARTING (Kubota Z482-E4) 1. Turn the speed control knob clockwise to ensure engine speed is at idle. 2. If needed, turn key switch counterclockwise to the PREHEAT position for not more than 5 seconds.
Page 18: Site Preparation
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SITE PREPARATION THE GOALS TO GOOD SITE PREPARATION ARE: To place the BurnBoss for easy access. To sort the waste wood pile. To organize the inflow of new wood waste. When towing and positioning the BurnBoss at the burn site: 1.
Page 19 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SITE PREPARATION FASTER OPERATION THROUGH STAGING THE WOOD PILES Air Burners air curtain burners were designed primarily as a pollution control device but operated correctly they will burn clean wood two or three times faster than open pile burning. To achieve the best throughput the fire must remain at the highest temperature possible.
Page 20 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SITE PREPARATION THE “TWO PILE SYSTEM” For an efficient operation you would have two piles: The first pile or “Main Debris” Pile, is the material being generated from the land clearing or forest clearing operation and is located away from the ember path but with good access to your loading machinery.
Page 21: Loading And Starting A Fire
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL LOADING AND STARTING THE BURNBOSS THE GOALS IN STARTING A BURNBOSS ARE: To achieve an even fire across the length of the box. To start the fire from the bottom of the initial pile. To build a hot base fire.
Page 22 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL LOADING AND STARTING THE BURNBOSS 7. Once you have this smaller material loaded and your accelerant added (if used) load some larger heavier material on top, such as logs or big branches. Load these heavier materials, also from your “Good Wood”...
Page 23 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL LOADING AND STARTING THE BURNBOSS HOT START A hot start uses the coals from the previous days burning operation. Depending on how much ash is in the unit, a hot start can usually be done only once before the unit will need to be emptied. The more ash in the BurnBoss that you start with the LESS room you have for burning new materials.
Page 24: How To Feed A Fire
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL HOW TO FEED A FIRE It will generally take 30 minutes for the fire to build to a point where the temperatures are sufficient for the unit to be operating with minimal smoke. 1.
Page 25: Shutdown
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SHUTDOWN HOW TO BURN FIRE DOWN FOR SHUTDOWN All loading should stop one or two hours before you intend to put the fire out. As the fire burns down, maintain the air speed until the box begins to smoke. As the smoke increas- es, reduce the air speed in increments of about 300 RPM.
Page 26: Ash Removal
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL ASH REMOVAL HOW TO EMPTY THE BURNBOSS We recommend removing the ash every morning before burning operations begin. This will give you maximum capacity in the firebox and the ash will be easier to handle. The BurnBoss will operate with up to 1½...
Page 27: Troubleshooting
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL TROUBLESHOOTING 1. Fire will not start. Material in fire box has too much air space. To correct, load heavy material such as stumps to make the lower material pack down. Use torches and light from the bottom, so the fire burns up. 2.
Page 28: Maintenance, Care And Safety Checks
Ensure that the hitch pins with chains that are part of the actuator travel safety pins are in place and properly installed. Contact Air Burners, Inc., should you require assistance with any of these necessary maintenance tasks. Send Email to support@airburners.com, call 772-220-7303 or 888- 566-3900 (Customer Support) Consult the supplied Kubota Engine Service Manual.
Page 29 ® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL MAINTENANCE, CARE AND SAFETY CHECKS 1. FIRST WEEK OF OPERATION CHECK LIST: AXLE MAINTENANCE This maintenance work requires that the trailer be chocked for safety, raised and supported by suita- ble jacks placed under the frame to a height that will relax the torsion springs and removal of each wheel.
Page 30: Minor Repairs Of Refractory Panels
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL THERMAL-CERAMIC PATCHING COMPOUND THERMAL-CERAMIC WET PRE-MIX PART # 6900-1003 For minor repair of Air Burners BurnBoss refractory panels. Directions: 1. Cracking of the panels is normal as they flex in the heat. Filling the cracks every 6 months or as needed will extend the life of your Thermo-ceramic Panels.
Page 31: Servicing Specifications
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL SERVICING SPECIFICATIONS Parts List for Routine Service of Kubota Industrial Diesel Engine Z482-E4 Also Refer to Engine Manufacturer’s Service Manual for Engine Service Details (Engine should be serviced after first 50 hours, then every 100 hours of operation) Description Air Burners P/N Manufacturer’s P/N...
Page 32: Trailer Wiring Diagram
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL Page 28 of 30 (Vers. 05.05..2023)
Page 33: 7-Blade Rv-Type Connector Wiring
® BurnBoss T24 Air Curtain Burner (Kubota Z482-E4 Engine) OPERATING MANUAL Page 29 of 30 (Vers. 05.05..2023)
Page 34: Vin No. And Trailer Tire Placards (2018/19 Models)
OPERATING MANUAL VIN NUMBER AND TIRE PLACARDS BurnBoss T24 machines built after February 2018 are street legal and have a Manufacturer’s Certi- fication Label for a Trailer (VIN placard) and a tire placard. They are located on the left trailer tongue near the hitch.
