Quick Start Guide
Usage
1
Gimbal Pro is meant for manual use and Xbot Go is designed for auto
tracking and recording.
Securing Your Phone on the Gimbal
2
Follow the following figure to attach your phone to the gimbal, and
ensure it is tightly secured and centered on the phone clamp panel.
Top
Press the power button for one second to power on.
CONNECTING BLUETOOTH FOR USING CAMERA
Power on the gimbal and activate Bluetooth on your phone.
Access to your phone's Bluetooth settings and select "GP7-xx" to
connect the device.
INSTRUCTIONS FOR THE 4 MODES:
All Follow (AF):
1
The Roll axis is locked, the Pan (left/right) and Tilt (up/down) will
follow the movement of the handle.
Operation Instructions
Notch
POWER ON
GIMBAL PRO
1
Advertisement
Table of Contents
Related Manuals for GIMBAL PRO
Summary of Contents for GIMBAL PRO
- Page 1 Operation Instructions Quick Start Guide Usage Gimbal Pro is meant for manual use and Xbot Go is designed for auto tracking and recording. Securing Your Phone on the Gimbal Follow the following figure to attach your phone to the gimbal, and ensure it is tightly secured and centered on the phone clamp panel.
- Page 2 The Roll, Pan, and Tilt axes are all locked in position, and the phone camera direction remains fixed. First Person View (FPV) Mode : In this mode, the gimbal follows the handle's movement in all three axes (Roll, Pan, and Tilt) and keeps the camera pointed in the direction of the handle.
- Page 3 Gimbal Pro app is in use). • Triple press —— Capture photos during video recording (when Bluetooth is connected and the Gimbal Pro app is in use) Joystick： Use the joystick to control the gimbal's movement in the...
-
Page 4: Other Features
• Underslung mode: Hold the gimbal upside down to capture images from a low position. • Side grip mode: Rotate the gimbal 90 degrees to the right or left to switch from upright to side grip mode, which works in both landscape and portrait modes. - Page 5 GIMBAL PRO Operation Instructions ※ The Gimbal Pro app requires iOS 12.0 or later for Apple devices, and Android 6.0 or later for Android devices. Android Gimbal Pro App Gimbal Pro App CONNECT TO THE GIMBAL PRO APP Enter the phone's "Settings".
-
Page 6: Specification
GIMBAL PRO Operation Instructions SPECIFICATION VALUE Tilt Axis Movement Angle 160° Roll Axis Movement Angle 325° Pan Axis Movement Angle 340° Product Weight 362g (excluding phone) Operating Temperature 0°C - 40°C Controllable Tilt Angle +30°/-30° Controllable Roll Angle +90°/-90° Controllable Pan Angle +240°/-100... -
Page 7: Storage And Maintenance
• Ensure that external forces do not obstruct the gimbal's rotation, as this may result in a failure and a "dinging" sound. • Keep the handle stable when the gimbal is powered on, and avoid shaking it to prevent failure. Use a tripod for stable operation.
