Summary of Contents for Minolta MNCD350X
- Page 2 The Minolta MNCD350X allows you to record video when mounted to your car’s windshield in a wide, large angle.
-
Page 3: Getting Started
1. GETTING STARTED 1.1 Overview USB Port Display Mount Port Charging LED OK | Record Power | IR Mode Lock File Status LED Menu Down Lens Speaker Memory Card Slot Lens IR LEDs... - Page 4 1.2 Button and Functions Explanation Function Description Shows the current view and menu, options and different Display statuses of each mode. Tap once to power on, press and hold for 3 seconds to Power power off. Tap once to cycle between Video, Photo and Playback Mode modes.
- Page 5 1.3 Memory Card Insertion and Removal 1. Ensure the camcorder is powered off. 2. Insert a MicroSD memory card into the MicroSD card slot with the gold pins facing the display screen. Do not force it through the MicroSD card into the slot as it can only be inserted in one direction.
- Page 6 1.5 Startup 1.5.1 In-Car Use Connect the included auxiliary DC power adaptor to your car’s power port. Plug the USB plug into the camcorder’s USB port. Charging will begin immediately. Please note that the camcorder’s internal battery has a very limited capacity and is only intended for use in emergency use situations.
- Page 7 To disable the IR LED lights, short-press the POWER button again. You will notice that the IR light indicator on the screen is no longer showing, instead a sun icon will show. Note: The IR LEDs can also be enabled or disabled during a recording. 2.
-
Page 8: Camcorder Operation
3. CAMCORDER OPERATION Once you have inserted the MicroSD memory card and plugged your camcorder into a power source, your camcorder will automatically power on. You may also manually power your camcorder on or off by pressing the POWER button for 2 seconds. There are 3 operation modes available for use. - Page 9 3.4 Main Screen and Icons Explanation VIDEO MODE 1. VIDEO Mode 2. Recording Active 3. Night Vision Mode Off 4. Park Mode 5. Recording Time Elapsed 6. Video Size (Resolution) 7. Memory Card Inserted 8. Battery Level 9. Current Time 10.
- Page 10 4. MENU & SETTINGS INTERFACE 4.1 Video Mode Settings Overview Your camcorder comes preset with some user-adjustable settings to fine tune and customize how you would like your videos to be captured. The settings are already optimized and preset for the easiest experience. Before you begin, ensure you are in VIDEO mode .
- Page 11 1. In VIDEO mode, press the MENU button. Select ‘Loop Recording’ by using the UP or DOWN buttons. Press the OK button to enter the ‘Loop Recording’ submenu. 2. Press the UP or DOWN buttons again to navigate the submenu and select a setting. You can select from Off, 1 Minute, 3 Minutes and 5 Minutes.
- Page 12 4.1.5 Date & Time Stamp This setting allows you to imprint a date & time onto your recorded video files. Once a video file is recorded with the imprint, the imprint cannot be removed. 1. In VIDEO mode, press the MENU button. Select ‘Date & Time Stamp’ by using the UP or DOWN buttons.
- Page 13 4.2 Photo Mode Settings Overview Your camcorder comes preset with some user-adjustable settings to fine tune and customize how you would like your photos to be captured. The settings are already optimized and preset for the easiest experience. Before you begin, ensure you are in PHOTO mode .
- Page 14 To exit the settings menu, press the MENU button twice and your camcorder will return to the main status screen of the current mode. 4.2.3 Photo Quality This setting determines the level of compression the camera uses when saving photos to your memory card.
- Page 15 4.2.6 ISO This setting determines the light sensitivity in the photos being captured. 1. In PHOTO mode, press the MENU button. Select ‘ISO’ by using the UP or DOWN buttons. Press the OK button to enter the ‘ISO’ submenu. 2. Press the UP or DOWN buttons again to navigate the submenu and select a setting. You can select from Auto, 100 and 200.
- Page 16 1. In PHOTO mode, press the MENU button. Select ‘Quick Review’ by using the UP or DOWN buttons. Press the OK button to enter the ‘Quick Review’ submenu. 2. Press the UP or DOWN buttons again to navigate the submenu and select a setting. You can select from Off, 2 Seconds and 5 Seconds.
- Page 17 4.3 Playback Mode Settings Overview Before you begin, ensure you are in PLAYBACK mode . From the main screen, press the MODE button two times. The current mode will be displayed in the upper right corner of the display. To cycle through the different modes, simply press the MODE button again. 4.3.1 Delete Your camcorder gives you the option of deleting your recording video and photo files right from your camcorder.
- Page 18 4.4 Setup Settings Menu Overview The Setup Settings Menu can be accessed while in any mode. From the main screen, press the MENU button twice. The menu will move right and switch tabs from the current mode’s icon to the Setup Settings menu.
- Page 19 3. Press the UP or DOWN buttons to change the any of the values of the date and time. When you are satisfied with the highlighted value, press the OK button to confirm that value and proceed to the next value. Once you are completed, press the MENU button once to save your setting and exit.
- Page 20 2. Press the UP or DOWN buttons again to navigate the submenu and select a setting. You can select from Off and On. 3. Press the OK button to confirm your selected setting. To exit the settings menu, press the MENU button once and your camcorder will return to the main status screen of the current mode.
- Page 21 4.4.9 Format Memory Card This setting allows you to erase all video and photo files stored on your memory card. 1. In any mode, press the MENU button twice. Select ‘Format Memory Card’ by using the UP or DOWN buttons. Press the OK button to enter the ‘Format Memory Card’ submenu.
- Page 22 5. MEDIA TRANSFER & RESET Connecting to a Computer Your camcorder can connect to a computer to transfer photo and video files for viewing and editing, or to use the camcorder as a web cam. To connect the camcorder to your computer, insert the small end of the USB plug into the camcorder’s port, and the larger end into the USB port on your computer.
-
Page 23: Technical Specifications
Built-in Battery during power outage Minolta is a registered trademark of JMM Lee Properties, LLC and is used in the United States by Elite Brands Inc. under license. 40 Wall Street, 61st Floor, New York, NY 10005 USA • Tel: 800-441-1100 www.minoltadigital.com •...
