Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
il tuo prodotto tra le
migliori offerte di Lavastoviglie
Contents
1. Description of the controls _______________________________ 2
2. Operating instructions __________________________________ 15
3. Cleaning and maintenance ______________________________ 27
4. Troubleshooting ______________________________________ 32
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need use your dishwasher safely, correctly and in the
most satisfactory manner.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
USER INSTRUCTIONS: these consist of recommendations for using
the appliance, a description of its controls and of the correct cleaning
and maintenance procedures.
Smeg STA4515
o cerca
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the STA4515 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg STA4515

Summary of Contents for Smeg STA4515

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg STA4515 o cerca il tuo prodotto tra le migliori offerte di Lavastoviglie Contents 1. Description of the controls _______________________________ 2 2. Operating instructions __________________________________ 15 3. Cleaning and maintenance ______________________________ 27 4.

  • Page 2: Description Of The Controls

    User instructions 1. Description of the controls 1.1 Upper panel All the dishwasher controls are grouped on the upper panel. Switching on, programming, switching off, etc. are only possible when the door is open. The panel shown is given as example: the form of the lights and buttons may vary depending on the model.
  • Page 3 User instructions Information displayed INFORMATION DISPLAY (on some models only) Program duration Remaining program time Delayed start: 1-24 hours Error message: Err <<OPTIONS (6)>> Depending on the model, this zone may contain the information display and one or more of the following options, identified by symbols and described in more detail later in the manual.
  • Page 4 User instructions SWITCHING ON, SETTING THE WASHING PROGRAM STARTING THE PROGRAM Press the ON/OFF button (1); the PROGRAM INDICATOR LIGHT  (2) will come on; Keep pressing the PROGRAM SELECTION button (3) until the  indicator light for the required program lights up; ...
  • Page 5 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER MINUTES POWER CUTLERY PROGRESS WATER & SYMBOL kWh (1) LITRES 1 RAPID 27’ Dishes with light dirt, Wash at 38°C 0,70 washed immediately after Rinse at 50°C Wash at 45°C 2 GLASS Glass, china and mixed Cold rinse...
  • Page 6 User instructions QUICK TIME PROGRAMS (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME PROGRAM LOAD CROCKERY AND NUMBER E PROGRESS MINUTI WATER POWER CUTLERY SYMBOL LITRES kWh (1) 6 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load DELICATE Cold prewash...
  • Page 7 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER MINUTES POWER CUTLERY PROGRESS WATER & SYMBOL kWh (1) LITRES 1 RAPID 27’ Dishes with light dirt, Wash at 38°C 0,70 washed immediately after Rinse at 50°C AUTO 45-65 When the "...
  • Page 8 User instructions QUICK TIME PROGRAMS (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME PROGRAM LOAD CROCKERY AND NUMBER E PROGRESS MINUTI WATER POWER CUTLERY SYMBOL LITRES kWh (1) 6 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load DELICATE Cold prewash...
  • Page 9 User instructions NOTES AND REFERENCES Only run the soak program with partial loads. The options cannot be used with the soak program. The ENERSAVE option (if featured) cannot be used with soak, ultra clean, or any programs which do not include the final drying stage. Standard program under EN 50242.
  • Page 10 User instructions 1.2 Wash programs Before starting a wash program check that: The water supply tap is open.  The softener container contains regenerating salt.  The correct amount of detergent has been added to  the dispenser. The baskets have been correctly loaded. ...
  • Page 11 User instructions SPREAD HALF LOAD Suitable when there are not many dishes to be washed, it saves energy and reduces the program duration. Spread dishes across both baskets; the detergent dispenser should be loaded with less than the normal amount for a full load. ENERSAVE Allows energy consumption to be further reduced by opening the door automatically for better drying at the end of the wash cycle, ensuring...
  • Page 12 User instructions These products are not suitable for use with excessively “hard” water. If the hardness level set is higher than H3, when the option is activated the relative light flashes to indicate that the product is being used incorrectly; the dishwasher will still work, but washing results may be poor.
  • Page 13 User instructions CANCELLING A PROGRAM IN PROGRESS Open the door, taking care to avoid splashes of water, and hold  down the PROGRAM SELECTION (3) button for a few seconds until the indicator lights for programs 4 and 5 illuminate simultaneously (marked "end").
  • Page 14 User instructions SWITCHING OFF At the end of the program the beeper sounds briefly and the lights of programs no. 4 and 5 (marked "end") flash. To switch off the dishwasher, open the door and press the ON/OFF button (1). ENERGY MANAGEMENT After 5 minutes of inactivity (wash cycle completed, stopped or set but not started), the dishwasher switches to standby mode to reduce energy...

  • Page 15: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare it for use as follows:  Adjust the water softening system Add salt   Add rinse aid and detergent 2.1 Using the water softening system The dishwasher is equipped with an automatic softening system which uses a special regenerating salt to reduce the SALT...
  • Page 16 User instructions Do not use table salt, as it contains insoluble substances which,  over time, may damage the water softening system. The salt container should be refilled before starting the wash  program. This way, the excess saline solution will be immediately removed by the water;...
  • Page 17 User instructions WATER HARDNESS TABLE German French SETTING degrees (°dH) Degrees (°dF) All lights off 0 - 6 0 - 11 (no salt) One light on 7 - 10 12 - 18 Two lights on 11 - 15 19 - 27 Three lights on 16 - 21 28 - 37...
  • Page 18 User instructions ADDING RINSE AID Rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle. To add rinse aid:  Open the door. ...
  • Page 19 User instructions ADDING DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the wash cycle, the dispenser will open automatically.  When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity G/H (depending on model).
  • Page 20 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. 2.3 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types and loading. There are generally no constraints on washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account.
  • Page 21 User instructions WARNING! Make sure that the dishes are securely in place so that they cannot  tip over or obstruct the rotation of the spray arms during the wash cycle.  Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the pump.
  • Page 22 User instructions 2.4 Using the baskets The dishwasher has a capacity of 10 place-settings, including serving dishes. LOWER BASKET Used for items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces exposed to the water jets coming from the bottom.
  • Page 23 User instructions BOTTOM BASKET INSERTS Some models are equipped with bottom basket inserts which improve the drying of dishes. The inserts are supplied in the accessories bag; to use them, simply fit them into place as shown. CUTLERY BASKET The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing downwards.
  • Page 24 User instructions UPPER BASKET It is recommended to load the upper basket with small or medium-sized items such as glasses, small plates and saucers, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If the upper basket is used in the lowermost position, it can also be loaded with serving dishes, provided they are only lightly soiled.
  • Page 25 User instructions ADJUSTING THE UPPER BASKET The height of the upper basket can be according to requirements and the size of the dishes in the lower basket. Pull-out adjustment system:  Turn the retainer E on both runners, right and left, through 90° Remove the basket ...
  • Page 26 User instructions Quicklift position setting system: system with 3 position settings (1 lowest, 3 highest). The basket is snapped into the position required, lifting both sides simultaneously. To return to the lowest position from any height, lift the basket to the highest position and then release.
  • Page 27 User instructions LOWEST MEDIUM RELEASE HIGHEST...

  • Page 28: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or turn off the dual-pole dedicated switch. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft, damp cloth or with a normal detergent suitable for painted surfaces.
  • Page 29 User instructions CLEANING THE OSCILLATING BOTTOM SPRAY ARM ● Take hold of the bottom spray arm unit and pull it upward to release. ● Separate the oscillating arm A from the spray arm B. ● Turn the oscillating arm A upside down to release the toothed wheel C by pressing the teeth D and turning them anticlockwise.
  • Page 30 User instructions CLEANING THE FILTER UNIT The central filter should be cleaned regularly. To remove it, pull the  spray arm assembly upwards.  Turn the microfilter M anticlockwise to release and extract it, then lift the stainless steel filter F. Push the central filter H from below to extract it from the micro-filter.
  • Page 31 User instructions PROLONGED DISUSE: Run the soak program twice in succession.  Unplug the power cord from the socket.  Leave the door slightly open in order to prevent the formation of  unpleasant odours inside the wash tank. Fill the rinse aid dispenser. ...
  • Page 32 User instructions If the dishes fail to dry or remain dull, check that: The rinse aid container is not empty  The rinse aid dispenser setting is correct   The detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open) If the dishes show signs of streaking, staining etc., check that:...

  • Page 33: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is capable of signalling a number of faults by the simultaneous illumination of multiple indicator lights; the meanings are given below: FAULT DESCRIPTION Aquastop failure The anti-flooding system has activated (relevant models only). The system trips in case of water leaks. Contact the after-sales service.
  • Page 34 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (relevant models only) The intake water quantity is not being measured accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the wash cycle. If the problem persists, contact the after-sales service.
  • Page 35 User instructions TECHNICAL DATA Width 497  499 mm Depth measured flush with the 550 mm outer edge of the control panel Height (depending on models) from 820 mm to 870 mm Capacity 10 Standard place settings Water supply pressure min.
