Summary of Contents for Candy IBDWI600
- Page 1 User instructions IBDWI600 DISHWASHER...
-
Page 3: Table Of Contents
CONTENTS pag. General safety rules Water connection pag. Loading the salt pag. pag. Adjusting the upper basket pag. Loading the dishes pag. Information for test laboratories pag. Loading the detergent Types of detergent pag. Loading the rinse aid pag. Cleaning the filters pag. -
Page 4: General Safety Rules
above and persons with reduced GENERAL SAFETY RULES physical, sensory or mental capabilities or lack of experience This appliances is intended to be and knowledge if they have been used in household and similar given supervision or instruction applications such as: concerning use of the appliance in a safe way and understand the - staff kitchen areas in shops,... - Page 5 The dishwasher is designed for WARNING ! normal kitchen utensils. Objects that Knives and other utensils with have been contamined by petrol, sharp points must be loaded paint, traces of steel or iron, corrosi- in the basket with their points ve chemicals, acids or alkalis must down or placed in a horizontal not be washed in the dishwasher.
-
Page 6: Water Connection
WATER CONNECTION IMPORTANT The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. The inlet and drain hoses can be directed to left or right. IMPORTANT The dishwasher can be connected to either cold or hot water, as long as it is no hotter than 60°C. - Page 7 The hose can be hooked over the side of Connecting the outlet hose the sink, but it must not be immersed in water, in order to prevent water from being syphoned back to the machine The outlet hose should disharge into a when this is in operation (fig.
-
Page 8: Loading The Salt
The salt dispenser has a capacity of LOADING THE SALT between 1.5 and 1.8 kg and, for efficient use of the appliance, it should be refilled from time to time according to the The appearance of white stains on dishes regulation of the water softener unit. - Page 9 ADJUSTMENT OF THE UPPER BASKET If 29 cm to 32,5 cm plates are normally used, load them onto the lower basket after the upper basket has been placed in its upper position and proceed as detailed below: 1. Turn the front stops “A” outwards; 2.
-
Page 10: Loading The Dishes
A standard daily load is represented in LOADING DISHES figs. 1, 2 and 3. Using the upper basket Upper basket (fig. 1) The upper basket is provided with A = soup plates mobile racks hooked to the sides of the B = dinner plates basket, which can be regulated into 4 C = dessert plates... - Page 11 Upper basket (fig. 3) A standard daily load is represented in figs. 4 and 5. A = glasses B = saucers C = cups Lower basket (fig. 4) D = small bowl A = medium-sized saucepan E = medium bowl B = large saucepan F = large bowl C = frying pan...
-
Page 12: Information For Test Laboratories
INFORMATION FOR THE TEST LABORATORIES Please ask information required for comparison testing and measuring noise levels, according to EN normative, to the following address: testinfo-dishwasher@candy.it In the request, please specify model name and number of the dishwasher (see rating plate). -
Page 13: Loading The Detergent
LOADING THE DETERGENT The detergent IMPORTANT It is essential to use a detergent that is specifically designed for dishwashers either in powder, liquid or tablet form. pressing on it (2) until you hear the click. Unsuitable detergents (like those for washing up by hand) do not contain the proper ingredients for use in a dishwasher, and stop the dishwasher from working... -
Page 14: Types Of Detergent
TYPES OF DETERGENT the effectiveness of detergents containing the built in water softener/salt depends on the hardness of your water supply. Detergent tablets Check that the hardness of your water supply is within the effective range given Detergent tablets of different manufacturers on the detergent packaging. -
Page 15: Loading The Rinse Aid
LOADING THE RINSE AID The rinse aid The rinse aid, which is automatically released during the last rinsing cycle, helps the dishes to dry quickly and prevents spots and stains forming. Filling the rinse aid container The rinse aid container can be found to the left of the detergent container (fig. -
Page 16: Cleaning The Filters
CLEANING THE FILTERS The filter system (fig.A “4”) consists of: a central container that traps the larger particles; a flat gauze that continuously filters the wash water; a micro filter, located beneath the gauze, that traps the tiniest particles ensuring a perfect rinse. - Page 17 PRATICAL HINTS How to make savings How to get really good wash If you want the dishwasher to give a complete wash, place the dishes in the results dishwasher at the end of each meal and if necessary turn on the COLD RINSE Before placing the dishes in the cycle to soften the food remains and dishwasher, remove any remaining...
- Page 18 CLEANING AND MAINTENANCE To clean the dishwasher outside, do not use solvents (degreasing action) neither abrasives, but only a cloth soaked with water. The dishwasher does not require special maintenance, because the tank is self-cleaning. Regularly wipe the door gasket with a damp cloth to remove any food remains or rinse aid.
-
Page 19: Description Of The Control Panel
DESCRIPTION OF THE CONTROL PANEL "ON/OFF" button "SALT EMPTY" light "PROGRAMME SELECTION" button "OPTION SELECTION" light "DELAY START" button "PROGRAMME STATUS" lights/ "DELAY START" time lights "EXPRESS" option button "PROGRAMME SELECTION" lights "RESET" button for "SALT EMPTY" light Programme guide "START"/"RESET"... -
Page 20: Programme Selection And Special Functions
PROGRAMME SELECTION AND SPECIAL FUNCTIONS WARNING! If you open the door during the drying cycle, an audible audio signal (Use in conjunction with programme guide) advises you that the drying cycle has not yet finished. Programme settings Changing a running programme Open the door and place the dirty dishes inside the appliance. - Page 21 "DELAY START" button Option buttons The dishwasher start time can be set with "EXPRESS" button this button, delaying the start by 3, 6 or 9 hours. This button provides an energy and time Proceed as follows to set a delayed start: saving of 25% on average (according to the select cycle) reducing the wash water Choose a programme by pressing the...
- Page 22 2. Keep the "PROGRAMME SELECTION" Alarm mute for the PROGRAMME button pressed for at least 30 seconds (during this time, 3 audible signals will sound). The alarm for the programme end may be muted as follows: 3. Release the button when the THIRD audible signal sounds (all the indicator lights will flash).
-
Page 23: Water Softener Unit
WATER SOFTENER UNIT * The water softener unit is set in the factory at level 3, as this is suitable for the majority of users. Depending on the source of the supply, water contains varying amounts of limestone and minerals which are deposited on the According to the degree of hardness of dishes leaving whitish stains and marks. -
Page 24: Programme Guide
PROGRAMME GUIDE Programme Description Once a day - for heavily soiled pans and any Intensive other items that have been left all day for washing. Once a day - for normal soiled pans and any Universal other items that have been left all day for washing. - Page 25 Special function Avarage Programme contents Check list buttons duration in minutes available • • • • • • • • • • • • • 75°C • • • • • • • • • • 60°C • • • • • •...
-
Page 26: Identifying Minor Faults
IDENTIFYING MINOR FAULTS Should the dishwasher fail to operate, before contacting the Service Centre, make the following checks: FAULT CAUSE REMEDY Plug is not connected to wall Connect electric plug socket O/I button has not been pressed Press button 1 - Machine completely dead Door is open Close door No electricity... - Page 27 FAULT CAUSE REMEDY See causes for no. 5 Check Bottom of saucepans have not Burnt on food remains must been washed well be soaked before putting pans in dishwasher Edge of saucepans have not Reposition saucepans been washed well Spray arms are partially blocked Remove spray arms by unscrewing ring nuts clockwise and wash under running water...
- Page 31 The manufacturer declines all responsibility in the event of any printing mistakes in this booklet. The manufacturer also reserves the right to make appropriate modifications to its products without changing the essential characteristics. To consult the product fiche, please refer to the manufacturer website.
- Page 32 This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). WEEE contains both polluting substances (which can cause negative consequences for the environment) and basic compo- nents (which can be re-used). It is important to have WEEE subjected to specific treatments, in order to remove and dispose properly all pollutants, and recover and recycle all materials.
