Summary of Contents for Candy Brava CDIN 2D620PB-80E

  • Page 2: Table Of Contents

    Thank you for choosing this product. Contents We are proud to offer the ideal product for you and the best complete range of home appliances for your daily routine. 1. GENERAL SAFETY RULES Carefully read this manual for correct and 2.
  • Page 3: General Safety Rules

    1. GENERAL SAFETY sensorial or mental capacities, without experience or knowledge RULES of the product, only if supervised This appliances is intended to  or provided with instruction as be used in household and to the operation of the appliance, similar applications such as: in a safe way with awareness −...
  • Page 4 Make sure carpets or rugs do Ensure that the dishwasher   not obstruct the base or any of does not crush power cables. the ventilation openings. In general it is not advisable to  After installation, the appliance use adaptors, multiple plugs ...
  • Page 5 When moving, do not lift the  marking this product, dishwasher by the door; during we confirm, under our own the transport, never lean the responsibility, full compliance door trolley. this product with recommend two people lift the relevant safety, health and machine.
  • Page 6: Water Connection

    2. WATER CONNECTION If the dishwasher is connected to new  The appliance must be connected to pipes or to pipes which have not been the water mains using new hose-sets. inuse for a long time run water through for The old hose-sets should not be a few minutes before connecting the inlet reused.
  • Page 7 AQUASTOP (fig. 4):  Hydraulic safety devices A device located on the supply tube that stops water flow if the tube deteriorates; in this case, a red mark will appear in the All the dishwashers are equipped with window "A" and the tube must be an overflow safety device which, if replaced.
  • Page 8 Connecting the outlet hose The outlet hose should disharge into a  The hose can be hooked over the side of  standpipe, making sure that there are no the sink, but it must not be immersed in kinks (fig. 6). water, in order to prevent water from being syphoned back to the machine ...
  • Page 9: Loading The Salt

    3. LOADING THE SALT After loading the salt, YOU MUST run a complete washing cycle, or the (Fig. A "1") PRE-WASH/COLD RINSE/REFRESH programme. The appearance of white stains on dishes  is generally a warning sign that the salt container needs filling. The salt dispenser has a capacity of ...
  • Page 10: Adjusting The Upper Basket (Only On Some Models)

    4. ADJUSTING THE UPPER Type "B": (ONLY MODELS WITH EASY CLICK): BASKET (ONLY ON SOME 1. Remove the upper basket; 2. Hold the basket on both sides and lift it MODELS) upwards (fig. 1). Dishes that are greater than 20 cm* in ...
  • Page 11: Loading Dishes

    5. LOADING DISHES A standard daily load is represented in figs. 1 and 2. Using the upper basket Upper basket (fig. 1) The upper basket is provided with mobile  racks hooked to the sides of the basket, which can be regulated into 4 positions. In the lowered position (A-A1) the racks ...
  • Page 12 Upper basket (fig. 5) Place the cutlery in the plastic cutlery  holder with the handles pointing upwards and place the cutlery holder on the lower basket (fig. 6) making sure that the cutlery does not get in the way of the rotating arms.
  • Page 13: Information For Test Laboratories

    For loading salt, cleaning filter and for following address: ordinary maintenance, the complete testinfo-dishwasher@candy.it extraction of the basket is necessary. In the request, please specify model name and number of the dishwasher (see rating Cutlery basket (fig.7)
  • Page 14: Loading The Detergent

    7. LOADING THE DETERGENT (Fig. A "2") The detergent It is essential to use a detergent that is specifically designed for dishwashers either in powder, liquid,gel or tablet form. After pouring detergent into container, close the lid, firstly pushing (1) and then pressing on it (2) until you hear Unsuitable detergents...
  • Page 15: Types Of Detergent

    8. TYPES OF DETERGENT read carefully and follow the manufacturer’s  instructions given on the packaging; Detergent tablets the effectiveness of detergents containing  the built in water softener/salt depends on Detergent tablets of different manufacturers the hardness of your water supply. Check dissolve at different speeds, for this reason, that the hardness of your water supply is during short programmes, some detergent...
  • Page 16: Loading The Rinse Aid

    9. LOADING THE RINSE AID (Fig. A "3") The rinse aid The rinse aid, which is automatically released during the last rinsing cycle, helps the dishes to dry quickly and prevents spots and stains forming. Filling the rinse aid container. The rinse aid container can be found to the left of the detergent container (fig.
  • Page 17: Cleaning The Filters

    10. CLEANING THE FILTERS (Fig. A "4") The filter system consists of: A. A central container that traps the larger particles; B. A micro filter, located beneath the gauze, that traps the tiniest particles ensuring a perfect rinse; C. A flat gauze that continuously filters the wash water.
  • Page 18: Practical Hints

    11. PRACTICAL HINTS If you want the dishwasher to give a  complete wash, place the dishes in the dishwasher at the end of each meal and if How to get really good wash necessary turn on the COLD RINSE cycle results.
  • Page 19: Cleaning And Maintenance

    12. CLEANING AND 2) wash the rotor arms under a jet of water to clear any blockage in the spray MAINTENANCE heads. Looking after your appliance correctly can Do not use tools that can deform the extend its lifespan. spray heads.
  • Page 20 If the machine is not going to be used for 4. fill the rinse aid container; some time, it is advisable to follow these 5. Ieave the door ajar; rules: 6. keep the inside of the machine clean; 1. do an empty wash with detergent in order to clean the machine of any 7.
  • Page 21: Description Of The Control Panel

    13. DESCRIPTION OF THE 14. TECHNICAL DATA CONTROL PANEL...
  • Page 22: Programme Selection And Special Features

    15. PROGRAMME SELECTION Close the door (after an audible signal  has sounded, the programme will start AND SPECIAL FEATURES automatically). ON/OFF button WARNING To turn the appliance on and off, press  In the event that the machine remains the ON/OFF button (for at least 3 switched on without selecting or seconds).
  • Page 23 Parameter adjustment is performed by  ADDISH (possibility of adding pressing the "SMART DOOR/EXPRESS" dishes after the programme has and "TABS" buttons. started) To adjust the SOFTENER see the specific  Chapter of the manual. When the programme starts, you should only open the door and add more dishes To adjust the BUZZER see the specific ...
  • Page 24 Changing a running programme. Proceed as follows to change or cancel a running program: Open the door.  Keep the START/RESET button pressed  for at least 3 seconds. "RESET" will appear on the display and acoustic signals will be emitted. The running programme will be cancelled.
  • Page 25 "SMART DOOR" (Automatic door opening) WARNING (Only in models where present) Once selected, this option keeps This option enables a special device that being on (light on) also for next opens the door by a few centimetres at the washing cycles and it can be de- end of the "ECO"...
  • Page 26 When the delay is set on a programme:  Activation/Muted END-OF- PROGRAMME signal. - after pressing "START/RESET", the countdown time “00:00” appears on the display with flashing “ : ” You can deactivate turning on and off of the audio signal as follows (the default setting is - if you press any button (except for the active): "ON/OFF", "PROGRAMME SELECTION"...
  • Page 27 Disabling "Demo mode" The message "SETTINGS" will appear  on the display and the indicator lights of the "SMART DOOR/EXPRESS" and WARNING "TABS" buttons will be on. Once installed, if the appliance works Pressing the "PROGRAMME SELECTION"  correctly but the wash cycle does not button until the "MEMO FUNCTION"...
  • Page 28: Remote Control (Wi-Fi)

    "Wi-Fi" indicator light will be steady on.  You can now check the machine from the Pairing the machine with the app App. Download the Candy simply-Fi app onto  Unsuccessful enrollment your device. If enrolment fails (or does not succeed within 5 mins.):...
  • Page 29 DISABLING REMOTE CONTROL "Wi-Fi" indicator light To exit remote control, press "PROGRAMME  Indicates the connection status of the  SELECTION" again for 3 secs. product to the home Wi-Fi network. It can When no cycle is under way:  - SLOW FLASHING: remote...
  • Page 30: Programme Legend

    17. PROGRAMME LEGEND Programme Description Programme for normally soiled tableware (the most efficient in terms of its combined energy and water consumption for that type of tableware). Programme standardised to EN 50242. Once a day - for heavily soiled pans and any other INTENSIVE items that have been left all day for washing.
  • Page 31 Options Programme ● ● ■ INTENSIVE NIGHT ● ■ UNIVERSAL 55-65 75-95 AUTO WASH ■ DELICATE ● RAPID 24’ - - - PREWASH ● = Add detergent for prewash ■ = "IMPULSE" Programmes = only on some models N.B. = the SMART DOOR function is only active if the ‘Express’ option has not been selected. N/A= OPTION NOT AVAILABLE 1) With cold water (15°C) –...
  • Page 32: Water Softener Unit

    18. WATER SOFTENER UNIT Regulate the setting of your water softener Depending on the source of the supply, unit according to the degree of hardness of water contains varying amounts your water, as follows: limestone and minerals which are deposited on the dishes leaving whitish stains and marks.
  • Page 33: Troubleshooting And Warranty

    19. TROUBLESHOOTING AND WARRANTY If you believe the dishwasher is not working correctly, consult the quick guide provided below with some practical tips on how to fix the most common problems. If the malfunction continues or recurs, contact the Technical Assistance Centre. BUG REPORTS Models with a display: errors are reported by a number preceded by the letter "E"...
  • Page 34 Only models without a display If malfunctions or faults occur when a programme is running, the indicator light that corresponds to the selected cycle will blink rapidly, and an intermittent audio signal will sound. In this case, turn the dishwasher off by pressing the "ON/OFF" button. After checking to make sure the water supply is open, that the drain pipe is not bent and that the siphon or filters are not clogged, set the selected program again.
  • Page 35 FAULTS CAUSE SOLUTION Reduce amount of detergent Use 5. Spray arms are Excessive amount of detergent suitable detergent not heard to Item prevents arms from rotating Check rotate Filtering plate and filter very dirty Clean filtering plate and filter 6. On electronic appliances without a Switch off the appliance.
  • Page 36 N.B.: Should any of the above situations result in a bad wash performance or insufficient rinsing, remove dirt deposits from the dishes by hand since the final drying cycle hardens the dirt, making it difficult to remove with a subsequent wash. If the malfunction continues, contact the Technical Assistance Centre, quoting the model of the dishwasher.
  • Page 37: Environmental Conditions

    20. ENVIRONMENTAL CONDITIONS This appliance marked WEEE should treated  cording to the European directive household waste; 2012/19/EUon Waste Electrical Electronic Equipment WEEE should be handed over to the  (WEEE). relevant collection points managed by WEEE contains both polluting substances municipality registered (which can cause negative consequences...
  • Page 38 fk hldsk...
  • Page 39 fk hldsk...
  • Page 40 - CDIN 2D620PB-80E -...
