- Page 1 QCast Mirror User Manual HDMI Wireless Dongle | QP30 V 1.00...
-
Page 2: Copyright And Disclaimer
Any third party content or service preinstalled in this product is provided “as is”. BenQ does not, by expression or by implication, make any warrant to the content or to the services provided by third parties. BenQ does not warrant or guarantee that the content or services provided by third parties are accurate, effective, most up-to-date, legal, or complete. - Page 3 In addition, BenQ is not involved in any transactions you conduct in the websites or similar resources maintained by third parties.
-
Page 4: Table Of Contents
Mirroring the content from your device via a direct connection ...10 Mirroring the content from your device via a router ......12 The Advanced Settings menu ............14 Connecting the QCast Mirror to a Wi-Fi router ........16 Other advanced settings ................18 Connected Devices ................18 Device Management ................19... -
Page 5: Package Contents
Package contents QCast Mirror HDMI Wireless Dongle USB-C-to-USB-A Cable HDMI Adapter Cable Quick Start Guide Product overview 1. HDMI Connector Connects to the projector. 2. USB-C Port Connects to the projector’s USB port (or a standard adapter head) via the USB-C-to-USB-A cable to supply the dongle with power. - Page 6 the settings for the dongle. 4. LED Indicators Lights up blue when power is supplied.
-
Page 7: Operating Instructions
Operating instructions Connecting the QCast Mirror to your projector Note Depending on your device’s operating system, different installation procedures and setup are required. Read this document and on-screen instructions (if provided) carefully. 1. Connect the USB-C-to-USB-A cable to the USB-C port on the dongle. - Page 8 • The dongle does not support USB-A plug adapters with Power Delivery or Quick Charge capabilities. USB-A 4. Switch the input source on the projector to HDMI, a standby screen may appear. Once the QCast Mirror screen is shown you can begin the mirroring process.
- Page 9 QP30 QP30 QP30 QP30 QP30 192.168.168.1 QP30 HDMI Source...
-
Page 10: Mirroring The Content From Your Device Via A Direct Connection
1. [For iOS/macOS/Android devices only]: Open your device’s Wi-Fi menu and connect to the SSID displayed on the top side of the QCast Mirror screen and enter the security password displayed next to the SSID on the QCast Mirror screen. - Page 11 key simultaneously to open your PC’s screen casting menu. [For iOS/macOS/Android devices only]: Open your device’s screen casting menu. 3. Select the dongle’s name (“QP30_XXXXXX”) in the screen casting menu. MacOS Android & iOS Device Device QP30_xxxxxxxx QP30_xxxxxxxx Windows PC Device P / K QP30_xxxxxxxx...
-
Page 12: Mirroring The Content From Your Device Via A Router
Wi-Fi router with Internet access. The steps to begin mirroring in this manner are described below. 1. Follow the instructions in Connecting the QCast Mirror to a Wi-Fi router on page 16 to connect the dongle to a Wi-Fi router. - Page 13 4. Select the dongle’s name (“QP30_XXXXXX”) in the screen casting menu. Android & iOS MacOS Device Device QP30_xxxxxxxx QP30_xxxxxxxx Windows PC Device P / K QP30_xxxxxxxx...
-
Page 14: The Advanced Settings Menu
The Advanced Settings menu The Advanced Settings menu for the QCast Mirror allows you to connect the QCast Mirror to a Wi-Fi router as well as configure various settings for the dongle. The steps to accessing the Advanced Settings menu are described below: 1. - Page 15 http://192.168.168.1, the Advanced Settings menu will open in the browser. 192.168.168.1 4. Enter the Advanced Settings menu password to log in. Note • When opening the Advanced Settings menu for the first time, enter the default password “000000” to log in. Once logged in you will be asked if you want to change the password, select Skip if you want to keep the default password.
-
Page 16: Connecting The Qcast Mirror To A Wi-Fi Router
Fi router To provide devices connected to QCast Mirror with Internet access you must first connect QCast Mirror to a Wi-Fi router via the Advanced Settings menu. The steps to connecting QCast Mirror to a Wi-Fi router are described below. - Page 17 Mirror. Once the dongle has been rebooted, repeat the steps in this section to connect to the Wi-Fi router. Once you have successfully connected to the Wi-Fi router, the connection between the dongle and router at the top-right corner of the QCast Mirror screen will feature a blue Wi-Fi icon.
-
Page 18: Other Advanced Settings
• Connected Devices • Device Management • Network Management • Admin Settings • Reboot • About Device Connected Devices The Connected Devices sub-menu lists the various devices currently connected to QCast Mirror including the device(s) name and their IP address:... -
Page 19: Device Management
This sub-menu is only available when you log into the Advanced Settings menu using its password. Language Selects the language for QCast Mirror. Device Name Changes the name of the QCast Mirror’s SSID. • Hide SSID: Makes the QCast Mirror’s SSID invisible in the Wi-Fi menu of nearby devices. -
Page 20: Network Management
Mirror automatically reboots itself. If you make any changes to the settings in the sub-menu, you will need to reboot QCast Mirror in order for the changes to take effect. Network Management The Network Management sub-menu includes the following items: Note This sub-menu is only available when you log into the Advanced Settings menu using its password. - Page 21 Connect to 5GHz Wi-Fi Connects QCast Mirror to a Wi-Fi router. For more details, see Connecting the QCast Mirror to a Wi-Fi router on page Remember Wi-Fi Allows QCast Mirror to remember any previous Wi-Fi routers QCast Mirror has previously connected to so that the dongle will automatically reconnect after any reboot.
-
Page 22: Admin Settings
Internet Access control Sets which type of user connected to QCast Mirror has access to the Internet. The available options include: All Allowed, Only Casting Users, and All Denied. My Screen Changes the image shown as the QCast Mirror screen. - Page 23 Wi-Fi Diagnostic Tool Allows you to test the performance of QCast Mirror’s Wi-Fi signal. Reset to Factory Default Resets QCast Mirror’s to its factory default settings. If you make any changes to the settings in the sub-menu, you will need to...
-
Page 24: Reboot
Select Reboot in the Advanced Settings menu to manually reboot QCast Mirror. Note Reboot is only available when you log into the Advanced Settings menu using its password. About Device Lists the following information for QCast Mirror: • SSID • Firmware Version • IP • Internet IP •... -
Page 25: Product Specifications
Product specifications Model name QP30 - QCast Mirror HDMI Wireless Dongle Dimensions 97.2 x 12 x 32 mm (W x H x D) Input terminals USB-C Output terminals HDMI 1.4b Weight 32g approximately Wireless standard IEEE 802.11a/b/g/n/ac Security WPA/WPA2 Blue LED indication for Power Output resolution •... -
Page 26: System Requirements
• Transmission quality depends on the Wi-Fi environment and the screen mirroring compatibility of mobile devices from different brands. To ensure the best transmission quality, visit http://www. benq.com/ for the list of compatible devices. • For further information, please visit:... -
Page 27: Faq
If your problems remain after checking this manual, please visit the local website from Support.BenQ.com for more support , FAQ and local customer service. Support.BenQ.com...
