- Page 1 QCast Mirror - QP20 HDMI Wireless Dongle User Manual V 1.00...
-
Page 2: Table Of Contents
Table of Contents Package Contents 1 Product Overview 1 Operating Instructions 2 Connecting the dongle to your projector �����������������������������������������������������������������������������������2 Mirroring the content from your device �������������������������������������������������������������������������������������4 Advanced Settings �����������������������������������������������������������������������������������������������������������������������������8 Product Specifications 9 System Requirements 9 FAQ 10... - Page 3 Any third party content or service preinstalled in this product is provided “as is”. BenQ does not, by expression or by implication, make any warrant to the content or to the services provided by third parties. BenQ does not warrant or guarantee that the content or services provided by third parties are accurate, effective, most up-to- date, legal, or complete.
-
Page 4: Package Contents
Package Contents QCast Mirror Micro-USB cable Quick start guide HDMI wireless dongle Product Overview HDMI Connector Connects to the projector. 24/5G Wi-Fi Switcher Switches the Wi-Fi signal between 5G and 2.4G when pushed, the default setting for the signal is 5G. See “Advanced Settings”... -
Page 5: Operating Instructions
Operating Instructions Connecting the dongle to your projector Depending on your device’s operating system, different installation procedures and setup are required. Read this document and on-screen instructions (if provided) carefully. Connect the Micro-USB cable to the Micro-USB port on the dongle. Micro USB Plug the dongle into the HDMI port on the projector. - Page 6 Connect the USB type-A connector of the Micro-USB cable to the USB port on the projector, the LED indicator on the dongle will light up blue. The USB port on the projector that you connect the cable to must provide 5V/1A power. If the LED indicator on the dongle does not light up blue, the USB port on your projector may not supply enough power and you may need to connect the cable to a power socket via a standard USB power adapter.
-
Page 7: Mirroring The Content From Your Device
Mirroring the content from your device The QCast Mirror allows you to mirror the screen of smartphones, tablets, and computers via a Wi- Fi signal. Devices that do not have Wi-Fi capabilities are not able to mirror their screen via the QCast Mirror. - Page 8 • Android Open your Android device’s Screen Mirroring menu. Select the QCast Mirror from the list of available mirroring devices. English...
- Page 9 For Desktop/Laptop Computers • Mac OS Enter your Mac’s Wi-Fi menu and connect to the SSID displayed on the top right side of the QCast Mirror screen. Enter the security password displayed below the SSID on the QCast Mirror screen. Open the Mac screen mirroring menu in the Mac OS home screen, and then select the QCast Mirror from the list of available mirroring devices.
- Page 10 • Windows OS Select the Connect button from Windows Action Center Select the QCast Mirror from the list of available mirroring devices. English...
-
Page 11: Advanced Settings
Advanced Settings The Advanced Settings menu for the QCast Mirror allows you to configure various settings for the QCast Mirror. To access the Advanced Settings menu: Enter your device’s Wi-Fi menu and connect to the SSID displayed on the top right side of the QCast Mirror screen. -
Page 12: Product Specifications
Windows Phone Windows Phone 8.1 and later with Mirror Screen support • 5G Wi-Fi only supports Band 1 (5.150 - 5.250 GHz). Transmission quality depends on the Wi-Fi environment and the compatibility of mobile devices from different brands. • For further information, please visit: http://www.benq.com/ English... -
Page 13: Faq
Is my device able to use QCast Mirror? Any device with screen mirroring capabilities is able to use QCast Mirror. How can I tell if my device has screen mirroring capabilities? For smartphones/tablets: Check to see if the operating system for your device matches the system requirements for QCast Mirror, see “System Requirements”... - Page 14 • Re-connect the QCast Mirror’s Micro-USB cable to the power source. • Select the Restart System button in the Advanced Settings menu. • With BenQ Wireless Projectors (M6 series), press the Menu key and enter the advanced OSD and set the USB power switch to Off and then On. Visit www.BenQ.com...
- Page 15 What do I do if videos shown via QCast Mirror lag or are choppy? When videos shown via QCast Mirror lag or are choppy, the most likely factors are Wi-Fi signal strength or the video bitrate: • For videos located locally on the mirrored device: The most likely factor is the video’s bitrate. •...
- Page 16 BenQ.com © 2017 BenQ Corporation All rights reserved. Rights of modification reserved. 5/25/2017...
