SPECIFICATIONS
PXIe-8374
This document lists the system specifications for the PXIe-8374 (193970x-02L) only.
Note
The specific NI assembly number in parentheses follows the model number.
Ensure the specifications of interest match the NI assembly number on either the
front or back side of the module. x denotes all letter revisions of the assembly.
Note
These specifications are typical at 25 °C, unless otherwise stated.
Caution
Physical
Dimensions
Maximum cable length
Slot requirements
Compatibility
Weight
Power Requirements
Power Rail
+3.3 V
+12 V
+5 V
AUX
Specifications are subject to change without notice.
Typical Current
480 mA
430 mA
5 mA
10.0 cm × 16.0 cm (3.9 in. × 6.3 in.)
7 m
One peripheral slot (PXI Express or
CompactPCI Express)
Fully compatible with the PXI Express
Hardware Specification, Revision 1.0, and the
PICMG CompactPCI Express EXP.0 R1.0
Specification
0.16 kg (0.35 lb) typical
Maximum Current
700 mA
750 mA
20 mA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for National Instruments PXIe-8374
Summary of Contents for National Instruments PXIe-8374
- Page 1 SPECIFICATIONS PXIe-8374 This document lists the system specifications for the PXIe-8374 (193970x-02L) only. Note The specific NI assembly number in parentheses follows the model number. Ensure the specifications of interest match the NI assembly number on either the front or back side of the module. x denotes all letter revisions of the assembly.
- Page 2 5% to 95%, noncondensing (Tested in accordance with IEC-60068-2-56.) Note Clean the PXIe-8374 with a soft nonmetallic brush. Make sure that the device is completely dry and free from contaminants before returning it to service. Shock and Vibration Operating shock 30 g peak, half-sine, 11 ms pulse (Tested in accordance with IEC-60068-2-27.
- Page 3 Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance information. To obtain product certifications and the DoC for this product, visit ni.com/ certification, search by model number or product line, and click the appropriate link in the Certification column. PXIe-8374 Specifications | © National Instruments | 3...
- Page 4 NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at . You can find patents.txt ni.com/patents...
