USER MANUAL
GAS HOB
TGF64E | TGWF64E | TGWF93E
IMPORTANT //
Please ensure that you read through this manual prior to installation and use. This
user manual contains important information to ensure optimal performance and keep you safe. Please
retain your proof of purchase, as this will be needed in the event that you require a warranty service.
Remember to keep this user manual for future reference.
www.tisira.com
Advertisement
Related Manuals for Tisira TGF64E
Summary of Contents for Tisira TGF64E
- Page 1 USER MANUAL GAS HOB TGF64E | TGWF64E | TGWF93E IMPORTANT // Please ensure that you read through this manual prior to installation and use. This user manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be needed in the event that you require a warranty service.
-
Page 3: Table Of Contents
Content Contents Warning & Safety Instructions Product Overview 4 - 5 Operating Instructions 6 - 7 Cleaning & Maintenance Installation 9 - 15 Page 2 Gas Hob User Manual... -
Page 4: Warning & Safety Instructions
Warning & Safety Instructions IMPORTANT // To ensure best performance, avoid risk of damage or accidents. Please read the operating instructions prior to first time use. Important Safety Instructions • This appliance has been designed for indoor domestic use only. To maintain the efficiency and safety of this •... -
Page 5: Product Overview
Product Overview 1. Burner positions 4. Small Burner 7. WOK Burner 2. Glass or Metal Surface 5. Medium Burner 8. Cast Grill 3. Control Buttons 6. Large Burner 9. Enamel Grill Page 4 Gas Hob User Manual... - Page 6 Product Overview Burners 1. Burner cap 5. Burner base (cup) 2. Inner burner cap 6. Ignition candle 3. Outer burner cap 7. Flame failure device (thermocouple) 4. Burner head (diffuser) Gas Hob User Manual Page 5...
-
Page 7: Operating Instructions
Operating Instructions IMPORTANT // To ensure best performance, avoid risk of damage or accident. Please read the operating instructions prior to first time use. This appliance is supplied with a spare data plate label. Please attach it to an adjacent surface for future reference if the labels on the base of the cooktop are not visible after installation. - Page 8 Operating Instructions NOTE // When one of the control knobs is centre, so they should stay beneath the pan base activated, sparks are generated on all burners of for a best efficiency and a lower risk of injuries the cooktop simultaneously. and damages on pan handles.
-
Page 9: Cleaning & Maintenance
Cleaning & Maintenance IMPORTANT // Before cleaning your oven, or 2. Soak them in hot water with a small performing maintenance, turn the appliance amount of washing detergent. off and disconnect it from the power supply. 3. Softly scrub off any remaining pieces of Also allow the appliance to cool down before food. -
Page 10: Installation
Installation IMPORTANT // This unit must be installed by authorised personnel and used only in permanently ventilated rooms in accordance with the requirements of AS 5601 (gas installations), wiring code, manufacturer’s instructions, local and national authority and any other statutory regulations. Follow carefully the safety instructions and clearance requirements given below. - Page 11 Installation 600mm Hobs - The Gas inlet (1) is located underneath the appliance towards the rear edge. The Electrical terminal (2) is also located underneath the appliance approximately in the centre of the rear edge. Installation Accessories Supplied The following installation accessories are supplied with the appliance: 4 x mounting brackets and screws 1 x seal strip 1 x natural gas regulator...
- Page 12 Installation 9. Secure the appliance by matching the Installation Procedure screws with the correspondent screw holes in each bottom corner of the cooktop. 1. Make the benchtop cut-out for the cooktop in accordance with the diagrams previously presented in this manual. 2.
- Page 13 Installation terminal that is marked with the letter N or ATTENTION // If the connection cable is coloured black. damaged, it must be replaced by a suitably • The brown wire must be connected to the qualified electrician. terminal that is marked with the letter A or coloured red.
- Page 14 Installation 2. Connect the hose from the pressure gauge. The Gas pressure must be set by an approved 3. Reassemble one of the large burners, turn gas fitter as shown on the table presented on the gas and manually light the burners. on the next page or, alternatively, on the 4.
- Page 15 Installation Gas Consumption and Injectors Specifications Natural Gas Universal LPG TGF64E Inj. diam. (mm) MJ/h Gas pressure Inj. diam. (mm) MJ/h Gas pressure Rapid burner x 1 1.55 12.00 1.0kPa 0.85 10.00 2.75kPa Semi-rapid burner x 2 1.18 7.00 1.0kPa 0.65...
- Page 16 Installation conditions, it may be necessary to readjust the Gas Conversion – Natural Gas / ULPG intensity of the minimum flame. Follow the operations below for each burner in This appliance is factory fitted with Natural order to adjust the minimum flame intensities: Gas Injectors (burner nozzles) and is also supplied with a ULPG conversion kit.
- Page 17 New Zealand P // 09 306 1020 F // 09 302 0077 sales@aristonappliances.co.nz Tisira is committed to ongoing research and development. Every effort has been made to ensure all information in this service manual is correct at time of going to print.
