USER MANUAL GAS HOBS TGWF31G TGWF61G TGWF91G IMPORTANT // Please ensure that you read through this user manual prior to installation and use. This manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be required in the event that you require warranty service.
Page 3
Warning & Safety Instructions IMPORTANT // To avoid the risk of accidents and damage to the appliance, please read these instructions carefully before using it for the first time. They contain important notes on installation, safety, use and maintenance. To maintain the efficiency and safety of this •...
Page 4
WARNING & SAFETY INFORMATION DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE STORAGE DRAWER OR NEAR THIS APPLIANCE DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION DO NOT MODIFY THIS APPLIANCE This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
Page 5
220-240V~ / 50Hz Power Capacity 5 Burners Gas Burners 1 Wok / 1 Rapid 2 Semi-rapid / 1 Auxiliary Model: TGWF31G Dimensions W300 x D520 x H90mm Bench Cut-out Dimensions W262 x D480mm Voltage / Frequency 220-240V~ / 50Hz Power...
Page 6
Product Overview Model: TGWF61G Model: TGWF31G Model: TGWF91G 1. Auxiliary burner 4. Triple ring (Wok) burner 2. Semi-rapid burner 5. Control Panel 3. Rapid burner 6. Pan support Page 6 Gas Hob User Manual...
Page 7
Product Overview Burners 1. Burner cap 5. Burner base (cup) 2. Inner burner cap 6. Ignition candle 3. Outer burner cap 7. Flame failure device (thermocouple) 4. Burner head (diffuser) Gas Hob User Manual Page 7...
Page 8
Operating Instructions IMPORTANT // To ensure best performance, avoid risk of damage or accident. Please read the operating instructions prior to first time use. This appliance is supplied with a spare data plate label. Please attach it to an adjacent surface for future reference if the labels on the base of the cooktop are not visible after installation.
Page 9
Operating Instructions NOTE // When one of the control knobs is centre, so they should stay beneath the pan base activated, sparks are generated on all burners of for a best efficiency and a lower risk of injuries the cooktop simultaneously. and damages on pan handles.
Page 10
Cleaning & Maintenance ATTENTION // Before cleaning your oven, or 2. Soak them in hot water with a small amount performing maintenance, turn the appliance off of washing detergent. and disconnect it from the power supply. Also 3. Softly scrub off any remaining pieces of allow the appliance to cool down before touching food.
Page 11
Installation IMPORTANT // This unit must be installed by authorised personnel and used only in permanently ventilated rooms in accordance with the requirements of AS 5601 (gas installations), wiring code, manufacturer’s instructions, local and national authority and any other statutory regulations. Follow carefully the safety instructions and clearance requirements given below.
Page 12
A minimum safety clearance of 25mm underneath the cooktop must be provided for the min. 25 TGWF31G - The Electrical Terminal (1) is located underneath the appliance on rear left hand side and on distance 80mm from the rear glass edge. The Gas Inlet (2) is also located underneath the appliance on rear right hand side and on distance 80mm from the rear glass edge.
Page 13
Installation TGWF91G - The Gas inlet (3) is located underneath the appliance towards the rear right hand side 50mm from the rear edge. The Electrical terminal (4) is also located underneath the appliance towards the rear and approximately 300mm away from the gas inlet. TGWF61G - The Gas Inlet (6 ) is located underneath the appliance on rear right hand side and on distance 100mm from the glass edge.
Page 14
Installation Installation Procedure 8. Connect the appliance to the gas supply (refer to the ‘Gas Connection’ section). 9. Secure the appliance by matching the 1. Make the benchtop cut-out for the cooktop screws with the correspondent screw holes in accordance with the diagrams previously in each bottom corner of the cooktop.
Page 15
Installation ATTENTION // If the connection cable is terminal that is marked with the letter N or damaged, it must be replaced by a suitably coloured black. qualified electrician. • The brown wire must be connected to the terminal that is marked with the letter A or The supply cord has been fitted with a coloured red.
Page 16
Installation The Gas pressure must be set by an approved 2. Connect the hose from the pressure gauge. gas fitter as shown on the table presented 3. Reassemble one of the large burners, turn on the next page or, alternatively, on the on the gas and manually light the burners.
Page 17
Installation Natural Gas Universal LPG TGWF61G Inj. diam. (mm) MJ/h Gas pressure Inj. diam. (mm) MJ/h Gas pressure Wok burner x 1 1.72 13.50 1.0kPa 1.00 13.50 2.75kPa Semi-rapid burner x 2 1.15 6.30 1.0kPa 0.68 6.30 2.75kPa Auxiliary burner x 1 0.93 4.30 1.0kPa...
Page 18
Installation Gas Conversion – Natural Gas / ULPG Follow the operations below for each burner in order to adjust the minimum flame intensities: This appliance is factory fitted with Natural 1. Light the burner. Gas Injectors (burner nozzles) and is also supplied with a ULPG conversion kit.
Page 19
Installation NOTE // A full operational test and a test for possible leakages must be carried out by the installer before leaving. Check all burner flames are blue in colour, stable and completely ignite at both high and low flame settings with no appreciable yellow tipping, carbon deposition, lifting, floating lighting back or objectionable odour.
