Single Port Outdoor Midspan User Guide
Introduction
Microchip's PD-9001GCO, PD-9501GCO, and PD-9601GCO is a single-port IEEE
midspan that offers a cost-effective, IEEE
and ensures safe and reliable operation in outdoor environments for standard PoE data terminal. These midspans
support 10/100/1000 Mbps data rates and are powered through a wide range of AC inputs (100 V
These midspans are IP67-rated and have an extended temperature range to be installed outdoors. In a typical
installation, the midspans provide power to outdoor devices such as WLAN AP, WLAN Mesh, or an IP Camera.
These units offers surge protection for both the AC and the PoE ports ensuring that the indoor equipment is protected
from outdoor surges.
PoE midspan powers devices that are PoE enabled or equipped to receive PoE. These devices are called Powered
Devices (PDs).
Note: This user guide contains installation information for the PD-9001GCO, PD-9501GCO, and PD-9601GCO PoE
midspan units. These units are referred to as PD-9x01GCO PoE midspan units in the following section of this
document.
Features
PoE Midspans offer the following key features:
Outdoor Rated: IP67
Extended Temperature Range
Supports 10/100/1000 Mbps Data Rates
Standards Compliant: IEEE 802.3at/bt
Plug and Play Installation
Includes Integrated Surge/Lightning Protection
©
2022 Microchip Technology Inc.
and its subsidiaries
PD-9x01GCO/AC
®
802.3at/bt compliant solution that guarantees 30W/60W/90W of power,
User Guide
®
802.3bt Gigabit PoE outdoor
to 240 V
AC
AC
DS50003422A-page 1
).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD-9 01GCO/AC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Microchip Technology PD-9 01GCO/AC Series

  • Page 1 Outdoor Rated: IP67 • Extended Temperature Range • Supports 10/100/1000 Mbps Data Rates • Standards Compliant: IEEE 802.3at/bt • Plug and Play Installation • Includes Integrated Surge/Lightning Protection User Guide DS50003422A-page 1 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 2: Table Of Contents

    Microchip Information........................... 22 The Microchip Website..........................22 Product Change Notification Service....................22 Customer Support..........................22 Microchip Devices Code Protection Feature..................22 Legal Notice............................22 Trademarks............................23 Quality Management System........................ 24 User Guide DS50003422A-page 2 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 3 PD-9x01GCO/AC Worldwide Sales and Service........................25 User Guide DS50003422A-page 3 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 4: Standards And Safety Guidelines

    D marking on this product indicates that the product complies with the Denmark Product Safety Act. Surge/Lightning Protection Microchip’s PD-9x01GCO PoE midspan units are designed to me the following requirements. • GR-1089-CORE Lightning Protection Requirements • ITU K.21 Lightning Protection—Enhanced Level User Guide DS50003422A-page 4 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 5: Dust And Water Protection

    Data and Data and Power ports of the midspan unit are shielded RJ45 data sockets. They cannot be used as Plain Old Telephone Service (POTS) sockets. Only connect RJ45 data connectors to these sockets. • When disposing this product, follow all local laws and regulations. User Guide DS50003422A-page 5 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 6: Information En Matière De Sécurité

    être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble. • Pour disposer/jeter ce produit, suivre les lois et règlements locaux. User Guide DS50003422A-page 6 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 7: Poe Midspan Unit Installation

    Quick Installation Guide Additional Tools The following table lists the additional tools required to install the midspan unit. Quantity Part Screwdriver Wire stripper Solid Wrench No. 27 or Adjustable Wrench User Guide DS50003422A-page 7 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 8: Installation

    The midspan has no ON-OFF switch, simply plug the midspan to an AC power source. • PoE midspan AC power lines must be connected to the socket-outlet that shall be installed near the equipment and be easily accessible. User Guide DS50003422A-page 8 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 9 Connect the other end of the ground wire to earth ground at your installation point. Tighten the screw to 1.1 Nm to 1.7 Nm. Figure 3-4. Earth Ground Connection To Earth Ground User Guide DS50003422A-page 9 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 10 The screws are not provided with the kit. Tighten each screw until the midspan unit is securely attached to the mounting surface. Note: The dimensions in the above figure are in millimeters. User Guide DS50003422A-page 10 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 11 Pole of large diameter: The following parts list identifies the components required to install the metal bracket on a pole with a diameter of 76 mm to 203 mm (3 in. to 8 in.). User Guide DS50003422A-page 11 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 12 For poles of both small and large diameter, connect the chassis bolt to the earth ground point on the mount kit. Warning: Mounting bracket must be connected to earth ground. User Guide DS50003422A-page 12 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 13 Pole bracket supports poles with diameters ranging from 60 mm to 200 mm (2.5 in. to 8 in.). • The unit must be installed with DATA IN, and DATA & PWR OUT ports facing down, as shown in the following figures. User Guide DS50003422A-page 13 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 14: Installation Of Cables

    Insert the AC cable through the parts, crimp, and screw the wire leads to 0.8 Nm torque. Push Housing into Body according to lead rails, as shown in the following figure. User Guide DS50003422A-page 14 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 15: Rj45 Cable Installation

    Slide the washer and the upper cap towards the midspan and hand-tighten the upper cap onto the DATA IN port. Note: Secure the gland until the rubber gasket is firmly closed around the cable. User Guide DS50003422A-page 15 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 16 For non AF/AT compliant unit—use a splitter; ensure that the splitter is connected close to the terminal and not on the midspan. These units are designed for outdoor use only. User Guide DS50003422A-page 16 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 17: Data And Power Connection

    LINE IN Power input, 100 V –240 V DATA IN Data in to the Ethernet (network) switch DATA & PWR OUT Data and power out to the Ethernet terminal User Guide DS50003422A-page 17 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 18: Troubleshooting

    Verify that for this link you are using a standard UTP/FTP Category 5 straight (non-crossover) cabling, with all four pairs. Verify that the Ethernet cable length is less than 100 meters from Ethernet source to the remote terminal. User Guide DS50003422A-page 18 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 19: Specifications

    4-5 and 7-8 on wire pairs: 3-6, 4-5 and 1-2, 7-8 AC Power IN 3 Pins AC power-in—Line, Neutral 3 Pins AC power-in—Line, Neutral and and Earth Ground Earth Ground User Guide DS50003422A-page 19 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 20: Technical Support

    If you encounter problems while installing or using this product, consult the Microchip technical support team through the website or contact on the following number: USA/Canada Telephone: +1 877 480 2323 Internet: www.microchip.com/support User Guide DS50003422A-page 20 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 21: Revision History

    PD-9x01GCO/AC Revision History Revision History Revision Date Description 10/2022 Initial Revision. User Guide DS50003422A-page 21 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 22: Microchip Information

    Microchip products with your application. Use of this information in any other manner violates these terms. Information regarding device applications is provided only for your convenience and may be superseded User Guide DS50003422A-page 22 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 23: Trademarks

    The Adaptec logo, Frequency on Demand, Silicon Storage Technology, and Symmcom are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries.
  • Page 24: Quality Management System

    PD-9x01GCO/AC Quality Management System For information regarding Microchip’s Quality Management Systems, please visit www.microchip.com/quality. User Guide DS50003422A-page 24 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 25 Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 User Guide DS50003422A-page 25 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 26 • Für den Außenbereich geeignet: IP67 • Erweiterter Temperaturbereich • Unterstützt Datenraten von 10/100/1000 Mbps • Konform mit den Standards: IEEE 802.3at/bt • Plug-and-Play-Montage • Inklusive integrierter Überspannungsschutz/Blitzschutz User Guide DS50003422A-page 1 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 27 Schnittstelle..........................21 Technischer Support..........................22 Überarbeitungsübersicht........................23 Informationen zu Microchip.......................... 24 Die Microchip-Website.......................... 24 Produktbenachrichtigungsservice......................24 Kunden-Support............................ 24 Microchip Devices Code Protection Feature..................24 Legal Notice............................25 Warenzeichen............................25 Qualitätsmanagementsystem........................26 User Guide DS50003422A-page 2 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 28 Weltweiter Vertrieb und Service......................27 User Guide DS50003422A-page 3 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 29: Normen Und Sicherheitsrichtlinien

    Die D-Kennzeichnung auf diesem Produkt zeigt an, dass das Produkt dem dänischen Produktsicherheitsgesetz entspricht. Überspannungs-/Blitzschutz Die PoE-Midspan-Geräte PD-9x01GCO von Microchip wurden entwickelt, um den folgenden Anforderungen zu entsprechen. • GR-1089-CORE Blitzschutzanforderungen • ITU K.21 Blitzschutz—Erweiterte Stufe User Guide DS50003422A-page 4 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 30: Schutz Vor Staub Und Wasser

    Sie können nicht als Plain Old Telephone Service (POTS)-Buchsen verwendet werden. Schließen Sie nur RJ45-Datenstecker an diese Buchsen an. • Beachten Sie bei der Entsorgung dieses Produkts alle örtlichen Gesetze und Vorschriften. User Guide DS50003422A-page 5 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 31: Information En Matière De Sécurité

    être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble. • Pour disposer/jeter ce produit, suivre les lois et règlements locaux. User Guide DS50003422A-page 6 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 32: Installation Des Poe Midspan-Geräts

    Zusätzliche Werkzeuge In der folgenden Tabelle finden Sie die zusätzlichen Werkzeuge, die für die Installation des Midspan-Geräts erforderlich sind. Menge Teil Schraubendreher Abisolierzange Schraubenschlüssel Nr. 27 oder verstellbarer Schraubenschlüssel User Guide DS50003422A-page 7 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 33: Installation

    Stellen Sie sicher, dass die Kabellänge von der Ethernetnetzwerkquelle bis zum Endgerät 100 Meter (330 Fuß) nicht überschreitet. Dieser Midspan ist kein Repeater und verstärkt das Ethernetdatensignal nicht. • Der Midspan hat keinen EIN/AUS-Schalter, schließen Sie den Midspan einfach an eine AC-Stromquelle an. User Guide DS50003422A-page 8 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 34 Installation des PoE Midspan-Geräts • PoE-Midspan-AC-Stromleitungen sollten an eine Steckdose angeschlossen werden, die in der Nähe des Geräts montiert und leicht zugänglich sein sollte. User Guide DS50003422A-page 9 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 35 Verbinden Sie das andere Ende des Erdungskabels mit der Erdung an Ihrem Installationsort. Ziehen Sie die Schraube auf 1,1 bis 1,7 Nm an. Abbildung 3-4. Erdungsanschluss To Earth Ground User Guide DS50003422A-page 10 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 36 Die Schrauben sind nicht im Lieferumfang des Kits enthalten. Ziehen Sie jede Schraube an, bis der Midspan sicher an der Montageoberfläche befestigt ist. Anmerkung: Die Abmessungen in der obigen Abbildung sind in Millimeter angegeben. User Guide DS50003422A-page 11 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 37 Mast mit einem großen Durchmesser: In der folgenden Teileliste sind die Bauteile aufgeführt, die für die Montage der Metallhalterung an einem Mast mit einem Durchmesser von 76 mm bis 203 mm (3 Zoll bis 8 Zoll) erforderlich sind. User Guide DS50003422A-page 12 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 38 Installation des PoE Midspan-Geräts Verbinden Sie bei Masten mit kleinem und großem Durchmesser den Erdungsbolzen mit dem Erdungspunkt des Montage-Kits. Achtung: Die Halterung muss mit der Erdung verbunden sein. User Guide DS50003422A-page 13 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 39 Das Gerät muss so installiert werden, dass die Dateneingangs- und Datenausgangs- sowie Stromausgangs-Ports (DATA IN und DATA & PWR OUT) nach unten zeigen, wie in den folgenden Abbildungen dargestellt. User Guide DS50003422A-page 14 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 40 Installation des PoE Midspan-Geräts User Guide DS50003422A-page 15 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 41: Installation Der Kabel

    Führen Sie das AC-Kabel durch die Teile, quetschen Sie es und schrauben Sie die Adern mit einem Drehmoment von 0,8 Nm fest. Schieben Sie das Gehäuse entsprechend den Führungsschienen in das andere Gehäuse, wie in der folgenden Abbildung gezeigt. User Guide DS50003422A-page 16 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 42: Rj45-Netzkabelinstallation

    Schieben Sie die Unterlegscheibe sowie die obere Kappe in Richtung Midspan und ziehen Sie die obere Kappe am Dateneingangs-Port (DATA IN) handfest an. Anmerkung: Sichern Sie die Verschraubung, bis die Gummidichtung fest um das Kabel geschlossen ist. User Guide DS50003422A-page 17 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 43 Für nicht AF/AT-konforme Geräte – verwenden Sie einen Splitter; stellen Sie sicher, dass der Splitter in der Nähe des Endgeräts und nicht am Midspan angeschlossen ist. Diese Geräte sind nur zum Verwenden im Außenbereich vorgesehen. User Guide DS50003422A-page 18 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 44: Daten- Und Stromanschluss

    Schutzklassen IP66 und IP67 entspricht. Etikett Beschreibung LINE IN Netzeingang, 100 V –240 V DATA IN Dateneingang zum Ethernet (Netzwerk)-Switch DATA & PWR OUT Daten- und Stromausgang zum Ethernet-Terminal User Guide DS50003422A-page 19 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 45: Fehlersuche

    Stellen Sie sicher, dass Sie für diese Verbindung ein gerades (nicht gekreuztes) Standard-UTP/FTP-Kabel der Kategorie 5 mit allen vier Paaren verwenden. Stellen Sie sicher, dass die Länge des Ethernet-Kabels von der Ethernet-Quelle zum Remote-Endgerät weniger als 100 Meter beträgt. User Guide DS50003422A-page 20 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 46: Technische Daten

    Adernpaaren: 3 - 6, 4 - 5 und 1 - 2, 7 - 8 AC-Stromeingang (AC Power IN) 3 Pins AC-Stromeingang – Leitung, 3 Pins AC-Stromeingang – Leitung, Neutral und Erdung Neutral und Erdung User Guide DS50003422A-page 21 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 47: Technischer Support

    Sollten bei der Installation oder Verwendung dieses Produkts Probleme auftreten, wenden Sie sich an den technischen Support von Microchip über die Webseite oder unter der folgenden Nummer: USA/Kanada Telefon: +1 877 480 2323 Internet: www.microchip.com/support User Guide DS50003422A-page 22 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 48: Überarbeitungsübersicht

    Überarbeitungsübersicht Überarbeitungsübersicht Überarbeitung Datum Beschreibung 10/2022 Erste Überarbeitung. User Guide DS50003422A-page 23 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 49: Informationen Zu Microchip

    “unbreakable”. Code protection is constantly evolving. Microchip is committed to continuously improving the code protection features of our products. User Guide DS50003422A-page 24 © 2022 Microchip Technology Inc. and its subsidiaries...
  • Page 50: Legal Notice

    Das Adaptec-Logo, Frequency on Demand, Silicon Storage Technology und Symmcom sind eingetragene Warenzeichen von Microchip Technology Inc. in anderen Ländern. GestIC ist ein eingetragenes Warenzeichen von Microchip Technology Germany II GmbH & Co. KG, einer Tochtergesellschaft von Microchip Technology Inc., in anderen Ländern.
  • Page 51: Qualitätsmanagementsystem

    Alle anderen hier erwähnten Warenzeichen sind Eigentum der jeweiligen Unternehmen. © 2022, Microchip Technology Incorporated und seine Tochtergesellschaften. Alle Rechte vorbehalten. ISBN: 978-1-6683-1537-8 Qualitätsmanagementsystem Für Informationen über die Qualitätsmanagementsysteme von Microchip besuchen Sie bitte www.microchip.com/ quality. User Guide DS50003422A-page 26 ©...
  • Page 52 Tel.: 631-435-6000 Schweden - Stockholm San Jose, CA Tel.: 46-8-5090-4654 Tel.: 408-735-9110 UK - Wokingham Tel.: 408-436-4270 Tel.: 44-118-921-5800 Kanada - Toronto Fax: 44-118-921-5820 Tel.: 905-695-1980 Fax: 905-695-2078 User Guide DS50003422A-page 27 © 2022 Microchip Technology Inc. and its subsidiaries...
