PoE Midspan User Installation Guide
Introduction
Microchip's family of Power over Ethernet (PoE) Midspans PD-9501-xxGCO/AC is a single-port high-power PoE
outdoor solution that offers a cost-effective IEEE
802.3af/at standard guaranteeing 60W of power and ensures safe and reliable operation in outdoor environments
for standard PoE data terminal. The PD-9501-xxGCO/AC supports emerging wireless 10 Gbps devices, such as
®
wireless IEEE
802.11ac access points.
PoE midspan powers devices that are PoE enabled or equipped to receive PoE. These devices are called powered
devices (PDs).
Features
PoE Midspans offer the following key features:
•
Outdoor Rated: IP66 and IP67
•
Extended Temperature Range: –40 °C to 65 °C
•
Supports 10/100/1000 Mbps and 2.5/5/10 Gbps Data Rates
•
Standards Compliant: IEEE 802.3bt and IEEE 802.3af/at
•
Plug and Play Installation
•
Includes Integrated Surge Protection
©
2022 Microchip Technology Inc.
and its subsidiaries
PD-9501-xxGCO/AC
®
802.3bt compliant solution and pre-BT support for IEEE
User Guide
®
DS50003340A-page 1
Advertisement
Chapters
Related Manuals for Microchip Technology PD-9501-GCO/AC Series
Summary of Contents for Microchip Technology PD-9501-GCO/AC Series
- Page 1 Extended Temperature Range: –40 °C to 65 °C • Supports 10/100/1000 Mbps and 2.5/5/10 Gbps Data Rates • Standards Compliant: IEEE 802.3bt and IEEE 802.3af/at • Plug and Play Installation • Includes Integrated Surge Protection User Guide DS50003340A-page 1 © 2022 Microchip Technology Inc. and its subsidiaries...
-
Page 2: Table Of Contents
The Microchip Website..........................17 Product Change Notification Service....................17 Customer Support..........................17 Microchip Devices Code Protection Feature..................17 Legal Notice............................17 Trademarks............................18 Quality Management System........................ 19 Worldwide Sales and Service........................20 User Guide DS50003340A-page 2 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 3: Standards And Safety Guidelines
Microchip’s PD-9501-xxGCO/AC is designed according to the following requirements. • ITU-T K.21 (6 kV enhanced surge)—Port and AC Main • EN61000-4-5 (6 kV)—Port and AC Main • GR-1089-CORE Issue 6—Port Only User Guide DS50003340A-page 3 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 4: Safety Information
Data and Data and Power ports of the midspan unit are shielded RJ45 data sockets. They cannot be used as Plain Old Telephone Service (POTS) sockets. Only connect RJ45 data connectors to these sockets. • When disposing this product, follow all local laws and regulations. User Guide DS50003340A-page 4 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 5: Information En Matière De Sécurité
être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble. • Pour disposer/jeter ce produit, suivre les lois et règlements locaux. User Guide DS50003340A-page 5 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 6: Poe Midspan Unit Installation (Outdoor Unit)
Quick Installation Guide Additional Tools The following table lists the additional tools required to install the midspan unit. Quantity Part Screwdriver Wire stripper Solid Wrench No. 27 or Adjustable Wrench User Guide DS50003340A-page 6 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 7: Midspan Unit Installation
The midspan has no ON-OFF switch, simply plug the midspan to an AC power source. • PoE midspan AC power lines must be connected to the socket-outlet that shall be installed near the equipment and be easily accessible. User Guide DS50003340A-page 7 © 2022 Microchip Technology Inc. and its subsidiaries... - Page 8 The screws are not provided with the kit. Tighten each screw until the midspan unit is securely attached to the mounting surface. Note: The dimensions in the above figure are in millimeters. User Guide DS50003340A-page 8 © 2022 Microchip Technology Inc. and its subsidiaries...
- Page 9 Pole bracket supports poles with diameters ranging from 60 mm to 200 mm (2.5 inches to 8 inches). • The unit must be installed with DATA IN, and DATA & PWR OUT ports facing down, as shown in the following figures. User Guide DS50003340A-page 9 © 2022 Microchip Technology Inc. and its subsidiaries...
-
Page 10: Installation Of Cables
Approved for indoor and outdoor applications. The following figure shows how to connect the AC power cable to the midspan unit: Figure 4-1. Connecting the AC Power Cable to the Unit User Guide DS50003340A-page 10 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 11: Rj45 Cable Installation
RJ45 cable to the DATA & PWR OUT port. Notes: Use cable up to 5 Gig Cat 5e and above outdoor grade. Use cable up to 10 Gig Cat 6 and above outdoor grade. User Guide DS50003340A-page 11 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 12: Data And Power Connection
LINE IN Power input, 100 V –240 V DATA IN Data in to the Ethernet (network) switch DATA & PWR OUT Data and power out to the Ethernet terminal User Guide DS50003340A-page 12 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 13: Troubleshooting
UTP/FTP Category 5/5e/6 straight (non- crossover) cabling, with all four pairs. Verify that the Ethernet cable length is less than 100 meters from Ethernet source to the remote terminal. User Guide DS50003340A-page 13 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 14: Specifications
5G/10GBase-T for the PD-9501-10GCO/AC or up to 7-8, 4-5 and 1-2, 3-6 2.5GBase-T for the PD-9501-25GCO/AC, plus 54 V AC Power IN 3 Pins AC power in – Line, Neutral and Earth Ground User Guide DS50003340A-page 14 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 15: Technical Support
If you encounter problems while installing or using this product, consult the Microchip technical support team through the website or contact on the following number: USA/Canada Telephone: +1 877 480 2323 Internet: www.microchip.com/support User Guide DS50003340A-page 15 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 16: Revision History
PD-9501-xxGCO/AC Revision History Revision History Revision Date Description 06/2022 Initial revision. User Guide DS50003340A-page 16 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 17: Microchip Information
Microchip products with your application. Use of this information in any other manner violates these terms. Information regarding device applications is provided only for your convenience and may be superseded User Guide DS50003340A-page 17 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 18: Trademarks
The Adaptec logo, Frequency on Demand, Silicon Storage Technology, Symmcom, and Trusted Time are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries. -
Page 19: Quality Management System
PD-9501-xxGCO/AC Quality Management System For information regarding Microchip’s Quality Management Systems, please visit www.microchip.com/quality. User Guide DS50003340A-page 19 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 20: Worldwide Sales And Service
Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 User Guide DS50003340A-page 20 © 2022 Microchip Technology Inc. and its subsidiaries... - Page 21 Erweiterter Temperaturbereich: -40 °C bis 65 °C • Unterstützt Datenraten von 10/100/1000 Mbps und 2,5/5/10 Gbps • Konform mit den Standards: IEEE 802.3bt und IEEE 802.3af/at • Plug-and-Play-Montage • Inklusive integrierter Überspannungsschutz User Guide DS50003340A-page 1 © 2022 Microchip Technology Inc. and its subsidiaries...
- Page 22 Schnittstelle..........................15 Technischer Support..........................16 Überarbeitungsübersicht........................17 The Microchip Website..........................18 Product Change Notification Service......................18 Customer Support............................18 Microchip Devices Code Protection Feature....................18 Legal Notice..............................18 Trademarks..............................19 User Guide DS50003340A-page 2 © 2022 Microchip Technology Inc. and its subsidiaries...
- Page 23 PD-9501-xxGCO/AC Quality Management System........................20 Worldwide Sales and Service........................21 User Guide DS50003340A-page 3 © 2022 Microchip Technology Inc. and its subsidiaries...
-
Page 24: Normen Und Sicherheitsrichtlinien
Der PD-9501-xxGCO/AC von Microchip wurde gemäß den folgenden Anforderungen entwickelt. • ITU-T K.21 (6 kV erweiterte Überspannung)—Port und AC-Hauptschalter • EN61000-4-5 (6 kV)—Port und AC-Hauptschalter • GR-1089-CORE Ausgabe 6—Nur Port User Guide DS50003340A-page 4 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 25: Sicherheitshinweise
Sie können nicht als Plain Old Telephone Service (POTS)-Buchsen verwendet werden. Schließen Sie nur RJ45-Datenstecker an diese Buchsen an. • Beachten Sie bei der Entsorgung dieses Produkts alle örtlichen Gesetze und Vorschriften. User Guide DS50003340A-page 5 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 26: Information En Matière De Sécurité
être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble. • Pour disposer/jeter ce produit, suivre les lois et règlements locaux. User Guide DS50003340A-page 6 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 27: Poe-Midspan-Geräte-Installation (Modell Für Den Außenbereich)
Zusätzliche Werkzeuge In der folgenden Tabelle finden Sie die zusätzlichen Werkzeuge, die für die Installation des Midspan-Geräts erforderlich sind. Menge Teil Schraubendreher Abisolierzange Schraubenschlüssel Nr. 27 oder verstellbarer Schraubenschlüssel User Guide DS50003340A-page 7 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 28: Installation Des Midspan-Geräts
Der Midspan hat keinen EIN/AUS-Schalter, schließen Sie den Midspan einfach an eine AC-Stromquelle an. • PoE-Midspan-AC-Stromleitungen sollten an eine Steckdose angeschlossen werden, die in der Nähe des Geräts montiert und leicht zugänglich sein sollte. User Guide DS50003340A-page 8 © 2022 Microchip Technology Inc. and its subsidiaries... - Page 29 Die Schrauben sind nicht im Lieferumfang des Kits enthalten. Ziehen Sie jede Schraube an, bis der Midspan sicher an der Montageoberfläche befestigt ist. Anmerkung: Die Abmessungen in der obigen Abbildung sind in Millimeter angegeben. User Guide DS50003340A-page 9 © 2022 Microchip Technology Inc. and its subsidiaries...
- Page 30 Das Gerät muss so installiert werden, dass die Dateneingangs- und Datenausgangs- sowie Stromausgangs-Ports (DATA IN und DATA & PWR OUT) nach unten zeigen, wie in den folgenden Abbildungen dargestellt. User Guide DS50003340A-page 10 © 2022 Microchip Technology Inc. and its subsidiaries...
-
Page 31: Installation Der Kabel
Durchm. 5,0 mm – 9,5 mm Zugelassen für Anwendungen im Innen- und Außenbereich. Die folgende Abbildung zeigt, wie das AC-Netzkabel an die Midspan-Einheit angeschlossen wird: Abbildung 4-1. Anschließen des AC-Netzkabels an das Midspan-Gerät User Guide DS50003340A-page 11 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 32: Rj45-Netzkabelinstallation
Verwenden Sie Kabel bis zu 5 Gig Cat 5e und darüber für den Außenbereich. Verwenden Sie Kabel bis zu 10 Gig Cat 6 und darüber für den Außenbereich. User Guide DS50003340A-page 12 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 33: Daten- Und Stromanschluss
Schutzklassen IP66 und IP67 entspricht. Etikett Beschreibung LINE IN Netzeingang, 100 V –240 V DATA IN Dateneingang zum Ethernet (Netzwerk)-Switch DATA & PWR OUT Daten- und Stromausgang zum Ethernet-Terminal User Guide DS50003340A-page 13 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 34: Fehlersuche
Standard-UTP/FTP-Kabel der Kategorie 5/5e/6 mit allen vier Paaren verwenden. Stellen Sie sicher, dass die Länge des Ethernet-Kabels von der Ethernet- Quelle zum Remote-Endgerät weniger als 100 Meter beträgt. User Guide DS50003340A-page 14 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 35: Technische Daten
7 - 8, 4 - 5 und 1 - 2, 3 - 6 2,5GBase-T für den PD-9501-25GCO/AC, plus 54 V AC-Stromeingang (AC Power IN) 3 Pins AC-Stromeingang - Leitung, Neutral und Erdung User Guide DS50003340A-page 15 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 36: Technischer Support
Sollten bei der Installation oder Verwendung dieses Produkts Probleme auftreten, wenden Sie sich an den technischen Support von Microchip über die Webseite oder unter der folgenden Nummer: USA/Kanada Telefon: +1 877 480 2323 Internet: www.microchip.com/support User Guide DS50003340A-page 16 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 37: Überarbeitungsübersicht
PD-9501-xxGCO/AC Überarbeitungsübersicht Überarbeitungsübersicht Überarbeitung Datum Beschreibung 06/2022 Erste Überarbeitung. User Guide DS50003340A-page 17 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 38: The Microchip Website
It is your responsibility to ensure that your application meets with your specifications. Contact your local Microchip sales office for additional support or, obtain additional support at www.microchip.com/en-us/support/ design-help/client-support-services. User Guide DS50003340A-page 18 © 2022 Microchip Technology Inc. and its subsidiaries... -
Page 39: Trademarks
The Adaptec logo, Frequency on Demand, Silicon Storage Technology, Symmcom, and Trusted Time are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries. - Page 40 PD-9501-xxGCO/AC Quality Management System For information regarding Microchip’s Quality Management Systems, please visit www.microchip.com/quality. User Guide DS50003340A-page 20 © 2022 Microchip Technology Inc. and its subsidiaries...
- Page 41 Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 User Guide DS50003340A-page 21 © 2022 Microchip Technology Inc. and its subsidiaries...
