Summary of Contents for ESP MAGDUO8B

  • Page 2 ESP’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, ESP shall be under no liability whatsoever in respect of such contents.

  • Page 3: Table Of Contents

    MAGDUO Control Panel Engineering and Commissioning Manual Contents Introduction .......................... 5 System Design ......................5 Equipment Guarantee ....................5 Anti Static Handling Guidelines ................5 Warning ........................5 EMC .......................... 6 The MAGDUOSystem ......................6 Control Panel ........................7 Mounting the Control Panel ..................7 Physical Dimensions ....................
  • Page 4 MAGDUO Control Panel Engineering and Commissioning Manual Installation and Commissioning ..................60 Installation 1st Stage ....................60 Installation 2nd Stage ....................60 Commissioning ......................61 End User Training ..................... 61 Maintenance ......................61 Fault Finding ........................62 Summary of Faults....................62 Finding Zone Faults ....................

  • Page 5: Introduction

    MAGDUO Control Panel Engineering and Commissioning Manual Introduction This Manual is intended as a guide to the engineering and commissioning principles of the MAGDUO 2- wire Fire Detection and Alarm system and covers the system hardware information only. Due to the complexity and inherent importance of a system covering a ‘Life Protection Risk’, training on this equipment is essential and commissioning should only be carried out by competent and approved persons.

  • Page 6: Emc

    MAGDUO Control Panel Engineering and Commissioning Manual This equipment when installed is subject to the EMC directive 2014/108/EC. It is also subject to UK Statutory Instrument 2006 No. 3418. To maintain EMC compliance, this system must be installed as defined within this manual. Any deviation from this renders the installer liable for any EMC problems that may occur either to the equipment or to any other equipment affected by the installation.

  • Page 7: Control Panel

    MAGDUO Control Panel Engineering and Commissioning Manual Zone test facility EN54-2 Clause 10 Input/output facilities These facilities are described elsewhere in this manual. Control Panel Mounting the Control Panel First identify the proposed location for the control panel. Ensure that the control panel will be easily accessible and that account is taken of any subsequent work that may affect access.

  • Page 8: Power Supply Unit

    MAGDUO Control Panel Engineering and Commissioning Manual Power Supply Unit The mains supply should be dedicated to the Fire Alarm Panel and should be clearly labelled ‘FIRE ALARM: DO NOT SWITCH OFF’ at all isolation points. The Fire Alarm Panel 230V AC supply requires a 3 amp with local isolation and fixed wiring between 0.75 mm and 2.5 mm...

  • Page 9: General Assembly

    (at the SCRN terminal provided, not at any earthing point). Do not connect the screen to any device back box used other than those supplied by ESP. 3. The cable screen continuity must be maintained at every point of the circuit, using the terminals provided or a suitable connection block.

  • Page 10: System Wiring Schematic

    MAGDUO Control Panel Engineering and Commissioning Manual System Wiring Schematic The following schematic may prove useful as an aid to understanding the cable requirements for the system; 1-8 MAGDUO zones. Cabled in 2 core 1.5mm Screened cable complying with BS 5839: Pt 1: 2017 Category 1.

  • Page 11: Control Panel Connections

    MAGDUO Control Panel Engineering and Commissioning Manual Control Panel Connections TERMINAL DESCRIPTION Overview- 2 zone panel USB-B USB-B CONNECTION FOR PC LINK MONITORED I/P Monitored Input positive connection MI1 + Monitored Input 0V connection MI1 - Field cable screen connection SCRN PROG I/P 1+2 Programmable Input positive connection...

  • Page 12: Overview - 4 / 8 Zone Panel

    MAGDUO Control Panel Engineering and Commissioning Manual Overview – 4 / 8 zone Panel TERMINAL DESCRIPTION USB-B USB-B CONNECTION FOR PC LINK NETWORK NET A Peripheral Bus Connections NET B Peripheral Bus Connections SCRN Peripheral Bus Connections NET A Peripheral Bus Connections NET B Peripheral Bus Connections SCRN...

  • Page 13: Programmable Inputs 1 & 2

    MAGDUO Control Panel Engineering and Commissioning Manual Refer to the ancillary equipment manuals for network connections. Note: Ancillary equipment e.g. repeaters connected to the network do not meet EN 54-2 requirements. Monitored Input: MI1+, MI1-, SCRN ON BOARD PCB FIELD CONNECTIONS MI1 + N/O CONTACT MI1 -...

  • Page 14: Magduo Device Zones Wiring

    (at the SCRN terminal provided, not at any earthing point). Do not connect the screen to any device back box used other than those supplied by ESP. 3. The cable screen continuity must be maintained at every point of the circuit, using the terminals provided or a suitable connection block.

  • Page 15: Conventional Device Zones Wiring

    (at the SCRN terminal provided, not at any earthing point). Do not connect the screen to any device back box used other than those supplied by ESP. 3. The cable screen continuity must be maintained at every point of the circuit, using the terminals provided or a suitable connection block.

  • Page 16: Fault Relay

    MAGDUO Control Panel Engineering and Commissioning Manual Fault Relay: C, N/C, N/O ON BOARD PCB FIELD CONNECTIONS COMMON NORMALLY CLOSED NORMALLY OPEN The fault relay is derived from a single pole change over ‘volt-free’ relay contact which is not fault monitored.
  • Page 17 MAGDUO Control Panel Engineering and Commissioning Manual Monitored Outputs 1 and 2: MO+, MO-, SCRN ON BOARD PCB FIELD CONNECTIONS 10k EOL MO - SCREEN SCREEN SCREEN Outputs 1 and 2 are monitored circuits which may be configured to monitor for open and short circuit faults with a 10k EOL resistor.

  • Page 18: Batteries

    For extended backup times an external battery box can be purchased from ESP. This includes extended battery connection leads. This requires 2 x 12V 7.0Ah – 7.2Ah batteries. When using the external battery box the internal panel batteries must be removed.

  • Page 19: Write Protect / Write Enable Switch

    MAGDUO Control Panel Engineering and Commissioning Manual Write Protect / Write Enable Switch Note: 4 Zone / 8 Zone Panel version shown The write protect / write enable switch is a two position switch which is normally set to stop options in the engineer menu from being inadvertently changed.
  • Page 20 MAGDUO Control Panel Engineering and Commissioning Manual Expansion Cards There are two expansion card options available for the MAGDUO4. Part number MAGDUOZC4 will provide 4 additional MAGDUO zones and part number MAGDUOCC4 will provide an additional 4 conventional zones. The zone expansion card provides an additional 4 MAGDUO zones which converts a MAGDUO4 panel to an 8 zone panel.

  • Page 21: General Operation Of Control Panel

    MAGDUO Control Panel Engineering and Commissioning Manual General Operation of Control Panel Control Panel Front Note : 4 Zone / 8 Zone Panel version shown General Indication LEDs Control Panel Information Window Zonal Indication LEDs Fire Alarm Controls / Controls Enabled Keyswitch System Indication LEDs System Controls...

  • Page 22: Led Indication

    MAGDUO Control Panel Engineering and Commissioning Manual LED Indication Note : 4 Zone / 8 Zone Panel version shown The operation of the LED indication on the front of the control panel is described below. The LED indication on the panel can also be confirmed by checking the message displayed in the panel information screen or by accessing the relevant event log from the panel menu.
  • Page 23 MAGDUO Control Panel Engineering and Commissioning Manual ZONE SOUNDERS Flashing A fault condition is present on a MAGDUO zone circuit. Yellow Continuous A device or an action associated with the zone sounder circuits has been disabled. Flashing A fault condition is present on the monitored fire FIRE OUTPUTS Yellow circuit.

  • Page 24: Fire Alarm Controls

    MAGDUO Control Panel Engineering and Commissioning Manual Fire Alarm Controls Note : 4 Zone / 8 Zone Panel version shown The main Fire Alarm Controls may be enabled by turning the key switch to the controls enabled position to go from access level 1 to AL2A, or by entering a valid access code to all modes above AL1.

  • Page 25: Access Level 1 (Normal)

    MAGDUO Control Panel Engineering and Commissioning Manual Access Level 1 (Normal): Controls Enabled LED off At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the following System Controls will only be accessible if a fire, fault or disablement is active on the panel: NORMAL 1.

  • Page 26: Access Level 2A (User)

    MAGDUO Control Panel Engineering and Commissioning Manual Access Level 2A (User): Enable Controls LED on At Access Level 2A (User), the main Fire Alarm Controls are enabled and the following System Controls are accessible: USER (1111) 1. View Current Events 1.
  • Page 27 MAGDUO Control Panel Engineering and Commissioning Manual 1. View Current Events 4. Current Warnings The Active Log will display any current warnings. These are displayed 01/09/09 22:26 USER in text format and may be scrolled through by pressing the UP and DOWN keys.

  • Page 28: Access Level 2B (Supervisor)

    MAGDUO Control Panel Engineering and Commissioning Manual Access Level 2B (Supervisor ): Enable Controls LED flashing slowly At Access Level 2B (Supervisor), the main Fire Alarm Controls are enabled and the following System Controls are accessible. Note: A system reset must be done after any changes are made in order for them to take effect. SUPR (2222) 1.
  • Page 29 MAGDUO Control Panel Engineering and Commissioning Manual 1. View Current Events 1. Current Fires The Active Log will display any current fires. These are displayed in FIRE 001 OF 001 text format and may be scrolled through by pressing the UP and Z01: ZONE 01 DOWN keys.
  • Page 30 MAGDUO Control Panel Engineering and Commissioning Manual 1. Test Cntrls & Disp 2. Test Modes 3. Test Buzzer The Test Buzzer function toggles on and off to ensure correct buzzer 01/09/09 22:26 SUPR operation unless the buzzer has been disabled by fitting a jumper link BUZZER TESTING..
  • Page 31 MAGDUO Control Panel Engineering and Commissioning Manual 2. Test Modes 2. Test Zone 3. System Test The System Test function allows the selection of one or more 01/09/09 22:26 SUPR detection-zones to operate in a ‘one-man walk test mode with local SYSTEM TEST (ZONES) sound’.
  • Page 32 MAGDUO Control Panel Engineering and Commissioning Manual 5. Peripheral Buss 3. Enable/ Disable This allows the Peripheral Buss to be switched on or off. 01/09/09 22:26 SUPR Note: Ancillary equipment e.g. repeaters connected to the PERIPH BUSS: OFF peripheral bus do not meet EN 54-2 requirements. 1.

  • Page 33: Access Level 3 (Engineer)

    MAGDUO Control Panel Engineering and Commissioning Manual Access Level 3 (Engineer): Controls Enabled LED flashing quickly At Access Level 3A (Engineer), the main Fire Alarm Controls are enabled, and the following System Controls are accessible. To change options contained within the engineer menu, enter Access Level 3B.
  • Page 34 MAGDUO Control Panel Engineering and Commissioning Manual 1. All Event Logs 5. View Logs 2. Fire Logs 3. Fault Logs 4. Panel Event Logs 6. Zones 1. Zone Status 2. Zone Description 3. Zone Mode 1. Set Zone Type 7. Alarm Confirmation 2.
  • Page 35 MAGDUO Control Panel Engineering and Commissioning Manual 10. Panel I/O 1. Programmable I/P 1 2. Programmable I/P 2 3. Monitored I/P 4. Monitored O/P 1 5. Monitored O/P 2 6. Fire Relay 7. Fault Relay 11. Peripheral Buss 1. RDU 1 Supervise 1.
  • Page 36 MAGDUO Control Panel Engineering and Commissioning Manual 1. View Current Events 2. Current Faults The Active Log will display any current faults. These are displayed in FAULT 001 OF 001 text format and may be scrolled through by pressing the UP and Z00: NA DOWN keys.
  • Page 37 MAGDUO Control Panel Engineering and Commissioning Manual 2. Test Modes 1. Test Cntrl & Display 4. Test Keyboard The Test Keyboard function enables the user to select each button to 01/09/09 22:26 ENGR ensure the correct function on the screen. Press the ESC key TWICE KEYBOARD TESTING..
  • Page 38 MAGDUO Control Panel Engineering and Commissioning Manual 2. Test Modes 3. Activate Outputs 1. Fire Relay Within this menu; selecting option 1. ON will turn on the fire 01/09/09 22:26 ENGR relay and selecting option 2. OFF, will turn the fire relay off. FIRE RELAY: OFF If the fire relay is left in the ON or OFF condition and the 1.ON...
  • Page 39 MAGDUO Control Panel Engineering and Commissioning Manual 2. Test Modes 4. Test inputs 3. Monitored I/P 01/09/09 22:26 ENGR This will test monitored input and when it is triggered MON I/P TESTING. INPUT ACTIVATED will be displayed on line 3 of the INPUT ACTIVATED display.
  • Page 40 MAGDUO Control Panel Engineering and Commissioning Manual 5. Peripheral Buss 3. Enable/ Disable 01/09/09 22:26 SUPR This allows the Peripheral Buss to be switched on or off. PERIPH BUSS: OFF Note: Ancillary equipment e.g. repeaters connected to the peripheral bus do not meet EN 54-2 requirements. 2.
  • Page 41 MAGDUO Control Panel Engineering and Commissioning Manual The Panel Event Log will display a log of events generated from the EVT 069 OF 069 panel. These are displayed in text format and may be scrolled through Z00: NA by pressing the UP and DOWN keys. Press the ESC key to exit the Engineer Mode 01/09/09 menu.
  • Page 42 MAGDUO Control Panel Engineering and Commissioning Manual 1. COMM. – Communal Zone – Smoke detectors on this zone will immediately activate all sounders 01/09/09 22:26 ENGR and outputs (subject to any other delays ZONE: COMMUNAL programmed into the system). 1.COMM. 2.DWELL. 2.
  • Page 43 MAGDUO Control Panel Engineering and Commissioning Manual selected zone will be delayed for the time period set in the ‘Delay Timer’ menu. 8. Alarm Delay 2. Delay Fire Relay This active control will allow the engineer to set an alarm delay for the 01/09/09 22:26 ENGR panel fire relay.
  • Page 44 MAGDUO Control Panel Engineering and Commissioning Manual the time period set in the ‘Delay Timer’ menu. 8. Alarm Delay 5. Delay Timer This active control will allow the engineer to set the alarm delay timer. 01/09/09 22:26 ENGR Press 0 – 5 to set the timer from No Delay to 5 Minutes, then press ALARM DELAY ENTER to confirm the change.
  • Page 45 MAGDUO Control Panel Engineering and Commissioning Manual the cursor between options and the alphanumeric keypad to enter the code. Press the ENTER key to confirm the change. 9. Panel Details 2. Access Code 3. Engineer This active control will allow the engineer to change the code for EXISTING CODE:3333 access to the engineer menus.
  • Page 46 MAGDUO Control Panel Engineering and Commissioning Manual 1. ON – Once a week at a determined day and time the routine service light will illuminate and the fault buzzer will sound to remind the user to perform their weekly test. The user will need to enter the user code or turn the key and reset the panel to clear.
  • Page 47 MAGDUO Control Panel Engineering and Commissioning Manual 3. TECHNICAL EVENT – Operation of I/P 1 will signal a technical event at the control panel. Panel outputs will be triggered but the control panel will read technical alarm and no fire indication will be given. 4.
  • Page 48 MAGDUO Control Panel Engineering and Commissioning Manual UP and DOWN arrow keys to toggle through the following options. To confirm the changes press ENTER. 1. LATCH – Operation of I/P 1 will signal a technical event at the control panel. All outputs will trigger and the panel will latch into fire.
  • Page 49 MAGDUO Control Panel Engineering and Commissioning Manual 10. Panel I/O 1. Programmable I/P 1 1. Input Type 4. Disablement This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of the disablement event set for programmable input 1. Use 1.
  • Page 50 MAGDUO Control Panel Engineering and Commissioning Manual 10. Panel I/O 2. Programmable I/P 2 1. Input Type This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of programmable input 2. Use the UP and DOWN arrow keys 1.CONTROL EVENT to toggle through the following options.
  • Page 51 MAGDUO Control Panel Engineering and Commissioning Manual 10. Panel I/O 2. Programmable I/P 2 1. Input Type 2. Remote Fire Event This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of the remote fire event set for programmable input 2. Use 1.REMOTE FIRE- FULL the UP and DOWN arrow keys to toggle through the following options.
  • Page 52 MAGDUO Control Panel Engineering and Commissioning Manual 10. Panel I/O 2. Programmable I/P 2 2. Description This option allows the engineer to change the text that will be displayed 01/09/09 22:26 ENGR on the panel when Programmable I/P 2 is activated. This is displayed EDIT PROGRAMABLE IP2 in text format and may be scrolled through by pressing the LEFT and NAME: PROG I/P 2...
  • Page 53 MAGDUO Control Panel Engineering and Commissioning Manual 3. Monitored I/P 1. Control Event 10. Panel I/O 1. Input Type This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of the control event set for monitored input. Use the UP and 1.SILENCE ALARMS DOWN arrow keys to toggle through the following options.
  • Page 54 MAGDUO Control Panel Engineering and Commissioning Manual 3. Monitored I/P 4. Disablement 10. Panel I/O 1. Input Type This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of the disablement event set for monitored input. Use the UP 1.
  • Page 55 MAGDUO Control Panel Engineering and Commissioning Manual alphanumeric keypad to change that character. After changing a character the cursor will automatically move to the next position. To confirm the changes press ENTER. 10. Panel I/O 5. Monitored O/P 2 1. Output Type This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of Monitored O/P 2.
  • Page 56 MAGDUO Control Panel Engineering and Commissioning Manual Note: Ancillary equipment e.g. repeaters connected to the 11. Peripheral Buss peripheral bus do not meet EN 54-2 requirements. 01/09/09 22:26 ENGR 1. PB RDU Supervise 1. PB Comm Configure Press Enter Key 1.

  • Page 57: Alarm Delays

    MAGDUO Control Panel Engineering and Commissioning Manual Alarm Delays The following alarm outputs can be delayed for smoke detector alarms: Zone Outputs (zone sounders & IO outputs) Fire Relay Monitored output 1 Monitored output 2 Zone Of Origin Manual Call Points always give instant operation, whichever type of zone they may be a part of. Note: If the Zone Mode is set to CP/DET then a heat detector alarm will operate in the same way as a smoke detector alarm and use the ‘Delay’...

  • Page 58: Alarm Confirmation

    MAGDUO Control Panel Engineering and Commissioning Manual Alarm Confirmation Introduction The instructions in this section apply only to the Alarm Confirmation mode which is a part of the MAGDUO control panel and is supplementary to the rest of this manual. The Alarm Confirmation technology has been designed primarily to address the problem of unwanted alarms in apartment blocks or ‘Houses of Multiple Occupancy’...

  • Page 59: Zones - Confirmation Delay For Dwelling Areas

    MAGDUO Control Panel Engineering and Commissioning Manual Zones – ‘Confirmation Delay’ for Dwelling Areas Dwelling zones are those covering apartments or private living areas. The activation of any smoke detector in these areas generates an ‘Alarm Confirmation Warning’ in that area but no indication shows on the control panel.
  • Page 60 MAGDUO Control Panel Engineering and Commissioning Manual The detector DIL switch number 2 may be used to enable the ‘Logical Link’ which links the operation of the sounder to that individual detector whilst in confirmation warning stage. If this is set to the off position, the Alarm Confirmation Warning will sound in the entire zone.

  • Page 61: Installation And Commissioning

    MAGDUO Control Panel Engineering and Commissioning Manual Installation and Commissioning Installation 1 Stage The installer must install the system wiring in the form of 2-core radial circuits. All cabling should be 2 core 1.5mm , screened and fire resistant, of an FP200 equivalent type. 4 core cable as a zone in and zone out must not be used, due to the possibility of data corruption.

  • Page 62: Commissioning

    MAGDUO Control Panel Engineering and Commissioning Manual Commissioning Commissioning the MAGDUO system involves programming and testing the system for correct operation. It is essential that every device is tested in every mode of operation, and that all programmed actions are observed for correct operation. This includes the smoke testing of smoke detectors, heat testing of heat detectors, testing of Manual Call Points, testing of all inputs, testing of all sounders and outputs, and fault testing of detectors by head removal.

  • Page 63: Fault Finding

    MAGDUO Control Panel Engineering and Commissioning Manual Fault Finding Summary of Faults Intermittent Zone Fault Tighten the unused ‘zone screw terminals’ at the EOL device and check all connections on the zone. Too many sounders on a zone. Remove some or adjust sound levels down. EOL resistor, capacitor or third party EOL device has been fitted.
  • Page 64 MAGDUO Control Panel Engineering and Commissioning Manual False Alarms Dirty or contaminated optical chambers. Replace with a new optical chamber or device. Incorrectly set smoke detector (smoke is not suitable for kitchens, bathrooms, boiler rooms etc., however, SM3 may be suitable outside a bathroom or kitchen but the individual situation needs to be looked at very carefully).

  • Page 65: Finding Zone Faults

    MAGDUO Control Panel Engineering and Commissioning Manual Finding Zone Faults A fault on a zone of the MAGDUO system may be found as follows: In order to prove whether the fault is control panel based or in the field (including the field wiring), swap the wires from the zone in fault with those in a clear zone (active but no fault) at the control panel.

  • Page 66: Advanced Connections

    MAGDUO Control Panel Engineering and Commissioning Manual Advanced Connections Magnetic Door Hold Units If magnetic door hold devices are required, it is recommended that they are connected as shown in the upper right diagram. This is suitable if it is convenient to cable to the control panel. An Input/Output module may also be used for this operation, in which case a relay would not be required.

  • Page 67: Connecting Two Panels Together

    MAGDUO Control Panel Engineering and Commissioning Manual Connecting Two Panels Together Only a maximum of two panels should be connected in this way. For each panel, configure a monitored input as a remote fire event as follows: Monitored inputs on panels 1 and 2 should be set to remote fire event with no relay activation. 10.

  • Page 68: Connecting Four Panels Together

    MAGDUO Control Panel Engineering and Commissioning Manual Connecting four Panels Together 10. Panel I/O 3. Monitored I/P MI 1. Input Type This active control will allow the engineer to view or change the 01/09/09 20:13 ENGR operation of the programmable input. Use the UP and DOWN arrow 1.CONTROL EVENT keys to toggle through the following options.
  • Page 69 MAGDUO Control Panel Engineering and Commissioning Manual circuit and will de-activate on SILENCE.
  • Page 70 MAGDUO Control Panel Engineering and Commissioning Manual 26-1649-03...

  • Page 71: Peripheral Buss Connections

    MAGDUO Control Panel Engineering and Commissioning Manual Peripheral Bus Connections Note: Ancillary equipment e.g. repeaters connected to the peripheral bus do not meet EN 54-2 requirements.
  • Page 72 MAGDUO Control Panel Engineering and Commissioning Manual External Battery box Only use the external battery box purchased from ESP which has been approved for use with the MAGDUO panel. This must be mounted beneath the MAGDUO panel. A template, conduit bushes and battery connection leads are provided with the external battery box kit.

  • Page 73: Technical Data

    MAGDUO Control Panel Engineering and Commissioning Manual Technical Data Control Panel Specification 2 Zone Panel 4 Zone Panel 8 Zone Panel Dimensions (mm) 331 x 331 x 99 Weight (excluding 2.25 kg 2.28 kg 2.36 kg batteries) Construction V0 rated ABS IP Rating IP 30 Cable Entry...

  • Page 74: Control Panel Fuses

    MAGDUO Control Panel Engineering and Commissioning Manual Control Panel Fuses and Protection 2 Zone Panel 4/8 Zone Panel Zone output 300 mA trip polyfuse Monitored Outputs 1 and 2 300 mA trip polyfuse Auxiliary 24V DC supply 300 mA trip polyfuse Mains T4A Time Delayed 20mm Ceramic (in mains terminal block) Battery Charger...

  • Page 75: Installation Checklist

    MAGDUO Control Panel Engineering and Commissioning Manual Installation Checklist Use the following checklist to ensure that your work is correct and that the commissioning engineer has the necessary information to complete the commissioning of the system If you require a commissioning visit, the engineer will require this sheet, along with ‘Zone Continuity and Insulation Test Results’...

  • Page 76: Commissioning Checklist

    MAGDUO Control Panel Engineering and Commissioning Manual Commissioning Checklist The following checklist may be used to ensure that all steps are taken. This is not a BS5839 certificate and serves as a reminder only and may need additional items added to suit your working practices. Step 1 Description Commissioning...

  • Page 77: Cable Continuity And Insulation Test Results

    MAGDUO Control Panel Engineering and Commissioning Manual Cable Continuity & Insulation Test Results After installation of the cable, and termination into all the relevant back-boxes, install a wire link between the zone +ve and –ve connections at the last device in order to be able to take cable continuity readings, removing it to take insulation readings.

  • Page 78: Fire Alarm System Notice

    MAGDUO Control Panel Engineering and Commissioning Manual FIRE ALARM SYSTEM NOTICE To Enable the Control Panel Keys You may gain access to the fire alarm controls by inserting the key turning ¼ turn or by entering the USER code (default 1111). The ‘Controls Enabled’...

  • Page 79: Fire Alarm User Notice

    MAGDUO Control Panel Engineering and Commissioning Manual FIRE ALARM USER NOTICE Note The Fire alarm system installed in this building has ‘Alarm Confirmation’ technology to help eliminate false alarms. Please read and understand the following information in order to make the most use of the system Operation When the detector within your area activates it will initially only operate the sounders within...

  • Page 80: Engineers Notes

    MAGDUO Control Panel Engineering and Commissioning Manual Engineers Notes 26-1649-03...
  • Page 81 MAGDUO Control Panel Engineering and Commissioning Manual Engineers Notes...
  • Page 82 MAGDUO Control Panel Engineering and Commissioning Manual Engineers Notes 26-1649-03...
  • Page 83 ESP’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has...
