Fast & Fluid Management TM280 Technical Notes

Technical Note
Applicable Equipment:
This is a guide to help prepare the Tintmaster Dispensers (TM280 / TM300) to normal operation after a
prolonged period of non-use.
Before trying to dispense colorant, please follow the steps below:

Tools

•
Paper towel / cloth / wet wipes for cleaning and/or to remove dried colorants
•
10 mm socket (to remove the side panels)
•
Anti mould spray if appropriate
•
Gloves and/or any other personal protective equipment recommended by site, employer, etc.

Procedure

1. Press E-Stop button on the dispenser
2. Check if the brush is clean, and that there is correct amount of cleaning liquid (water / solvent) in the
brush container
3. Open the canister lid one by one and check the colorant condition. If colorant is hardened, thickened
or mould has grown, take appropriate actions. You may need to contact the colorant supplier / paint
supplier for further instructions
4. Take off the side covers of the machine, and
a. Visually check the valve wiper and nozzle one by one.
i. Check to ensure the valve is returning to cover the nozzle. If not, the valve spring
ii. Check to ensure that the valve wipers are clean. Remove any dried colorants
b. Clean the nozzles manually if you suspect colorant may have dried. Take off the nozzle one
by one, wash with warm water, and place back onto the pump. IMPORTANT: Ensure to place
the o-ring back into the nozzle. If o-rings are broken or damaged, you need to replace with
new ones.
c. Visually check and ensure that each pump disk is in the correct height. You may find some
pump disks are raised up, if so, then push them down to the correct height.
d. NOTE: You may need to close the covers, switch on the machine, turn the turn table to the
different position to be able to access all pumps. For safety, close the side covers every time
before switching on the machine
e. Close the side covers before you proceed to the next step
5. If dispenser is not connected to the power, connect to the power supply
6. Release the E-Stop button on the dispenser
7. Start up the PC if not yet done
FAST & FLUID MANAGEMENT Australia Pty Ltd
Box 1066 Unanderra NSW 2526 Australia
T: +61 (0)2 4271 7111 F: +61 (0)2 4271 7306
Date: Tuesday, 9 June 2020
Tintmaster Dispensers (TM280 / TM300)
Subject: Start-up process following a prolonged idle period
and/or wiper pad may be damaged. Replace them or you may need to consult with
your service supplier
