- Page 1 HG6145F GPON Optical Network Terminal Product Manual Version: A FiberHome Telecommunication Technologies Co., Ltd. November 2020...
- Page 3 Please contact your local sales representative, service representative or distributor for any help needed at the contact information shown below. Fiberhome Telecommunication Technologies Co., Ltd. Address: No. 67, Guanggu Chuangye Jie, Wuhan, Hubei, China Zip code: 430073...
- Page 5 Legal Notice are trademarks of FiberHome Telecommunication Technologies Co., Ltd. (Hereinafter referred to as FiberHome) All brand names and product names used in this document are used for identification purposes only and are trademarks or registered trademarks of their respective holders.
-
Page 7: Safety Precautions
Safety Precautions For your correct and safe operations on the equipment, please carefully read and strictly observe the following safety instructions: High optical power can cause bodily harm, especially to eyes. Never look directly into the end of the optical transmitter fiber jumper or the end of its active connector. -
Page 9: Table Of Contents
GPON Interface ..............4 2.3.2 LAN Interface..............4 2.3.3 POTS Interface..............5 2.3.4 Wi-Fi Interface ..............5 2.3.5 USB Interface ..............6 Introduction to the HG6145F .............6 2.4.1 Appearance ................6 2.4.2 Product Characteristics............9 2.4.3 Functions and Features ............ 11 2.4.4 Technical Specifications............15 Handling Common Problems ................16 Power Status Indicator LED Extinguished........17... - Page 10 3.10 Test of Voice Service Failed ............19 Standards and Protocols................20 Appendix A Abbreviations ................23...
-
Page 11: Documentation Guide
Documentation Guide Document Orientation HG6145F Product Manual introduces the positioning, features, functions, technical specifications of the ONT (Optical Network Terminal) product HG6145F as well as handling of common problems, so that readers can have an overall knowledge about the HG6145F. -
Page 12: Product Introduction
Product Introduction Product Positioning Product Specifications Interface Specifications Introduction to the HG6145F Version: A... -
Page 13: Product Positioning
See Figure 2-1 for the network positioning of the HG6145F. Figure 2-1 Network Application of the HG6145F Product Specifications The tables below list the interfaces on the HG6145F and the services supported by the ONT for users' reference on ONT configuration. Table 2-1 Interfaces Supported by the HG6145F... -
Page 14: Interface Specifications
Internet Service Multicast Service Voice Service Wi-Fi Service HG6145F Note: indicates supported ; × indicates not supported . Service Reliability The HG6145F supports MTBF up to 30 000 hours. Interface Specifications 2.3.1 2.3.1 GPON Interface Table 2-3 GPON Interface Specifications Specification... -
Page 15: Pots Interface
2 Product Introduction Table 2-4 LAN Interface Specifications (Continued) Specification Parameter Supports full-duplex or half-duplex and 10/100/1000 Working mode M auto negotiation. Specifications of the cable used CAT-5 unshielded twisted pair 2.3.3 2.3.3 POTS Interface Table 2-5 POTS Interface Specifications Specification Parameter Interface type... -
Page 16: Usb Interface
20 MB/s Introduction to the HG6145F 2.4.1 2.4.1 Appearance The following describes the appearance of the HG6145F, including the overall look, interfaces, buttons, and indicator LEDs. Note: The pictures here are only for reference. Appearance The overall appearance of the HG6145F is shown in Figure 2-2. - Page 17 2 Product Introduction Figure 2-2 Overall Outlook of the HG6145F Interface and Button Table 2-8 Interfaces and Buttons of the HG6145F Description Interface and Button Function 2.4G/5G WPS button Enables or disables 2.4G/5G WPS. WLAN 2.4G/5G WLAN button Enables or disables 2.4G/5G WLAN.
- Page 18 HG6145F GPON Optical Network Terminal Product Manual Indicator LED Description Indicator LEDs of the HG6145F are located on the front panel of the equipment. Table 2-9 Indicator LEDs on the HG6145F Meaning Status Description Indicator LEDs Color Status The equipment is powered on.
-
Page 19: Product Characteristics
2.4.2 2.4.2 Product Characteristics The HG6145F can be used together with the OLT equipment to make up a GPON system and access multiple services for users. The HG6145F has the following characteristics: 1. GPON access capability Conforms to ITU-T G.984 series of standards, with good interoperability. - Page 20 HG6145F GPON Optical Network Terminal Product Manual Supports multiple authentication and encryption modes to provide users with safe and reliable wireless access mode. 4. Network storage and file sharing Provides two USB interfaces for connection with the USB interface storage devices to provide convenient network storage and file sharing service.
-
Page 21: Functions And Features
2.4.3 2.4.3 Functions and Features Table 2-10 Functions and Features of the HG6145F Description Item Compliant with standards ITU-T G.984.1, G.984.2, G.984.3 and G.984.4. Supports GEM encapsulation (Ethernet over GEM is supported, but ATM encapsulation is not supported). - Page 22 HG6145F GPON Optical Network Terminal Product Manual Table 2-10 Functions and Features of the HG6145F (Continued) Description Item Supports OMCI channel encryption. Supports the ONT registration process as specified in ITU-T. G.984.3. Supports four authentication modes: SN, Password, SN Password and LOID.
- Page 23 2 Product Introduction Table 2-10 Functions and Features of the HG6145F (Continued) Description Item Supports the IPv6 Snooping multicast service, supports the MLDv1 information, MLDv2 query information and MLDv2 report information. Supports the IEEE 802.1Q VLAN standard. Supports joining the 802.1Q VLAN in the tag / untag mode.
- Page 24 HG6145F GPON Optical Network Terminal Product Manual Table 2-10 Functions and Features of the HG6145F (Continued) Description Item Supports the WPS negotiation encryption algorithm and key. Supports adjustment of the transmit power. Complaint with the USB 2.0 standard. Supports plug-and-play and hot insertion of the USB storage device.
-
Page 25: Technical Specifications
2 Product Introduction 2.4.4 2.4.4 Technical Specifications Table 2-11 Technical Specifications of the HG6145F Description Classification Item Dimensions 204 mm × 41 mm × 149 mm Mechanical parameters Weight About 350 g Power supply parameter DC 12 V/1.5 A Static power consumption 12.5 W... -
Page 26: Handling Common Problems
Handling Common Problems The following introduces how to handle common problems encountered in equipment operation and service test. Power Status Indicator LED Extinguished Register Status Indicator LED Extinguished Optical Signal Status Indicator LED Blinking Ethernet Interface Status Indicator LED Extinguished Failing to Detect ONT Using Wi-Fi Failing to Access Local Web Login GUI and Failing to Ping 192.168.1.1 Failing to Access Internet Using the LAN Port... -
Page 27: Power Status Indicator Led Extinguished
3 Handling Common Problems Power Status Indicator LED Extinguished Handle the problem according to the procedures below: Check whether the mains supply is normal. Check whether the power adapter matches the device. Check whether the power button is pressed down. Check whether the power cable connection is normal. -
Page 28: Failing To Detect Ont Using Wi-Fi
HG6145F GPON Optical Network Terminal Product Manual Check whether the network cable is damaged or connected incorrectly. Check whether the color-coding scheme of the network cable is incorrect; if so, replace it with a standard CAT-5 twisted pair network cable. -
Page 29: Failing To Access Internet Using Wi-Fi
3 Handling Common Problems If the computer is obtaining IP addresses automatically, check whether the computer has obtained an IP address in the network segment of 192.168.x.x. Contact the personnel in the network management center to check whether the WAN is connected correctly and bound with the LAN port. Failing to Access Internet Using Wi-Fi Handle the problem according to the procedures below: Check whether the computer is connected to the ONT's Wi-Fi signal correctly... - Page 30 Standards and Protocols Classification Standard Number Title Gigabit-capable passive optical networks (GPON): General ITU-T G.984.1 characteristics Gigabit-capable Passive Optical Networks (GPON): Physical Media ITU-T G.984.2 Dependent (PMD) layer specification GPON Gigabit-capable Passive Optical Networks (G-PON): Transmission ITU-T G.984.3 convergence layer specification Gigabit-capable passive optical networks (G-PON): ONT ITU-T G.984.4 management and control interface specification...
- Page 31 4 Standards and Protocols Classification Standard Number Title Dual rate speech coder for multimedia communications transmitting at ITU-T G.723.1 5.3 and 6.3 kbit/s Coding of speech at 8 kbit/s using conjugate-structure algebraic-code- ITU-T G.729 excited linear prediction (CS-ACELP) G.729 based Embedded Variable bit-rate coder: An 8-32 kbit/s ITU-T G.729.1 scalable wideband coder bitstream interoperable with G.729 ITU-T G.165...
- Page 32 HG6145F GPON Optical Network Terminal Product Manual Classification Standard Number Title IEEE Draft Standard for Information Technology Telecommunications and Information Exchange Between Systems Local and Metropolitan Area Networks Specific Requirements Part P802.11ax 11: Wireless LAN Medium Access Control (MAC) and Physical Layer...
- Page 33 Appendix A Abbreviations Optical Network Terminal FTTH Fiber To The Home Gigabit-capable Passive Optical Network GPON Optical Distribution Network Optical Line Termination Dynamic Bandwidth Allocation Extensible Markup Language GPON Encapsulation Mode Asynchronous Transfer Mode Operation, Administration And Maintenance Forward Error Correction Time Division Multiple Access TDMA Physical Layer Operations, Administration and...
- Page 34 HG6145F GPON Optical Network Terminal Product Manual Hyper Text Transfer Protocol over Secure Socket Layer HTTPS CATV Cable Antenna Television Class of Service Session Initiation Protocol VoIP Voice over Internet Protocol Real-time Transport Protocol IGD_WLAN_SSID Service Set Identifier Wide Area Network...
- Page 35 Appendix A Abbreviations Integrated Services Digital Network ISDN Internet Control Message Protocol ICMP IP Multimedia Subsystem Internet Protocol Link Aggregation Control Protocol LACP Local Area Network Multi-Dwelling Unit Media Gateway Controller Media Gateway Control Protocol MGCP Multicast Listener Discover MoIP Modem over IP MTBF Mean Time Between Failure...
- Page 36 HG6145F GPON Optical Network Terminal Product Manual Strict Priority Set Top Box Synchronous Transport Module Straight-Through Processing Secure Shell Transmission Control Protocol Time Division Multiplex Trunk Gateway Time of Day Type of Service User Datagram Protocol User-Network Interface Video Distribution Network...
