Topcon 3D-MC MAX Installation Manual

Topcon 3D-MC MAX Installation Manual

Caterpillar d5/d6 dozer
Hide thumbs
Table of Contents

Advertisement

Quick Links

MAX
3D-MC
MC-X3
Caterpillar D5/D6 Dozer
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3D-MC MAX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Topcon 3D-MC MAX

Summary of Contents for Topcon 3D-MC MAX

  • Page 1 3D-MC MC-X3 Caterpillar D5/D6 Dozer Installation Manual...
  • Page 2 Revision A ©Copyright June, 2021 All contents in this manual are copyrighted by Topcon. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, distributed, or otherwise reproduced without express written consent from Topcon.

  • Page 3: Table Of Contents

    Table of Contents Preface ............. iv Terms and Conditions .
  • Page 4 FCC Statements ............3-2 IC Statements .

  • Page 5: Preface

    Microsoft Corporation. The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Topcon Positioning Systems, Inc. is used under license. Other product and company names mentioned herein may be trademarks of their respective owners.
  • Page 6 On the Topcon Support website (www.topconpositioning.com/support), or the Topcon Support app (myTopcon NOW!) you can download manuals, technical documentation, training material, and various utility software to help you set up and use your Topcon product. The website and app also offer registration resources, training, and technical assistance.

  • Page 7: Manual Conventions

    Type guest, and click Enter. Mono Italic Reference to another manual or help document Refer to the Topcon Reference Manual. Notification that one or more steps may be taken to reduce effort, time, and/or expense. Further information to note about system configuration, maintenance, or setup.

  • Page 8: Introduction

    3D-MC integrated 3D machine control system together with the MC-X3 controller combines TS-i4 IMU sensors, GNSS receivers, and a GX-55 touchscreen display for the Topcon dozer grade control system. This manual covers the installation procedure for the 3D-MC integrated 3D machine control system with MC-X3 control for the Caterpillar D5 and D6 dozers (Figure 1-1).
  • Page 9 Figure 1-2: Caterpillar 3D-MC D5/D6 Dozer System Diagram Preparing for Installation P/N: 1049060-01...

  • Page 10: Required Tools

    Required Tools • MC Systems Calibration Kit, P/N 1031278-01 • Metric wrench set • English wrench set • Allen wrench set (English and metric) • Drill • Hole saw • Grinder • Sharp utility knife • Wire cutters • Standard screwdriver •...

  • Page 11: General Guidance On Installation

    TS-i4 Sensor Guard Covers from seating properly. Mounting brackets for TS-i4 IMU sensors used on the Blade, C-Frame, and Body are shipped unpainted. Topcon strongly recommends painting these brackets, after welding, to prevent rust and corrosion. Ensure threaded holes remain free of paint.

  • Page 12: Installation

    Installation TS-i4 IMU Sensor Orientation The TS-i4 IMU sensor orientation is described using the X, Y, and Z axes where Z runs up and down, X runs lengthwise across the sensor and through the connectors, and Y runs across the width or the edge with no connectors (Figure 2-1).
  • Page 13 3. Provide adequate clearance for connection to protected M12 cable, strain relief plates, and cover. 4. Minimize the potential for debris striking the TS-i4 IMU sensor. 5. Prepare the back of the blade by removing any debris in the area where the TS-i4 IMU sensor will be installed (Figure 2-2).
  • Page 14 Welding preparation is not machine-specific. Figure 2-4 and Figure 2-5 are intended to illustrate the preparation process and may include different machine makes and/or models. 9. Prepare the welding area (Figure 2-4). Grind off the paint on the blade where welds will be applied.
  • Page 15 12. Weld the 4 Hole Weld-on plate (Figure 2-3 on page 2-2) to the back of the dozer blade, using a suitable welding method (Wire Welding or Stick Welding), weld the 4 Hole Weld-on plate to the back of the dozer blade. The weld leg size should be 6 mm (1/4 inch), and weld lengths should be at least 50 mm (2 inches).

  • Page 16: Installing Ts-I4 C-Frame Sensor

    Standoff M12 Cable Protected Terminator (4 PLCS) with Hydraulic Hose Strain Relief M6 Washer as Hose Clamps Plate (2 PLCS) Spacer (2 PLCS) Figure 2-7: Secure and Protect the TS-i4 Blade Sensor 25. Connect the M12 cable to the inside connector of the TS-i4 Blade sensor (Figure 2-7). 26.
  • Page 17 Protected Hose Clamp Standoff Strain Relief M12 Cable (4 PLCS) (4 PLCS) Plate (2 PLCS) Figure 2-8: TS-i4 Sensor Secured to C-Frame 5. Position the Excavator TS-i4 Guard Weld-On Base plate (P/N 1032189-01) from the 3rd TS-i4 Add On Kit (P/N 1043613-01) either parallel to the dozer blade or parallel to the centerline of the body (Figure 2-8).

  • Page 18: Ts-I4 Imu Sensor Cable Routing

    TS-i4 IMU Sensor Cable Routing M12 Cable from TS-i4 TS-i4 TS-i4 Machine TS-i4 Blade sensor to TS-i4 Blade C-Frame Cable entrance Body C-Frame sensor sensor sensor Route point to sensor MC-X3 Figure 2-9: M12 Cable Route from TS-i4 Blade Sensor to Body Sensor and Machine Entrance 1.

  • Page 19: Installing Ts-I4 Body Sensor

    Installing TS-i4 Body Sensor The TS-i4 Body sensor can be located under the tracks of the machine (Figure 2-10). It is mounted to the outside of the dozer body using: TS-i4 Body Mounting Kit (P/N 1040867-01) and 4 Hole Weld- on plate from the Blade/Body IMU Weld Plate &...
  • Page 20 5. Prepare the welding areas by grinding off the paint around the area where the weld-on plate will be installed. 6. Position the weld-on plate using clamps or magnets so that it is within two degrees of the plane of the grouser pads. Figure 2-11: TS-i4 Dozer Base Platform (P/N 1040755-01) for TS-i4 Body Sensor Installation 7.
  • Page 21 15. Determine the amount of protective hydraulic hose that will be required to protect the M12 cable from the TS-i4 Body sensor to the machine entrance point (refer to circled area in Figure 2-12). M12 Cable Routing To/From TS-i4 Body Sensor Machine Entrance Point Hose Corner bracket...

  • Page 22: Installing Cable Access Seal

    Installing Cable Access Seal Some machines will have pre-drilled holes to mount the cable seal on the cab floor behind the seat. If the machine does not have pre-drilled holes, locate the area shown in Figure 2-12 to install the cable seal.

  • Page 23: Installing Mc-X3 Controller

    Installing MC-X3 Controller The MC-X3 Controller is mounted on the ledge behind the operator’s seat (Figure 2-14). MC-X3 Controller Ledge behind operator’s seat Figure 2-14: MC-X3 Controller Installation Location 1. Clean the area behind the operator’s chair of all dirt and dust (Figure 2-14). 2.

  • Page 24: Installing Gnss Receivers

    Installing GNSS Receivers The system uses two GR-i3/GR-i3F GNSS Receivers, with the Main GNSS receiver installed at the front center of the cab roof and the Auxiliary GNSS receiver installed at the rear center of the cab roof. Install Main GNSS Receiver 1.

  • Page 25: Install Auxiliary Gnss Receiver

    4. Connect the single side of the Tee Connector to the single side of a second Tee Connector (Figure 2-18 on page 2-14). The connection will be completed in the Auxiliary GNSS Receiver installation process. Figure 2-18: AUX GNSS Receiver & M12 Cable Connections Install Auxiliary GNSS Receiver The Auxiliary GNSS receiver is secured to the roof at the back of the cab with CAT D6 Bolt-On GPS Mount MCMAX bracket (P/N 1040166-01).

  • Page 26: Installing Diversity Antenna

    Installing Diversity Antenna Antennas must be mounted as far away as possible from the GNSS receivers and other antennas. The Diversity Antenna (P/N 1031211-01) includes a magnetic base (Figure 2-19). 1. To install the antenna, simply place it in a clear open space on the roof of the cab. 2.

  • Page 27: Cable Routing From Gnss Receivers And Antennas To Mc-X3

    Cable Routing From GNSS Receivers and Antennas to MC-X3 Carefully route the GNSS M12 cable and the antenna cables down through the rear compartment of the machine (Figure 2-20) to the side compartment following the existing cable routing in the wiring column.

  • Page 28: Completing Mc-X3 Connections

    Completing MC-X3 Connections Several cable connections route to and from the MC-X3 Controller (refer to the Caterpillar 3D- D5/D6 Dozer System Diagram, Figure 1-2 on page 1-2). Identify each cable, as labeled on the associated cable jackets. The MC-X3 will connect to a breakout cable (P/N 1033631-02) with multiple extensions, as well as cellular and radio cables.
  • Page 29 3. Connect CAT D5/D6 CAN To M12 Cable Assembly (P/N 1040763-01) to the Tee connector on the J1939 cable from the breakout cable. This assembly uses a 3-Pin Deutsch connector. 4. Connect the female end of the 3-Pin Deutsch connector for the cable labeled P/N 1040763-01 from the breakout cable harness to male end of machine interface connector labeled 3RD Party ARO Connection with the green and yellow wires as shown in Figure 2-24.

  • Page 30: Measurement, Configuration, And Calibration

    Measurement, Configuration, and Calibration After the system hardware components have been installed, please refer to the MC-X Dozer Systems Reference Installation and Calibration Manual, P/N 1044736-01, for information on required the measurements, configuration, and calibration. Completing Installation After the machine has been measured and calibrated, the installation can be completed by securing the cover shields (P/N 1032188-01) to the TS-i4 IMU sensors.
  • Page 31 2-20 Completing Installation P/N: 1049060-01...

  • Page 32: Regulatory Information And Safety Warnings

    2. Use extreme caution on the job site. Working around heavy construction equipment can be dangerous. 3. DO NOT attach Topcon brackets, cables, or hose connections while the machine is running. 4. DO NOT allow any Topcon components to limit the visibility of the operator.

  • Page 33: Rf Radiation Hazard Warning

    Tampering with the unit by the operator or non-factory authorized technicians will void the unit’s warranty: ● Do not attempt to open the unit and modify any of its internal components. ● Do not short circuit. Use a maximum 15A inline fuse with the MC-X3 Controller. RF Radiation Hazard Warning To ensure compliance with FCC and Industry Canada RF exposure requirements, this device must be installed in a location where the...

  • Page 34: Ic Statements

    If this equipment does cause interference to radio or television equipment reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●...

  • Page 35: Eu Product Conformity

    EU Product Conformity Hereby, (Topcon) declares that (MC-X3, GR-i3 and GR-i3F) are in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive 2014/53/EC. EU Declaration of Conformity (Radio Equipment Directive 2014/53/EU) esky (Topcon) prohlašuje, že (MC-X3, GR-i3 a GR-i3F) jsou v souladu s požadavky [Czech] a dalšími příslušnými ustanoveními směrnice 2014/53/ES.

  • Page 36: Open Source Support

    2014/53/EG. Open Source Support The Topcon TotalCare website contains the licenses and notices for open source software used in this product. With respect to the free/open source software, if you have any questions or wish to receive a copy of the source code to which you are entitled under the applicable free/open source license(s), such as the GNU Lesser/General Public License, please visit http://topconcare.com/en/support/.
  • Page 37 Regulatory Information P/N: 1049060-01...
  • Page 38 ©2021 Topcon Corporation 7400 National Drive • Livermore, CA 94550 • All rights reserved. Specifications subject to change without notice. • 1049060-01 Revision A • 06/21...
