IDD Flame Detector Heads
Standard Models: IDD-II, IDD-IIL, IDD-IIU, and IDD-Ultra
Publication 372000-05 Rev K
BURNERS
IGNITERS
DAMPERS
CONTROLS
www.forneycorp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDD-II and is the answer not in the manual?

Questions and answers

Summary of Contents for Forney IDD-II

  • Page 1 IDD Flame Detector Heads Standard Models: IDD-II, IDD-IIL, IDD-IIU, and IDD-Ultra Publication 372000-05 Rev K BURNERS IGNITERS DAMPERS CONTROLS www.forneycorp.com...
  • Page 2 Forney supervision. PROPRIETARY NOTICE The contents of this publication are proprietary data of Forney Corporation. Reproduction or use of any part of the publication for purposes other than the support of the equipment for which it is published is permissible only if expressly authorized in writing by Forney.
  • Page 3 REVISIONS REVISIONS DATE COMMENTS Initial Release 4/2003 6/2004 6/2004 10/2006 Add CEX and Ultra versions of detector heads, 07/2013 update graphics. 08/2013 Correct graphics with cable support brackets. Update logo and address. 09/2015 Remove IDD-UV and IDD-UltraCEX 12/2020 IDD Flame Detector Heads Manual 372000-05 Rev K...
  • Page 4 TABLE CONTENTS PM IDD9000 Flame Ampli er 372001-02 Rev Kv...
  • Page 5: Table Of Contents

    TABLE OF CONTENTS Section 1 System Description 1.2 Safety Section 2 Installation 2.1 Installation Procedure 2.2 Detector Wiring Section 3 Commissioning 3.1 Initial Checkout 3.1.1 Operational Checkout Section 4 Operation Section 5 Troubleshooting Section 6 Maintenance Section 7 Storage Section 8 Return or Repair Service Section 9 Parts LIST OF FIGURES Figure 1...
  • Page 6 SECTION 1 DESCRIPTION Typical Spectral Detector Head Sensor Housing Application Response IDD-II Oil and Coal IR 700 to 3300 nm Standard IDD-IIL Lignite IR 700 to 3300 nm Standard IDD-IIU IR 400 to 3300 nm Standard & Coal IDD-Ultra Natural Gas...
  • Page 7: Figure 1 Dimensional Drawing - Idd Standard Housing

    Figure 1 Dimensional drawing – IDD Standard housing MECHANICAL SPECIFICATIONS ATTRIBUTE STANDARD MODELS Models IDD-II, IDD-IIL, IDD-IIU, IDD-Ultra Approvals Factory Mutual (FM) Housing Rating NEMA4 MECHANICAL 1.75 x 6.25 inches Size (44.5 x 158.8 mm) Weight 1.3 lbs (0.59kg) Mounting 1.0 inch NPT male pipe...
  • Page 8: Safety

    Operating: IDD-II, IDD-IIL and IDD-IIU 32oF to 140oF (0oC to 60oC) IDD-Ultra Temperature Rating 32oF to 250oF (0oC to 121oC) Storage: -25oF to 140oF (-32oC to 60oC) Front Mount: 10 scfm @ 6-inches w.c. (16m3/hr @ 152Kg/m2) Cooling / Sealing Air Fiber Optic: 15 scfm @ 6-inches w.c.
  • Page 9 WARNING: Do Not Open When Energized WARNING: glasses to prevent eye injury caused by airborne particles in cooling/seal-air supply or wind box. CAUTION: The detector head contains sensitive electrical components. Ensure that all the I/O cable. CAUTION: Disconnect the cable from the detector by hand, but do NOT twist the connector barrel.
  • Page 10: Section 2 Installation

    Cable support brackets are not used with supplemental cooling chambers or CEX versions. equipment from Forney Corporation. Note: The location and sighting instructions listed in the following sections are general guidelines for the location...
  • Page 11: Installation Procedure

    INSTALLATION PROCEDURE WARNING: 1. The best results are obtained when the detector is aimed so that the detector’s line of sight intersects the burner center at a slight angle (e.g. 5 degrees) and sees a maximum of the primary combustion zone, as shown in Figure 3.
  • Page 12: Figure 3 Detector Location Vs. Secondary Air Rotation

    Figure 3 Detector Location VS. Secondary air rotation close to the periphery of the throat where the ultraviolet radiation is at a maximum. (See Figures 3 and 4) Having determined an appropriate location for the sight tube, cut a clearance hole for a 2 inch pipe through the burner plate.
  • Page 13: Figure 4 Idd Direct Mount Arrangement

    Note: If freezing temperatures are expected at the detector head, Forney recommends heat tracing the detector sight tube. Contact Forney for additional details.
  • Page 14: Figure 5 Idd Swivel Mount Arrangement

    Figure 5 IDD Swivel Mount Arrangement Cable support bracket is required on Standard IDD when a cooling chamber is not used. Figure 6 IDD Direct Mount with Cooling Chamber Figure 7 IDD Swivel Mount Arrangement with Cooling Chamber IDD Flame Detector Heads Manual 372000-05 Rev K...
  • Page 15: Detector Wiring

    DETECTOR WIRING in a conduit to protect it from damage and to prevent moisture ingress. Take precautions to keep the detector cable away from any high inductive wiring associated with high inductive loads or high voltage, or high energy spark ignition systems. IDD Flame Detector Heads Manual 372000-05 Rev K...
  • Page 16: Section 3 Commissioning

    SECTION 3 COMMISSIONING Before commissioning, complete all of the installation instructions. INITIAL CHECKOUT 1. Verify the operation of the detector head as follows: a) Remove mounted IDD detector head. b) Connect it to the four-conductor cable. c) Place a light source 1 to 4 feet from the surface of the detector. Use a Tungsten light source for IR detector heads and a UV light source for the IDD-Ultra.
  • Page 17: Section 4 Operation

    SECTION 4 OPERATION decreases, it causes a change in resistance of the cell substrate. This resistance change in turn creates IMPORTANT: sighting may cause detector failure due to a weak or non-existent signal. burner and the sighting of the primary combustion zone. IDD Flame Detector Heads Manual 372000-05 Rev K...
  • Page 18: Section 5 Troubleshooting

    SECTION 5 TROUBLESHOOTING If the detector head malfunctions, ensure that the procedures described in the commissioning section have been performed successfully. Refer to Table 1 for Troubleshooting information. TABLE 1: IDD Detector Head Troubleshooting Symptom Probable Cause Remedy Supply voltage to head not Verify +50 vdc and +12 to +14.5 present.
  • Page 19: Section 6 Maintenance

    The IDD detector head is a non-repairable device and requires no maintenance other than periodically cleaning the cell surface. The appropriate cleaning schedule is determined by the quality and cleanliness of the cooling-/seal-air source. Forney recommends the use of a non-oily cleaning solution and a soft lint-free cloth for lens cleaning.
  • Page 20: Section 7 Storage

    SECTION 7 STORAGE Store the IDD detector head in its shipping box until used. IDD Flame Detector Heads Manual 372000-05 Rev K...
  • Page 21: Section 8 Return Or Repair Service

    • Customer’s purchase order number for repairs (if applicable) • Customer’s requested return date • Name and address to which Forney is to return-ship and any special container marking information that may be required • Name of individual (customer’s representative) requesting the RMA.
  • Page 22: Section 9 Parts

    38321-23 IDD-IIL IR Detector (700 to 3300 nanometers; for lignite) 38321-29 IDD-Ultra UV Detector (200 to 425 nanometers) 399854-xx Detector cable with connector (-xx consult Forney for available lengths) 364524-01 Cable support bracket 381071-01 Cooling air chamber (Standard IDD version) 354943-01 1”...
  • Page 23 Part Number Part Description 75450-06 1” NPT Close nipple 75450-09 2” NPT Close nipple 92527-02 IDD-CEX Cooling chamber 91016-63 1” NPT Swivel 91147-93 1” NPT Sealing Coupling 91147-82 1” BSP Sealing Coupling 38321-25 IDD-IICEX IR Detector Filtered (700 to 3300 nanometers) 38321-26 38321-27 401116-50...
