- Page 1 PORTABLE POWER STATION POWER STATION USER MANUAL...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION To ensure safe operation and service of the power station, read and understand all instructions. Failure to follow all instructions may result in severe injury or property damage. The loss caused by wrong use of POWER STATION is not covered by our Warranty. CHARGE NOW Please FULLY charge the POWER STATION as soon as possible once you have it in possession. -
Page 4: Feature Details
FEATURE DETAILS ⑩ ⑨ ⑧ ⑦ ① ⑥ ⑪ ② ③ ④ ⑤ ⑯ ⑫ ⑮ ⑬ ⑭ 1. LCD Screen Display 2. AC Outlet 3. USB QC3.0 4. USB-PD 5. Cigarette Lighter Output 6. DC Input 7. Flashlight 8. Wireless Charger 9. -
Page 5: Function Buttons
OPERATION GUIDE FUNCTION BUTTONS ECO Function ON/OFF Button Power ON/OFF Button LED Lighting & Flashlight ON/OFF Button AC Outlet Power ON/OFF Button DC/USB Outputs Power ON/OFF Button 12: Power ON/OFF Button POWER ON/OFF BUTTON is the master switch. Press POWER ON/OFF BUTTON to activate the DC/AC/ECO BUTTONS. -
Page 6: Lcd Features
OPERATION GUIDE LCD FEATURES Battery Level Remaining Usage Time Output Power Remaining Charging Time Input Power Low Voltage Warning Temperature Warning DETAILS DISPLAYED ON LCD Battery Level: The battery level is provided by the percentage of battery charge corresponding to the number of bars and percentage displayed. PLEASE BE AWARE that this value can adjust multiple times as the energy draw changes from the connected devices. -
Page 7: General Specifications
GENERAL SPECIFICATIONS Model ADVANCE 500 Battery Lithium Battery Capacity 400Wh (22.2V, 18Ah) Dimensions L230 x W168 x H178 mm Weight 8.6 lbs (4.3 kg) Charging Temperature 32 to 104°F (0 to 40°C) Discharging Temperature 14 to 104°F (-10 to 40°C) - Page 8 GENERAL SPECIFICATIONS NOTICE: Power stations are available in different types of AC outlets, which are suitable for different countries. Please check the below AC Outlet list for your references. Country Voltage/Frequency Country Voltage/Frequency Universal Israel 220V , 50Hz China 220V , 50Hz Australia 240V, 50Hz Japan...
-
Page 9: How To Charge
OPERATION GUIDE HOW TO CHARGE From Solar Charger depend on the solar conditions From Car Port 12V From Wall Charger 100 - 240V RECOMMEND TO DISCONNECT THE POWER STATION WHEN IT FULLY CHARGED. POWERING / CHARGING DEVICES Select the type of output required by pressing either the DC (DC/USB outputs), AC, or ECO outlet button. -
Page 10: Maintenance
MAINTENANCE MAINTENANCE Recharge as needed. There are no pre-designated intervals at which to recharge as long as the POWER STATION is being used regularly. Avoid fully draining the battery to 0%, as this can impact the quality and life span of the battery. Periodically inspect all ports and wall chargers for any debris, dirt, damage, and corrosion. -
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Indicator Phenomenon Solutions Please charge/power the devices within the rated AC Output power. Otherwise, the AC button will automatically Overload Warning turn off. Please charge/power the devices within the rated AC Output Off power. And then push the AC button to restart. Please charge/power the devices within the rated DC Output Voltage of DC and then press the ON/OFF... - Page 12 TROUBLESHOOTING Problem Solutions Remark Check if the power adapter’s cord is Confirm whether it is a connecting inserted fully into the DC input and problem. wall plug. Unable to Charge Check if the adapter indicator is on if If the light is still off, please contact connected well.
- Page 13 WARNINGS The warnings in this manual cannot cover all possible conditions or situations that could occur. Please use the POWER STATION with common sense and caution. Always be aware of the environment around you while using the device and ensure the POWER STATION is being used safely and responsibly.
-
Page 14: Warranty
CAUTIONS Transportation: POWER STATION complies with all legal requirements for the transport of dangerous goods. The capacity of the lithium battery pack exceeds 100Wh. Based on international standards, if POWER STATION is transported by airplane, it must be transported by IATA standard packaging. IATA instructions and labeling requirements and the relevant declarations must be completed.
