- Page 1 ADVANCE 240 Power Station USER MANUAL ADVANCE240 200W 231Wh AC OUT DC 12V 10A INPUT 12-28V QC 3.0 QC 3.0 PD 60W Empower Your Life, Empower Your World...
-
Page 3: Important Safety Information
To ensure safe operation and service of the meter, read and understand all instructions. Failure to follow all instructions may result in severe injury or property damage. The loss caused by wrong use of ADVANCE 240 is not covered by our Warranty. CHARGE NOW Please FULLY charge ADVANCE 240 as soon as possible when delivered. -
Page 4: Feature Details
FEATURE DETAILS ADVANCE240 200W 231Wh AC OUT DC 12V 10A INPUT 12-28V QC 3.0 QC 3.0 PD 60W LCD Screen Display USB-A & USB-C Outputs Flashlight Cigarette Lighter Output LED Lighting DC Input AC Outlet... -
Page 5: Button Feature
BUTTON FEATURE ADVANCE240 200W 231Wh AC OUT DC 12V 10A INPUT 12-28V QC 3.0 QC 3.0 PD 60W Power ON/OFF Button AC Outlet Power ON/OFF Button LED Lighting & Flashlight ON/OFF Button... -
Page 6: Function Buttons
FUNCTION BUTTONS A: POWER ON/OFF POWER ON/OFF BUTTON is the master switch. Press POWER ON/OFF BUTTON to activate the DC/USB/AC BUTTONS. Press POWER ON/OFF BUTTON to shut down the output(s) when not in use. B: AC OUTLET POWER ON/OFF The AC Outlet will NOT function until the AC OUTLET POWER ON/OFF BUTTON is pressed to activate. -
Page 7: Lcd Features
Low Voltage Warning: If the Low Voltage Warning indicator is on, please recharge the power station. Temperature Indicator: The Temperature Indicator lights on means the battery temperature of ADVANCE 240 is too low/high. All function of input and output will be stopped until the battery temperature returns to the working range. -
Page 8: General Specifications
GENERAL SPECIFICATIONS Model: ADVANCE 240 Battery: 18650 Lithium Battery Capacity: 231Wh (22.2V 10.4Ah) Dimensions: L192 x W142 x H148 mm Weight:6.38lb (2.9kg) Charging Temperature: 32 to 104°F (0 to 40°C) Discharging Temperature: 14 to 104°F (-10 to 40°C) Charging Input... -
Page 9: How To Charge
DC 12V 10A INPUT 12-28V QC 3.0 QC 3.0 PD 60W From Wall Charger 100 - 240V RECOMMEND TO DISCONNECT THE ADVANCE 240 WHEN FULLY CHARGED. WHAT IT POWERS CPAP without heated Laptops (41.4Wh) 32" TV(60W) Gopro (5.9Wh) Floodlight(4W) humidifier (15W) -
Page 10: Pass-Through Charging
When charging, the LCD Screen will be illuminated, and the LCD display will show battery level, ADVANCE 240 is fully charged when it shows 100%. It is recommended to FULLY charge ADVANCE 240 every 3 months to maintain the health of the battery pack. -
Page 11: Maintenance
Periodically inspect all ports and wall chargers for any debris, dirt, damage, and corrosion. DO NOT attempt to fix it. DO NOT cover the ADVANCE 240 with towels, clothing, or other items. Regularly observe if the side vents are collecting dirt or dust, and clean following cleaning procedures noted in manual. -
Page 12: Troubleshooting
Low Watt range 0 to 10 may be displayed on INPUT STATUS of LCD screen. * Please charge ADVANCE 240 when you get it. Long time storage ADVANCE 240 will cause failure to start. Try charging for more than ten minutes to restart it. If none of these attempts work, you can contact customer service for help. - Page 13 DO NOT use the ADVANCE 240 or AC Wall plug power adapter if it is damaged or has been modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury.
-
Page 14: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS WARRANTY TogoPOWER provides a limited warranty for the original consumer purchaser, which covers the TogoPOWER the products from defects in workmanship and material under consumer for 12 months from the date of purchase. In order to establish the start date of the warranty period, the sales receipt from the first consumer purchase, or other reasonable documentary proof is required TogoPOWER’s warranty does not apply to (i) any the porduct that is misused, abused, modified,damaged by accident, or used for anything other than normal consumer use... - Page 16 CONTACT US 322 Paseo Tesoro, Walnut, CA 91789 1-855-801-0798 support@togopower.com www.togopower.com...
