Summary of Contents for Togo POWER PIONEER 330
- Page 1 PIONEER 330 Power Station USER MANUAL PIONEER330 330W 288Wh INPUT 12-28V AC OUT QC 3.0 12V 10A QC 3.0 QC 3.0 USB-PD Empower Your Life, Empower Your World...
-
Page 3: Important Safety Information
To ensure safe operation and service of the meter, read and understand all instructions. Failure to follow all instructions may result in severe injury or property damage. The loss caused by wrong use of PIONEER 330 is not covered by our Warranty. CHARGE NOW Please FULLY charge PIONEER 330 as soon as possible when delivered. -
Page 4: Feature Details
FEATURE DETAILS PIONEER330 330W 288Wh INPUT 12-28V AC OUT QC 3.0 12V 10A QC 3.0 QC 3.0 USB-PD LCD Screen Display USB-A & USB-C Outputs AC Outlet DC Outputs LED Lighting Flashlight Cigarette Lighter Output DC Input Wireless Charger... -
Page 5: Button Feature
BUTTON FEATURE PIONEER330 330W 288Wh INPUT 12-28V AC OUT QC 3.0 12V 10A QC 3.0 QC 3.0 USB-PD Power ON/OFF Button AC Outlet Power ON/OFF Button DC Outputs Power ON/OFF Button LED Lighting & Flashlight ON/OFF Button USB Outputs Power ON/OFF Button... -
Page 6: Function Buttons
FUNCTION BUTTONS A: POWER ON/OFF POWER ON/OFF BUTTON is the master switch. Press POWER ON/OFF BUTTON to activate the DC/USB/AC BUTTONS. Press POWER ON/OFF BUTTON to shut down the output(s) when not in use. B: DC OUTPUTS POWER ON/OFF The DC output ports will NOT function until the DC OUTPUTS POWER ON/OFF BUTTON is pressed to activate. -
Page 7: Lcd Features
Note that when you first plug in a power source, whether it's a solar panel or a wall charger, the PIONEER 330 may take a minute to detect and adjust its charge circuitry before it starts drawing power from the source. -
Page 8: General Specifications
GENERAL SPECIFICATIONS Model: PIONEER 330 Battery: 18650 Lithium Battery Capacity: 288Wh (22.2V 13Ah) Dimensions: L230 x W168 x H178 mm Weight:8.6lb (3.9kg) Charging Temperature: 32 to 104°F (0 to 40°C) Discharging Temperature: 14 to 104°F (-10 to 40°C) Charging Input... -
Page 9: How To Charge
AC OUT QC 3.0 12V 10A QC 3.0 QC 3.0 USB-PD From Wall Charger 110 - 240V RECOMMEND TO DISCONNECT THE PIONEER 330 WHEN FULLY CHARGED. WHAT IT POWERS CPAP without heated Laptops (41.4Wh) 32" TV(60W) Gopro (5.9Wh) Floodlight(4W) humidifier (15W) -
Page 10: Pass-Through Charging
When charging, the LCD Screen will be illuminated, and the LCD display will show battery level, PIONEER 330 is fully charged when it shows 100%. It is recommended to FULLY charge PIONEER 330 every 3 months to maintain the health of the battery pack. -
Page 11: Maintenance
Periodically inspect all ports and wall chargers for any debris, dirt, damage, and corrosion. DO NOT attempt to fix it. DO NOT cover the PIONEER 330 with towels, clothing, or other items. Regularly observe if the side vents are collecting dirt or dust, and clean following cleaning procedures noted in manual. -
Page 12: Troubleshooting
Low Watt range 0 to 10 may be displayed on INPUT STATUS of LCD screen. * Please charge PIONEER 330 when you get it. Long time storage PIONEER 330 will cause failure to start. Try charging for more than ten minutes to restart it. If none of these attempts work, you can contact customer service for help. - Page 13 DO NOT use the PIONEER 330 or AC Wall plug power adapter if it is damaged or has been modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury.
-
Page 14: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS WARRANTY TogoPOWER provides a limited warranty for the original consumer purchaser, which covers the TogoPOWER the products from defects in workmanship and material under consumer for 12 months from the date of purchase. In order to establish the start date of the warranty period, the sales receipt from the first consumer purchase, or other reasonable documentary proof is required TogoPOWER’s warranty does not apply to (i) any the porduct that is misused, abused, modified,damaged by accident, or used for anything other than normal consumer use... - Page 16 CONTACT US 322 Paseo Tesoro, Walnut, CA 91789 1-855-801-0798 support@togopower.com www.togopower.com...
