FSC-BP301 serial Bluetooth adapter
instruction manual
1
3
2
4
5
6
7
10
8
9
1. SMA antenna connector
6. Red charging indicator
2. Power off/slave mode/master mode
7. Tighten the screws
3. Green communication indicator
8. Restore factory settings button
4. Type-C charging interface 9. DB9 female connector
5. Blue status indicator 10. SMA antenna
Advertisement
Related Manuals for Feasycom FSC-BP301 Serial
Summary of Contents for Feasycom FSC-BP301 Serial
- Page 1 FSC-BP301 serial Bluetooth adapter instruction manual 1. SMA antenna connector 6. Red charging indicator 2. Power off/slave mode/master mode 7. Tighten the screws 3. Green communication indicator 8. Restore factory settings button 4. Type-C charging interface 9. DB9 female connector...
-
Page 2: Product Features
Built-in lithium battery and charging circuit can be used in occasions without external power supply. Rich AT commands, complete functions, efficient and safe communication, and strong anti-interference ability. 1.2 Product packing list One FSC-BP301 serial Bluetooth adapter One SMA antenna An instruction manual 2. Specifications 2.1 Technical parameters... - Page 3 2.2 Adapter serial interface 2.3 Factory parameters The default parameters of FSC-BP301 when leaving the factory are as follows. Some parameters can be modified by sending AT commands to the adapter. For details, please refer to the AT command manual. Baud rate: 115200bps ...
- Page 4 Green communication indicator: When the SPP connection is established, the indicator light will always on 3.4 Restore factory If forget baud rate, please restore the factory setting by pressing the reset button. The factory setting is fixed at 115200bps. The operation is to press and hold the reset button. At this time, the blue light is always on.
- Page 5 A variety of serial port debugging software can be downloaded online, users can choose according to their own preferences. It is recommended to use Feasycom serial port assistant V1.2 debugging tool, users can contact Feasycom technical support. Carriage return line feed characters must be added to the end of AT commands, uses must check the option of "Send New...
- Page 6 <FSC-BT8X6 Programming User Guide V3.1(Universal).pdf> document. 5. FAQ Q: I use the Feasycom serial port tools to debug FSC-BP301, why couldn’t it return OK after sending the AT test command? Answer: It is probably that the serial port parameter selection is incorrect, please check the parameters of serial port number, baud rate, data bit, stop bit, check method, etc.
