Bluetooth Adapter FSC-BP119B User Guide
Bluetooth Adapter
FSC-BP119B User Guide
1. Introduction
FSC-BP119B is a Bluetooth 5.0 adapter equipped with USB 2.0 interface, supporting
multiple audio protocols (such as HFPAVRCP/A2DP), file transfer protocol (FTP), and
multiple data transfer protocols (SPP/GATT/HID).
FSC-BP119B does not need to install drivers under Win7/8/10 system. However, if the
driver is not installed, it can only transmit file data, not audio; If you need to transmit
audio data, please install the corresponding driver, or contact Feasycom for more
details.
2. Main Features
Support Bluetooth 5.0, compatible with Bluetooth 4.2/4.0/3.0/2.1/2.0
Windows 7/8/10 system without driver installation for file data transfer
Supports data and audio transfer after installing the driver under Win7/8/10 system
Supports HFP/AVRCP/A2DP/FTP/GATT/SPP/HID profiles
Can be used with Bluetooth speakers/Bluetooth headset/Bluetooth
keyboard/Bluetooth mouse/mobile phone/tablet and other devices
Equipped with whip antenna, the transmission distance can reach up to 20M
1
www.feasycom.com
Advertisement
Table of Contents
Related Manuals for Feasycom FSC-BP119B
Summary of Contents for Feasycom FSC-BP119B
- Page 1 (such as HFPAVRCP/A2DP), file transfer protocol (FTP), and multiple data transfer protocols (SPP/GATT/HID). FSC-BP119B does not need to install drivers under Win7/8/10 system. However, if the driver is not installed, it can only transmit file data, not audio; If you need to transmit audio data, please install the corresponding driver, or contact Feasycom for more details.
-
Page 2: Product Specifications
Bluetooth Adapter FSC-BP119B User Guide 3. Product Specifications Item Description Chipset RTL8761BUV Bluetooth Version BT 5.0 Working Frequency 2.4 GHz Transmission Rate 3 Mbps Transmit Distance Up to 20M Antenna Whip antenna Power Supply Interface USB2.0 Color Black Profiles HFP/AVRCP/A2DP/FTP/GATT/SPP/HID System compatibility Support Win7/8/10，Not support macOS... -
Page 3: Driver Installation
Bluetooth Adapter FSC-BP119B User Guide 6. Driver Installation Example: Install the driver using the Win10 system, right-click "Computer", open Management, click "Computer Management", and then click "Bluetooth" (this is the Bluetooth that comes with the computer) 2 Disable the Bluetooth that comes with the computer, as shown below:... - Page 4 Bluetooth Adapter FSC-BP119B User Guide Plug the Bluetooth adapter into the computer USB port, and then "Realtek Bluetooth Adapter" will appear in the Computer Management, as shown below: Right-click "Realtek Bluetooth Adapter", and then click "Update the Driver (P)", as shown below: www.feasycom.com...
- Page 5 Bluetooth Adapter FSC-BP119B User Guide Click "Browse my computer for driver software (R)", as shown below: Click "Browse (R)", and select the path for storing the driver and the driver program corresponding to the installation computer. www.feasycom.com...
-
Page 6: Function Description
Bluetooth Adapter FSC-BP119B User Guide Updating the driver, as shown below: The driver is updated successfully, as shown below: 7. Function Description 7.1 This Bluetooth adapter can be used with Bluetooth speaker, Bluetooth headset, Bluetooth keyboard, Bluetooth mouse and other devices. Here, we will introduce the example of connecting a Bluetooth speaker to listen to music and how to use it. - Page 7 Bluetooth Adapter FSC-BP119B User Guide 7.2 Right-click the " " of the computer, and then click "Add Bluetooth Device", as shown below: 7.3 Open the "Bluetooth and other devices" interface, as shown below: www.feasycom.com...
- Page 8 Bluetooth Adapter FSC-BP119B User Guide 7.4 Click "Add Bluetooth or other device" to enter the "Add device" interface, as shown below: 7.5 Click "Bluetooth" to enter the interface of searching for Bluetooth devices, as shown below: 7.6 Double-click the device to be connected with the mouse. For example, double-click the "HUAWEI CM510"...
- Page 9 Bluetooth Adapter FSC-BP119B User Guide 7.7 The "HUAWEI CM510" device is successfully connected, as shown below: 7.8 Right-click and open the computer sound settings " " , as shown below: www.feasycom.com...
- Page 10 Bluetooth Adapter FSC-BP119B User Guide 7.9 Sound input & output settings, as shown below: After setting, any sound from the computer will be played and output from the "HUAWEI CM510" device www.feasycom.com...
-
Page 11: Contact Information
9. Declaration The contents of this datasheet are subject to change without prior notice for further improvement. Feasycom team reserves all the rights for the final explanation. iBeacon is a trademark of Apple Inc., Eddystone is a trademark of Google Inc. -
Page 12: Revision History
Bluetooth Adapter FSC-BP119B User Guide Revision History Version Changes Author Initial Release Devin Update description Jerry Update product parameters www.feasycom.com...
