- Page 1 750c DISPLAY User Guide CYC MOTOR support@cycmotor.com +952 3690 8938...
-
Page 2: Table Of Contents
750c DISPLAY USER GUIDE TABLE OF CONTENTS 750c Display User Guide ..............2 Product Details ........................... 2 Main Functionalities ........................... 3 Parameter Settings ..........................5 Display Settings ..........................5 Basic Settings ............................. 7 Pin Layout ............................11 Certification ............................12 Quick Start Guide .......................... -
Page 3: 750C Display User Guide
750c DISPLAY USER GUIDE 750c Display User Guide Product Details High- contrast 3.2-inch IPS colourful matrix screen, model: 750c Firmware: CYCMOTOR LTD specific firmware Features • Suitable for low temperature: Max - 20°C • Ergonomic external button design, easy to operate •... -
Page 4: Main Functionalities
750c DISPLAY USER GUIDE Electrical Specifications • 3.2-inch IPS screen • 36V / 48V / 52V / 72V battery supply • Rated operating current: 40mA • Off leakage current: <1uA • Max output current to controller: 100mA • Operating temperature: -20°C ~ 70°C •... - Page 5 750c DISPLAY USER GUIDE Assist Level Operating Short press the UP/DOWN button to change assist levels. The top assist level is 9 while 0 is neutral. The amount of assist levels can be adjusted according to the user’s preference. Speed Display Switch Short press the MENU button to change speed mode: Speed ->...
-
Page 6: Parameter Settings
750c DISPLAY USER GUIDE Parameter Settings Button Navigation Double press the MENU button to access the settings menu. Note that the press interval must be less than 0.3 seconds. Press the POWER button to change between the Display Settings & Basic Settings. - Page 7 750c DISPLAY USER GUIDE Brightness Press the UP/DOWN button to change the brightness of the display’s backlight. “I” is the darkest “IIIII” is the brightest. Auto off Press the UP/DOWN button to change the auto power off time. This can be set between 1 to 9 minutes or off.
-
Page 8: Basic Settings
Press the UP/DOWN button to change the wheel settings. The optional wheel diameter is 16 to 29 inch. Battery Press the UP/DOWN button to change between the battery voltage settings. The optional battery voltages are 36V to 72V. Kindly note that some older 750c displays might not have the 36V setting. © 2023 CYCMOTOR LTD... - Page 9 750c DISPLAY USER GUIDE Start password Press the MENU button to access the password setting menu. The start input ON will activate on password upon start-up. You will need to input the right password before start within 30 seconds. The display will power off automatically if the password is entered incorrectly three times.
- Page 10 750c DISPLAY USER GUIDE The power output will be distributed evenly across the chosen number of assist levels (or gears) according to the Assist Level Configuration and Speed Limit Assist settings on your CYC Motor (BAC) mobile app and Motor Levels Page on the CYC Ride Control App.
- Page 11 750c DISPLAY USER GUIDE Press the MENU button to select Product Infor. This menu will show you the display’s information including its hardware and software versions as well as the display’s serial number. Press the MENU button to select Battery Infor. This menu will show you all the battery information provided that the information is supported by the battery communication system.
-
Page 12: Pin Layout
750c DISPLAY USER GUIDE Assembly Information Please note that the torque requirements described below as excessive torque can cause damage. Compatibility The clamps are suitable for 3x different handlebar sizes: 31.8mm, 25.4mm, and 22.2mm. There are transfer rings included for 25.4mm and 22.2mm (marked with L or R) as shown below. Be sure to pay attention to the directions below to insert the transfer rings correctly. -
Page 13: Certification
750c DISPLAY USER GUIDE Certification CE / IP65 (waterproof) / ROHS Be sure to contact us if further assistance is needed. Thank you! Quick Start Guide There are a few things you need to set up and check after installing your kit.
